D01449020A
IF-ST2110
SMPTE ST 2110 INTERFACE CARD
WebUI MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IF-ST2110 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tascam IF-ST2110

  • Page 1 D01449020A IF-ST2110 SMPTE ST 2110 INTERFACE CARD WebUI MANUAL...
  • Page 2: Table Of Contents

    Creating destination streams on the Patch Screen .....44 Deleting source streams ...............44 Deleting destination streams .............45 Changing the buffer time ..............45 Tips ......................46 Maximum codec and channel numbers .........46 Maximum number of streams for this card ......47 Buffer time adjustment range ............48 TASCAM IF-ST2110 WebUI manual...
  • Page 3: Introduction

    If two cards are installed, only the one in SLOT 1 of the o TASCAM is a registered trademark of TEAC Corporation. Sonicview can be used. o Microsoft, Windows, Windows 10 and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
  • Page 4: Preparation

    For LAN cables used for connection, use STP cables that are category 5e or higher. (Both straight and crossover cables are supported.) After completing connection, turn on the device that this card has been installed in. TASCAM IF-ST2110 WebUI manual...
  • Page 5: Changing The Ip Address Of The Computer

    Search for and select the Control Panel. Open the Network and Sharing Center Click Network and Internet. In the network connections list, right-click the network adapter being used (usually Ethernet), and select Properties. Click Network and Sharing Center. TASCAM IF-ST2110 WebUI manual...
  • Page 6: Set The Ip Address

    Using the factory default settings of this card, the IP address of its CONTROL port is “192.168.0.100”. In this case, set the computer IP address to a different value. The above is a setting example when the card is using its TASCAM IF-ST2110 WebUI manual...
  • Page 7: Webui

    Settings can be made related to the card’s PTP and the status can be shown. o Config Screen (see “Config Screen” on page 32.) Various card settings can be made and their states can be shown. TASCAM IF-ST2110 WebUI manual...
  • Page 8: Setting Process

    ATTENTION After the power is turned on, this card needs about 2 1/2 minutes before it can input and output audio. This time will vary according to the setup of the network connected to the card. TASCAM IF-ST2110 WebUI manual...
  • Page 9: Overview Of Audio Data Transmission With This Card

    SDP (Session Description Protocol) is a format that describes parameters for establishing transmission. SDP data is unique to each stream. Destination streams can be created by copying and pasting SDP data to this WebUI. Stream SMPTE ST 2110-30 device SMPTE ST 2110-30 device Copy manually TASCAM IF-ST2110 WebUI manual...
  • Page 10: Wizard Screen

    Detailed information can be shown by aligning the mouse cursor with the information/help button ( ) to the side of some items. NOTE By clicking the Load WebUI button, a screen where more detailed settings and monitoring are possible can be accessed. TASCAM IF-ST2110 WebUI manual...
  • Page 11: Device Name

    1. Device Name Input/edit the device name for the card in this area. 1 Device Name Input/edit the device name. (default: IF-ST2110) NOTE The device name set for the card might be shown on other devices and computers connected to the network.
  • Page 12: Ip Address For Control Port And Net Ports

    In the same manner, if Gateway addresses are set for the media ports (PORT 1/2) of the card, a Gateway address cannot be set for its CONTROL port. NOTE If the setting made following “5. Seamless Protection Switching” on page 13 is “Enable”, PORT 1 and PORT 2 will be shown. If it is “Disable”, only PORT 1 will be shown. TASCAM IF-ST2110 WebUI manual...
  • Page 13: Net Cable Status

    Enable (default) This enables the SMPTE ST 2022-7 function. This disables the SMPTE ST 2022-7 function. Disable This setting will hide network data for PORT 2. 2 Apply button Click this button to save setting changes. TASCAM IF-ST2110 WebUI manual...
  • Page 14: Ptp Timing System

    Range: 0 – 255 NOTE PTP synchronization will not be possible if the domain value is different from the system being used. 4 Apply button This saves the PTP settings changed for 1 – 3 above. TASCAM IF-ST2110 WebUI manual...
  • Page 15: Audio Packet Time

    Limitations on the number of channels that can be included in a stream as well as the number of streams change according to the packet time setting. See “Maximum codec and channel numbers” on page 46 and “Maximum number of streams for this card” on page 47 for details. TASCAM IF-ST2110 WebUI manual...
  • Page 16: Audio Sampling Frequency

    1 Audio Channel Count Mode This selects the number of channels contained in each stream. Click this area to open a window where it can be selected. Options: Mixed, 1, 2, 4, 8 (default), 16 or 64 channels TASCAM IF-ST2110 WebUI manual...
  • Page 17: Bulk Sessions

