Weber Connect Smart Grilling Hub, 3202 Manual

PACKAGE CONTENTS

LED INDICATOR INFORMATION

QUICK START INSTRUCTIONS

1. Download the Weber Connect App and ensure that wi-fi and Bluetooth have been enabled in your smart device's settings.




2. To power the unit on, remove the protective plastic and cling coverings. Next, plug one or more probes into your Weber Connect Smart Grilling Hub.

3. To check battery status of your Smart Grilling Hub, press down on device with no probes connected.

4. When required, charge your Weber Connect Smart Grilling Hub until the charge icon illuminates green.

5. Open up the Weber Connect App on your smart device and ensure that the Weber Connect Smart Grilling Hub is within range.

6. To finalise the initial pairing with your smart device, press down on your Smart Grilling Hub when the unit displays all four of the probe indicator lights.

7. When using meat probes, ensure that the tip of the probe is inserted into the thickest section of the meat, avoiding bones or fat.
   When using ambient probes, ensure that the provided grate clip has been properly secured to the cooking surface.

8. Follow the step-by-step barbecuing instructions in your Weber Connect App.
   Enjoy your meal!

9. After using your Smart Grilling Hub, unplug the probes to power off the device and conserve battery life.


HOT SURFACE WARNING

Avoid placing the Weber Connect Smart Grilling Hub on hot surfaces such as the lid or hood of your barbecue. Device is rated to 65°C.

Device Storage

When it is not in use, store the Weber Connect Smart Grilling Hub at room temperature in a dry place, such as an indoor cupboard or drawer.

Washing the Probes

When washing Temperature Probes, use caution to avoid exposing the probe wiring and the area where the probe and wire meet to water.
Never submerge the probes in water.

HARD-RESET INSTRUCTIONS

If it is necessary, you can reset the Weber Connect Smart Grilling Hub by inserting a pin or similar item into the Reset Port and pressing for a few seconds.

INTENDED USE

Use this device for measuring and monitoring the temperature of grilled items. Any use other than that described may cause damage. The manufacturer or retailer are not liable for damages arising from improper use

Risk of Injury! The temperature probes are very sharp. Please be careful when handling probes.


Risk of Burns! Handling the temperature probes without hand protection will result in severe burns. The coloured probe indicators are not intended to be touched with bare hands while using the barbecue as they are not heat insulated. Please wear heat protective gloves while using this product at all times to avoid being burned.

Important Note: When using probes, be sure to route wire where it will not be exposed to flames or temperatures exceeding 380°C. Avoid exposing probes to temperatures below -30°C. Temperatures below -30°C or above 300°C will not display in the app and will cause the probe to disappear from connection.

Battery Disposal! Never dispose of batteries in an open fire. Always dispose of batteries in accordance with local laws.

Note: The Connect Smart Grilling Hub and batteries are not designed to withstand high heat. If the surface is too hot to touch, it's too hot for the Connect Smart Grilling Hub.
Note: The device is not to be used by children or persons with reduced physical, sensory or mental capabilities.
Frequency Range (MHz): 2402.0 - 2480.0 MHz
Output Power: 19.05 dBm

BATTERY SAFETY INFORMATION

Important Safety Instructions and Warnings for Lithium Ion (Li-Ion) Batteries

General Guidelines and Warnings

• You must read these safety instructions and warnings before using or charging your Weber Connect Smart Grilling Hub.
• Li-ion batteries are volatile. Failure to read and follow the below instructions may result in fire, personal injury and damage to property if charged or used improperly.
• Li-Ion battery packs may explode and cause fire if misused or defective.
• Use only the charger supplied with your Weber Connect Smart Grilling Hub. Do not use a NiMH or NiCd charger. Failure to do so may a cause fire, which may result in personal injury and property damage.
• Do not charge when room temperature is below 32F(0C) or above 113F (45C).
• If at any time you witness your Weber Connect Smart Grilling Hub starting to smoke while charging, discontinue the charging process immediately, disconnect the battery and observe it in a safe place for approximately 15 minutes. Observation should occur in a safe area outside of any building or vehicle and away from any combustible material.
• Never drop the unit.
• Do not charge the battery in presence of flammable liquids or gases.
• Do not expose the charger to rain or snow.
• Children should be supervised to ensure they do no play with the battery charger.
• Use caution to avoid puncture of the cell. Puncture of cells may cause a fire.

Storage & Transportation

• Store unit at room temperature for best results.
• Do not expose battery pack to direct sunlight / heat for extended periods of time. Any exposure to heat can cause significant damage or fatal injury.
• Storing battery at temperatures greater than 140F (60C) for extended periods of time (more than 2 hours) may cause damage to battery and possible fire.

Voltage, Capacity, Capacity in Watts:

• Voltage: 3.7V
• Capacity: 3.2Ah
• Capacity in Watts: 11.7 Wh
