The following table outlines the steps for removing and replacing the memory in DIMM B on the Latitude™ D620.

Removing and Replacing the Memory in DIMM B

1. Before removing the memory in DIMM B:
Remove the AC power.
Remove the battery.
2. Locate the memory door on the bottom of the system.
3. Use a Phillips screwdriver to remove the screw securing the memory door, and then lift the door to remove it.
4.
Push outward on the retaining clips to allow the memory to release upward.