    Make settings for this card according to the Codec settings of the other devices in the system. 5 Add Bulk IP Streams button Click this button to create multiple source streams with the content of 1 – 4 above. TASCAM IF-ST2110 WebUI manual...
  • Page 18: Explanations Of Other Screenings

    The section explains common content shown on the screens. 1 Header A TASCAM banner Click this to open the TASCAM home page. (https://teac-global.com/) B Bandwidth occupancy This shows the sending and receiving network bandwidth occupancy separately for PORT 1 and PORT 2.
  • Page 19 Restarting this card will not restart the device that it is installed in. H Load Wizard button Click this button to open the Wizard Screen. 3 Content area This shows the linked screen selected by the navigation link (D). TASCAM IF-ST2110 WebUI manual...
  • Page 20: Home Screen

    Stream connection states Appearance Connection state Green Good transmission state Orange Problem with connection Connection not achieved Number Number of problems Black mark LAN cable not connected NOTE Hovering the mouse cursor over icons will show messages. TASCAM IF-ST2110 WebUI manual...
  • Page 21 Stream is not able to be received or sent D Stream deletion button This deletes the destination stream. ATTENTION Clicking this button will immediately delete the destination stream. Use caution because no confirmation will be shown before deletion. TASCAM IF-ST2110 WebUI manual...
  • Page 22: Patch Screen

    Click the Apply button shown in the Stream display area (5) to apply changes to links. 5 Stream display area This shows details about streams that have been linked in the matrix area (4). Click the Apply button to start stream reception. Click the Clear button to remove the link. TASCAM IF-ST2110 WebUI manual...
  • Page 23: Source Screen

    Clicking these buttons will immediately delete the destination streams. Use caution because no confirmation will be shown before deletion. i Clicking a stream will open the Source information menu. (see “Source Screen Source information menu” on page 25.) TASCAM IF-ST2110 WebUI manual...
  • Page 24: Source Screen Add Source Menu

    Multiple source streams can be created at once by setting the items in this area. See “10. Bulk Sessions” on page 17 in the Wizard Screen section for details about these settings. button Click this button to close the Add Source menu. TASCAM IF-ST2110 WebUI manual...
  • Page 25: Source Screen Source Information Menu

    This applies changes made on the Source Screen Add Source menu in the channel settings (H), address settings (I) and stream settings (J) areas. P SDP Information area SDP data for the selected source stream is shown here. The session ID is shown outside the field. button Click this button to close the Source information window. TASCAM IF-ST2110 WebUI manual...
  • Page 26: Destination Screen

    Clicking this button will immediately delete the destination stream. Use caution because no confirmation will be shown before deletion. i Clicking a stream will open the Update Destination menu. (see “Destination Screen Update Destination menu” on page 28.) TASCAM IF-ST2110 WebUI manual...
  • Page 27: Destination Screen Add Destination Menu

    “SSM Mode” on page 35 o “Changing the buffer time” on page 45 M Add Destination button Click this button to create a destination stream with the above settings. button Click this button to close the Add Destination menu. TASCAM IF-ST2110 WebUI manual...
  • Page 28: Destination Screen Update Destination Menu

    This applies stream setting changes using the above Destination stream name (P) and Link Offset setting area (R) content. T SDP Information area SDP data for the selected destination stream is shown here. The session ID is shown outside the field. button Click this button to close the Update Destination menu. TASCAM IF-ST2110 WebUI manual...
  • Page 29: Sync Screen

    If another device in the system being used has the same Priority 1 value as this card, the one with the lower priority 2 value will have precedence to become the PTP master. Apply button This saves the PTP domain and Priority 1/2 settings. TASCAM IF-ST2110 WebUI manual...
  • Page 30 If the Auto Refresh switch is “ON”, the graph will update automatically. i Click the RAW Offset button to change the graph calculation method to raw numbers. i Click the RMS Avg button to change the graph calculation method to the average value since startup. TASCAM IF-ST2110 WebUI manual...
  • Page 31 6 – Explanations of other screenings TASCAM IF-ST2110 WebUI manual...
  • Page 32: Config Screen

    WebUI Version: NOTE Information about the version of the card itself is not shown in this WebUI. To check the version information of this card, follow the operation procedures of the device that it is connected to. TASCAM IF-ST2110 WebUI manual...
  • Page 33: Audio Configuration Page

    SDP Source Interface The Ethernet port used as the source for SDP files can be selected. Options: Control (default), PORT 1, PORT 2 Apply button (A) Click the Apply button (A) to confirm the above changed settings. TASCAM IF-ST2110 WebUI manual...
  • Page 34: Connection Configuration Page

    When this is enabled, detection, registration and control of devices that are compliant with NMOS specifications are possible. Options: Enable, Disable (default) Advertised Receiver Channel Size This shows the maximum number of channels per stream when receiving streams using NMOS. TASCAM IF-ST2110 WebUI manual...
  • Page 35: Misc Configuration

