SW-Motech EVO TRT.00.640.10800/B Mounting Instructions

Item number: TRT.00.640.10800/B
ENGLISH ·Thank you for choosing this premium product from SW-MOTECH.
Visit our online shop for more information (e.g. model assignments). Required
documents (e.g. national type approval) are available there for you to
download.
Please read and understand all the instructions, safety information and
warnings in these mounting instructions before mounting and using the
product in order to avoid injury and damage. Keep these mounting
instructions for reference.
This product was developed for vehicles in factory condition. Compatibility
with original accessories or accessories from other manufacturers cannot
be guaranteed.
These mounting instructions have been prepared to the best of our current
knowledge. No legal claims relating to accuracy can be made. Errors and
omissions excepted. We reserve the right to make technical and design
changes. The copyright is held by SW-MOTECH.
SAFETY WARNING SYMBOL
 This warning symbol is used in these mounting instructions to warn of
deadly dangers, injuries or other hazards. The words DANGER, WARNING or
CAUTION are used as part of this warning symbol to convey important safety
messages and information relating to the installation and use of this
product. These words, together with the safety warning symbol, mean:
 DANGER: Indicates a hazardous situation which, if not avoided, will result
in death or serious injury!
 WARNING: Indicates a hazardous situation which, if not avoided, may
result in death or serious injury!
 CAUTION: Indicates a hazardous situation which, if not avoided, may result
in minor or moderate injury!
 NOTE: Important information, but not relating to a risk of death or injury
(property damage only)!
GENERAL INFORMATION
 WARNING: Assembly and/or maintenance of this product requires
advanced technical skill, appropriate tools, and a good understanding of tool
usage and torque specifications. For your own safety, SW-MOTECH
recommends having the assembly and/or maintenance carried out by a
qualified and certified motorcycle workshop.
 WARNING: If you do choose to assemble this product yourself, carefully
and fully read the mounting instructions before assembly and use, and
follow all instructions to avoid serious injury or death. Also observe all
relevant information in the vehicle manual when mounting or using the
product. IF YOU DO NOT UNDERSTAND ANY PART OF THESE MOUNTING
INSTRUCTIONS OR NEED
INSTRUCTION, DO NOT ATTEMPT TO INSTALL THIS PRODUCT WITHOUT
CONSULTING SW-MOTECH FOR ASSISTANCE!
The content translation is automated.
© SW-MOTECH GmbH & Co. KG
MOUNTING INSTRUCTIONS · READ AND KEEP MOUNTING INSTRUCTIONS!

~ 0.5 h.
AN EXPLANATION AS TO
EVO top ring
PREPARATION: Read the mounting instructions carefully and make sure
that all parts on the parts list are available.
 CAUTION: Ensure that your vehicle is standing securely. Switch off the
engine and remove the ignition key. Allow the engine/exhaust to cool
down if necessary. Disconnect the battery when working on the electrical
system. Only use proper tools and always wear safety goggles and gloves
during assembly and maintenance. Have a second person help you with
assembly and maintenance.
ASSEMBLY: All parts and connections removed from the vehicle must be
reinstalled according to the vehicle manufacturer's specifications or
replaced with parts and hardware supplied by SW-MOTECH.
 WARNING: Secure all threads with a medium-strength liquid
threadlocker, unless otherwise specified.
 DANGER: Tightening torques not defined by SW-MOTECH must be
obtained from the vehicle manufacturer or a certified motorbike
workshop.
FUNCTIONAL CHECK:After mounting the product, ensure that no moving
parts are obstructed and that the function of the vehicle is not impeded.
Cables and hoses must not rub against each other and/or be hindered in any
way.
 WARNING: Carry out a comprehensive functionality check before you
start to drive. Check the tightening torque of all connections and the tight
fit of the product after the first 50 km and then at regular intervals.
Mounted accessories can change the handling and stability of the vehicle.
A SPECIFIC
SW-MOTECH GmbH & Co. KG
Ernteweg 7-10
35282 Rauschenberg
Germany
1
Revision: 00 · Date: 01 - 2024

EASY DIFFICULT
   
info@sw-motech.com

www.sw-motech.com

Subject to technical and design changes.
Errors and omissions excepted
