Setting The Humidity
Setting The Humidity
Follow the steps below to change your
target humidity setpoint.
Press the humidity button.
Use the or button to
select the target humidity
setpoint. Press DONE when
completed.
Note:
The target humidity setpoint is not
programmable. Unlike temperature,
humidity does not change quickly
and should not be programmed.
Note:
Humidity is only energized during
heat. Dehumidity is only energized
during cool. Heat and cool each have
their own target setpoints.
Ambient Humidity Display
Ambient humidity will flash opposite the day and time, if the optional
outdoor temperature sensor is installed the ambient outdoor temperature
will also cycle in the display.
Mon
Humidity %
39
Ambient Humidity
Increasing Humidity
The table on the right shows
recommended indoor humidity
levels in relation to outdoor
temperatures during heating
(adding humidity).
Consult your professional HVAC
technician for recommended
settings for your climate.
29
Programming
Day of
Events
the Week
Wake/OCC1
Leave/UNOCC1
Return/OCC2
Weekday
Sleep/UNOCC2
Occupied
Unoccupied
Wake/OCC1
Leave/UNOCC1
Return/OCC2
Saturday
Sleep/UNOCC2
Occupied
Unoccupied
Wake/OCC1
LeaveUNOCC1
Return/OCC2
Sunday
Sleep/UNOCC2
Occupied
Unoccupied
33
Menu
Humidity Key
39
Target humidity setpoint keys
AM
Day & Time Outdoor Temperature
Outside Recommended
Temperature (0°) Relative Humidity
+20° and above 35% to 40%
+10°
0°
-10°
-20°
Custom Program
Setpoint
Time
Temperature Temperature
(HEAT)
Programming
Set Time
(If using programming)
Follow the steps below to set the day of the week and current time:
Set At
1. Press the MENU button.
2. Press Set Time.
3. Day of the week is flashing. Use the
select the current day of the week.
4. Press Next Step.
5. The current hour is flashing. Use the
select the current hour. When using 12-hour time, make sure
the correct a.m. or p.m. choice is selected.
Humidity %
6. Press Next Step.
7. Minutes are now flashing. Use the
select current minutes.
8. Press DONE when completed.
Programming
All our programmable thermostats are shipped with an energy saving default
program. You can customize this default program by following the
instructions in the set program schedule section starting on page 34.
Your thermostat can be programmed to have each day of the week
programmed uniquely (7 days), all the weekdays the same with a separate
program for Saturday and a separate program for Sunday (5+1+1), or
OUTDOOR
non-programmable. For the 7-day and 5+1+1 programming modes, there are
three time period options.
1. "4" Residential (WAKE, LEAVE, RETURN, SLEEP)
2. "2C" Commercial (OCCUPIED, UNOCCUPIED)
3. "4C" Commercial (OCCUPIED 1, UNOCCUPIED 1, OCCUPIED 2, UNOCCUPIED 2)
30%
25%
This thermostat has a programmable fan feature, which allows you to run the
20%
fan continually during any time period.
15%
Programming
Set Program Schedule For Two Time Periods
To customize your 5+1+1 Program schedule, follow these steps:
Setpoint
Weekday:
(COOL)
1. Select HEAT or COOL with the SYSTEM key.
Note: You have to program heat and cool each separately.
2. Press the MENU button (If menu does not appear first, press
RUN SCHED).
3. Press SET SCHED. Note: Monday-Friday is displayed and the
OCCUPIED text is shown. You are now programming the
OCCUPIED time period for the weekday setting.
4. Use the
weekday OCCUPIED time period. Note: If you want the fan to run
continuously during this time period, select ON with the FAN key.
5. Then use the
the weekday OCCUPIED period.
6. Press Next Step.
7. Repeat steps 4 through 6 for the weekday UNOCCUPIED
time period.
Saturday:
Repeat steps 4 through 6 for the Saturday OCCUPIED time period
and for the Saturday UNOCCUPIED time period.
Sunday:
Repeat steps 4 through 6 for the Sunday OCCUPIED time period, and
for the Sunday UNOCCUPIED time period.
or
or
or key to make your time selection for the
or key to make your setpoint selection for
key to
or key to
key to
30
(OCCUPIED, UNOCCUPIED)