    In this case, this can be prevented by using the “Receivers Only Mode” setting, which limits the control extent of this card using ANEMAN to destination streams. TASCAM IF-ST2110 WebUI manual...
  • Page 36: Board Configuration Page

    This will set all settings on the Connection Configuration page of the Config Screen to their default values. i This will restore the settings on the Sync Screen to their default values. i This will delete the streams on the Source Screen and Destination Screen. i This will restart the card automatically. TASCAM IF-ST2110 WebUI manual...
  • Page 37 For details about using the update screen, see the separate WebUI update manual. ATTENTION Only updater files provided by TASCAM can be used to update this WebUI. Updating with any other file will make this WebUI and the card inoperable. Do not update using anything other than an updater provided by TASCAM.
  • Page 38: Troubleshooting Page

    Select the desired port on the card to use for packet capture. Option Meaning eth0 Control eth1 PORT 1 eth2 PORT 2 5 Request Debug button Clicking this button will generate a log of operations since the card was started as a compressed file. TASCAM IF-ST2110 WebUI manual...
  • Page 39 6 – Explanations of other screenings TASCAM IF-ST2110 WebUI manual...
  • Page 40: Changing Various Settings

    When using this card to send and receive audio, always set this card as the Clock Master of the device that this card is installed in. If not set this way, noise could occur in the audio and operation could become unstable. When using this card with a Sonicview, always select this card for the Clock Master setting. TASCAM IF-ST2110 WebUI manual...
  • Page 41: Changing The Sampling Frequency And Packet Time

    If an error appears and the setting cannot be changed, see “Audio Configuration page” on page 33. ATTENTION Changing the sampling frequency or packet time will delete all source and destination streams. TASCAM IF-ST2110 WebUI manual...
  • Page 42: Making Audio Stream Transmission And Reception Settings

    The number of channels that can be included in a stream has a maximum limit. (see “Maximum codec and channel numbers” on page 46.) i The maximum output of this card is 64 channels, so no more than 64 can be selected.   TASCAM IF-ST2110 WebUI manual...
  • Page 43: Creating Destination Streams

    Confirm that the desired stream has been created in the destination stream display area of the Destination Screen. Click any stream and open the Update Destination menu. Then, check the stream settings in the SDP Information area. TASCAM IF-ST2110 WebUI manual...
  • Page 44: Creating Multiple Source Streams With Bulk Processing

    The bit depth, sampling frequency, packet time and number of channels are values that fit in one stream i The number of streams being created does not exceed the maximum for this card (see “Maximum codec and channel numbers” on page 46.) TASCAM IF-ST2110 WebUI manual...
  • Page 45: Deleting Destination Streams

    48.) Click the Update Destination Button. This will refresh the browser. Look at the Link Offset field in the destination stream display area and confirm that the buffer time for the stream changed as desired. TASCAM IF-ST2110 WebUI manual...
  • Page 46: Tips

    48 kHz, 125 usec channels channels channels channels 1 to 3 1 to 3 1 to 3 96 kHz, 1 msec channels channels channels 1 to 8 1 to 30 96 kHz, 125 usec channels channels TASCAM IF-ST2110 WebUI manual...
  • Page 47: Maximum Number Of Streams For This Card

    Example maximum numbers of streams for this card P [µs] S [Hz] B [bit] Maximum number of streams 1000 1000 1000 1000 1000 1000 TASCAM IF-ST2110 WebUI manual...
  • Page 48: Buffer Time Adjustment Range

    Decreasing the buffer time increases the chance of packet loss when changing transmission routing, but it also reduces transmission delay. class D class A BufferTime 150 μs 10 ms if Packet Time = 125 μs 250 μs 4000 μs if Packet Time = 1 ms 2000 μs 32000 μs TASCAM IF-ST2110 WebUI manual...
  • Page 49: Troubleshooting

    Confirm that PTP synchronization is occurring. (See “PTP synchronization is not possible” above.) o Confirm that the clock master setting of the device that this card is installed in is set to IF-ST2110 (this card). o Confirm that the number of cards in the device that this is installed in do not exceed its capacity. (see “Compatible models for installation”...
  • Page 50 TEAC CORPORATION https://tascam.jp/jp/ 1-47 Ochiai, Tama-shi, Tokyo 206-8530 Japan TEAC AMERICA, INC. https://tascam.com/us/ 10410 Pioneer Blvd., Unit #3, Santa Fe Springs, CA 90670, U.S.A TEAC UK Ltd. https://www.tascam.eu/en/ Luminous House, 300 South Row, Milton Keynes, Buckinghamshire, MK9 2FR, UK TEAC EUROPE GmbH https://www.tascam.eu/de/...
