Removing And Replacing The Phone Sim - Dell LATITUDE D620 User Manual

Dell - Latitude™ D620 - Printer-Friendly Format
The following table outlines the steps for removing and replacing the phone SIM (subscriber identity module) for the
Latitude™ D620.

Removing and Replacing the Phone SIM

1. Before removing the SIM:
Remove the AC power.
Remove the battery.
2. Locate the phone SIM in the battery bay.
CAUTION:
The customer's SIM contains account information and personal data not backed up to any media. When
repairing a system, you must migratee this card when replacing a system board.
3. Slide the module from the slot reader.
4.
Lift the module from the system.
