EN User Manual | Oven
ZOUNX3X1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZOUNX3X1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Zanussi ZOUNX3X1

  • Page 1 EN User Manual | Oven ZOUNX3X1...
  • Page 2: Table Of Contents

    VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................8 5. CONTROL PANEL..................8 6. BEFORE FIRST USE..................9 7.
  • Page 3: General Safety

    be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use.
  • Page 4: Safety Instructions

    • WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. • WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements or the surface of the appliance cavity. •...
  • Page 5: Electrical Connection

    The isolation device must have a contact opening width of minimum 3 mm. Type Maximum power • This appliance is supplied without a main ZHDN670X 6400 W plug and a main cable. • The hob connection socket is at the top of ZHDN640X 6000 W the oven cabinet.
  • Page 6: Internal Lighting

    2.3 Use • Always cook with the appliance door closed. WARNING! 2.4 Care and cleaning Risk of injury, burns and electric shock or explosion. WARNING! • Do not change the specification of this Risk of injury, fire, or damage to the appliance.
  • Page 7: Installation

    • Use original spare parts only. • Disconnect the appliance from the mains supply. 2.7 Disposal • Cut off the mains electrical cable close to the appliance and dispose of it. • Remove the door catch to prevent children WARNING! or pets from becoming trapped in the Risk of injury or suffocation.
  • Page 8: Product Description

    4. PRODUCT DESCRIPTION 4.1 General overview Control panel Knobs for the hob Power lamp / symbol Knob for the heating functions Display Control knob (for the temperature) Temperature indicator / symbol Heating element Lamp Cavity embossment - Aqua cleaning container Shelf support, removable Shelf positions 4.2 Accessories...
  • Page 9: Retractable Knobs

    5.4 Retractable knobs 2. Turn the knob slowly to the symbol until you can hear a click. The two To use the appliance press the knob. The cooking zones are on. knob comes out. 3. To set the necessary heat setting refer to "Heat settings".
  • Page 10: Daily Use

    Remove all accessories and re‐ Set the maximum temperature - press to set the time. movable shelf supports from After approximately 5 sec., the for the function: the oven. flashing stops and the display Time: 1 h. Clean the oven and the acces‐ shows the time.
  • Page 11: Clock Functions

    requirements (according to EU 65/2014 and EU 66/2014). Tests according to: IEC/EN Heating func‐ Application 60350-1. tion The oven door should be closed during To bake and roast food on one cooking so that the function is not interrupted shelf position. and the oven operates with the highest Refer to "Care and cleaning"...
  • Page 12: Using The Accessories

    How to set: Duration Step 2 - press repeatedly. - starts to flash. Step 3 - press to set the duration. The display shows: - flashes when the set time ends. The signal sounds and the oven turns off. Step 4 Press any button to stop the signal.
  • Page 13: Additional Functions

    Wire shelf: Push the shelf between the guide bars of the shelf support and make sure that the feet point down. Baking tray: Push the tray between the guide bars of the shelf support. 10. ADDITIONAL FUNCTIONS 10.1 Cooling fan 10.2 Safety thermostat When the appliance operates, the cooling fan Incorrect operation of the oven or defective...
  • Page 14: Moist Fan Baking - Recommended Accessories

    deep pan. To prevent the smoke Initially, monitor the performance when you condensation, add water each time after it cook. Find the best settings (heat setting, dries up. cooking time, etc.) for your cookware, recipes and quantities when you use this appliance. Cooking times Cooking times depend on the type of food, its consistency, and volume.
  • Page 15: Information For Test Institutes

    (°C) (min) Shashlik, 0.5 kg baking tray or dripping pan 40 - 50 Cookies, 16 pieces baking tray or dripping pan 30 - 45 Macaroons, 20 pieces baking tray or dripping pan 45 - 55 Muffins, 12 pieces baking tray or dripping pan 30 - 40 Savory pastry, 16 baking tray or dripping pan...
  • Page 16: Care And Cleaning

    ( °C) (min) Fatless True Fan Wire shelf 40 - 50 Preheat the oven for sponge Cooking 10 min. cake, cake mould Ø26 Fatless True Fan Wire shelf 2 and 4 40 - 60 Preheat the oven for sponge Cooking 10 min.
  • Page 17 Clean the cavity after each use. Fat accumulation or other residue may cause fire. Moisture can condense in the appliance or on the door glass panels. To decrease the con‐ densation, let the appliance work for 10 minutes before cooking. Do not store the food in the appliance for longer than 20 minutes.
  • Page 18 12.4 How to remove and install: Door The oven door has two glass panels. You can remove the oven door and the internal glass panel to clean it. Read the whole "Removing and installing door" instruction before you remove the glass panels. CAUTION! Do not use the oven without the glass panels.
  • Page 19 Step 7 Hold the door glass panel by its top edge and carefully pull it out. Make sure the glass slides out of the supports completely. Step 8 Clean the glass panels with water and soap. Dry the glass panels carefully. Do not clean the glass panels in the dishwasher.
  • Page 20: Troubleshooting

    14. ENERGY EFFICIENCY 14.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name Zanussi Model identification ZOUNX3X1 949723468 Energy Efficiency Index 95.3 Energy efficiency class Energy consumption with a standard load, conventional mode 0.93 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.81 kWh/cycle...
  • Page 21: Energy Saving

    IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐ ods for measuring performance. 14.2 Energy saving Cooking with fan When possible, use the cooking functions with fan to save energy. Residual heat The appliance has features which help When the cooking duration is longer than 30 you save energy during everyday...
  • Page 24 867359970-B-192023...
