Model
Indoor unit
Outdoor unit
AC TIM 09HDN S8ML-01
Refrigerant piping, Liquid side / Gas
side, (inch)
Max. refrigerant pipe length, m
Maximum difference in level, m
Filling of Freon, g
Operating temperature range:
cooling, ° C
Operating temperature range:
heating, ° C
Net weight, indoor unit (kg)
Net weight, outdoor unit (kg)
Gross weight, indoor unit (kg)
Gross weight, outdoor unit (kg)
Net dimensions, indoor unit (mm)
Net dimensions, outdoor unit (mm)
Packing dimensions, indoor unit
(mm)
Packing dimensions, outdoor unit
(mm)
AC TIM 09HDN S8ML AC TIM 12HDN S8ML
AC TIM 09HDN S8ML AC TIM 12HDN S8ML
AC TIM 12HDN S8ML-01
1/4 / 3/8 1/4 / 1/2
15
5
680
+18 ~ +43 +18 ~ +43
-7 ~ + 24 -7 ~ + 24
8
32
10
36
816x265x200 816x265x200
760x552x256 760x552x256
870x332x265 870x332x265
863x600x325 863x600x325
AC TIM 18HDN S8ML
AC TIM 18HDN S8ML
AC TIM 18HDN S8ML-01
1/4 / 1/2
15 15
5 5
880 1280
+18 ~ +43
-7 ~ + 24
8 11
32 40
10 14
36 44
946x308x226
820x605x300
1013x379x311
930x640x380
www.timberk.com • Electric air conditioner
AC TIM 24HDN S8ML
AC TIM 24HDN S8ML
AC TIM 24HDN S8ML-01
3/8 / 5/8
15
5
1800
+18 ~ +43
-7 ~ + 24
14
49
17
54
1089x315x226
902x650x315
1155x395x315
1028x705x430
