The following table outlines the steps for removing and replacing the WLAN card on the Latitude™ D620.

Removing and Replacing the WLAN Card

1. Before removing the WLAN card:
Remove the AC power.
Remove the battery.
Remove the hinge cover.
Remove the keyboard.
2. Locate the WLAN card.
3. Disconnect the two diversity cables from the mini card.
NOTE:
There are three cables for the wireless card. The third cable is for the new wireless standard not yet
approved. However, this system can use the new technology when it is approved.
4.
Pull the two securing levers away from the card, and then remove the card.
