Pro1 Technologies T755WH Installation Manual page 10

Programming
To customize your 7 day Program schedule, follow these steps:
Monday:
1. Select HEAT or COOL with the SYSTEM key.
Note: You have to program heat and cool each separately.
2. Press the MENU button (If menu does not appear first, press
RUN SCHED).
3. Press SET SCHED. Note: Monday is displayed and the
WAKE/OCC1 icon is shown. You are now programming the
WAKE/OCC1 time period for that day.
4. Use the
or key to make your time
selection for that day's WAKE/OCC1 time period.
Note: If you want the fan to run continuously during this time
period, select ON with the FAN key.
5. Then use the
or
that day's WAKE/OCC1 period.
6. Press Next Step.
7. Repeat steps 4 through 6 for
time period, for
that day's
SLEEP/UNOCC2 time period.
and for
that day's
Repeat steps 4 through 6 for the remaining days of the week.
A Note About Auto Changeover:
In Auto you have the ability to switch between Auto Heat or Auto Cool
by pressing the system key. This can be done once the current mode has
reached its setpoint. For example: if in Auto Heat, the heat setpoint must
be satisfied before the thermostat will allow you to switch to Auto Cool.
You can switch out of Auto by holding down the SYSTEM key. To get
back into Auto, you must toggle the system key to Auto.
37
Specifications
Specifications
The display range of temperature ... 41˚F to 95˚F (5˚C to 35˚C)
The control range of temperature.... 44˚F to 90˚F (7˚C to 32˚C)
Load Rating............................................... 1 amp per terminal, 1.5 amp
Swing (cycle rate or differential) ...... Heating is adjustable from 0.2˚ to 2.0˚
Power source ...........................................18 to 30 VAC, NEC Class II, 50/60 Hz
Operating ambient ............................... 32˚F to +105˚F (0˚C to +41˚C)
Operating humidity .............................. 90% non-condensing maximum
Dimensions of thermostat ................. 4.7" W x 4.3" H x 1.1" D
Frequency ................................................ 916 MHz
Base module
Load rating ............................................... 1 amp per terminal, 1.5 amp
Power source ........................................... 18 to 30 VAC, NEC class II, 50/60 Hz
Operating ambient ............................... 32°F to +150°F (0° to +65°C)
Operating humidity .............................. 90% non-condensing maximum
39
key to make your setpoint selection for
LEAVE/UNOCC1
that day's
RETURN/OCC2 time period,
maximum all terminals combined
Cooling is adjustable from 0.2˚ to 2.0˚
for hardwire
Battery power from 2 AA Alkaline
batteries
maximum all terminals combined
Features
Temporary & Permanent Hold Feature
Temporary Hold: The thermostat will display HOLD and Run Sched-
ule on the bottom of the screen when you press the
key. If you do nothing, the temperature will remain at this setpoint
temporarily for 4 hours. The program setpoint will then replace the
temporary setpoint.
Permanent Hold: With a temporary hold set, If you press the HOLD
key at the bottom of your screen, you will see HOLD appear next to
the setpoint temperature in the display. The thermostat will now
permanently stay at this setpoint and can be adjusted using the
or keys.
To Return To Program: Press the Run Schedule key at the bottom of
the screen to exit temporary and permanent holds.
Filter Change Reminder
If your installing contractor has configured the thermostat to re-
mind you when the air filter needs changed, you will seea reminder
in the display when your air filter needs changed. the reminder will
be shown in the display after your system has run long enough to
require an air filter change.
Resetting the filter change reminder: When the reminder is
displayed, you should change your air filter and reset the reminder by
holding down the "Clean" key on the left side of the thermostat for 3
seconds.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reason-able protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a installation. If this equipment does cause harmful interference
to radio or television reception, which can be deter-mined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
FCC RF Exposure Statement
The device shall be used in such a manner that the potential for human
contact normal operation is minimized. This equipment complies with FCC
radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of
20cm between the radiator and your body. This device and its antenna(s)
must not be co-located or operating in conjunction with any other antenna
or transmitter.
or
38
40
