Foxwell NT630 Pro User Manual
Hide thumbs Also See for NT630 Pro:

Advertisement

Quick Links

Trademarks
FOXWELL is the trademark of Shenzhen Foxwell Technology Co., Ltd.
All other marks are trademarks or registered trademarks of their respective holders.
Copyright Information
©2024 Shenzhen Foxwell Technology Co., Ltd.
All rights reserved.
Disclaimer
The information, specifications and illustrations in this manual are based on the latest information available at the
time of printing.
Foxwell reserves the right to make changes at any time without notice.
Visit our website at
www.foxwelltech.us
For Technical Assistance, send us email at
support@foxwelltech.com
1
NT630 Pro User's Manual_English_V1.03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NT630 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Foxwell NT630 Pro

  • Page 1 Disclaimer The information, specifications and illustrations in this manual are based on the latest information available at the time of printing. Foxwell reserves the right to make changes at any time without notice. Visit our website at www.foxwelltech.us For Technical Assistance, send us email at support@foxwelltech.com...
  • Page 2: One-Year Limited Warranty

    FOXWELL. 3 The customer shall bear the cost of shipping the product to FOXWELL. And FOXWELL shall bear the cost of shipping the product back to the customer after the completion of service under this limited warranty.
  • Page 3 repaired.
  • Page 4: Safety Information

    (for manual transmission). And never leave a running engine unattended. Do not wear jewelry or loose fitting clothing when working on engine. ● Don't connect or disconnect the equipment while the ignition is on or the engine is running. ● NT630 Pro User’s Manual_English_V1.03...
  • Page 5: Table Of Contents

    4.3.2 Clear Codes .......................... 20 4.3.3 ECU Information ........................20 4.3.4 Live Data ..........................21 4.3.4.1 Complete List ........................21 4.3.4.2 Custom List ........................23 4.3.5 Active Test ........................... 25 4.3.6 Special Functions ........................26 5 OBDII/EOBD OPERATIONS ......................28 NT630 Pro User’s Manual_English_V1.03...
  • Page 6 REATE A OXWELL 10.1.1 Register Through Website ....................65 10.1.2 Register by Scanning QR Code ..................67 ......................... 68 10.2 R EGISTER CANNER 10.2.1 Register Product Through Website ..................68 10.2.2 Register Product by Scanning QR Code ................. 69 NT630 Pro User’s Manual_English_V1.03...
  • Page 7: Using This Manual

    IMPORTANT indicates a situation which, if not avoided, may result in damage to the test equipment or vehicle. Example: IMPORTANT Do not soak keypad as water might find its way into the scanner. 2 Introductions This series of scanners from Foxwell are innovative diagnostic tools for most vehicles on the road today. NT630 Pro User’s Manual_English_V1.03...
  • Page 8: Scanner Descriptions

    2 Diagnostic Cable - provides connection between the scanner and a vehicle. 3 USB Cable - provides connection between the scanner and a computer to update and print data. 4 Warranty Card - A warranty card is required if you need any repair or replacement from us. NT630 Pro User’s Manual_English_V1.03...
  • Page 9: Technical Specifications

    Diagnostic - leads to screens for diagnostic trouble code information, live data stream, ECU information of ● a variety of vehicles. Maintenance - leads to screens of tests of the most frequently required service features. ● NT630 Pro User’s Manual_English_V1.03...
  • Page 10: Input Dialog Box

    ● hexadecimal keyboard for special functions, such as key matching, UDS coding ● To input text with the scan tool: 1. When you are requested to input text, press the function key Keyboard. NT630 Pro User’s Manual_English_V1.03...
  • Page 11: Diagnostic Operations

    Each selection you make advances you to the next screen. A Back button in the upper left corner of the screen returns you to the previous screen. Exact procedures may vary somewhat by vehicle. It typically identifies a vehicle by any of the following means: NT630 Pro User’s Manual_English_V1.03...
  • Page 12: 1Auto Vin

    Figure 4-2 Sample Application Menu 2.A screen with vehicle manufacturer areas displays. Select the area where the vehicle manufacturer is from. A menu of all vehicle manufacturers from this areadisplays. NT630 Pro User’s Manual_English_V1.03...
  • Page 13 Figure 4-4 Sample Vehicle Manufacturer Selection Screen 4.Select SmartVIN from the menu, and press the ENTER key. Figure 4-5 Sample VIN Acquisition Screen 5.The scan tool starts to communicate with the vehicle and read the Vehicle Specification or VIN Code NT630 Pro User’s Manual_English_V1.03...
  • Page 14: 2Manual Vin Entry

    Manual VIN Entry identifies a vehicle by manually inputting a 17-digit VIN code. To identify a vehicle by manual VIN entry: 1.Refer to Step 1-3 of 4.1.1 Automatic VIN Acquisition. 2.Select an appropriate option from the menu. A virtual keyboard opens for VINentry. NT630 Pro User’s Manual_English_V1.03...
  • Page 15: 3Manual Vehicle Selection

    2.On each screen that appears, select the correct option and then press the ENTER key. Do this until the complete vehicle information is entered and the menu of controller selectiondisplays. Figure 4-9 Sample Manual Vehicle Selection Screen NT630 Pro User’s Manual_English_V1.03...
  • Page 16: System Selection

    5.4-11To pause the scan, press the function key corresponding with Pause on the screen. Figure 4-11 Sample Automatic system scan screen 6.At the end of successful automatic controller scan, a menu with a list of installed controllers together with their DTC overview displays. NT630 Pro User’s Manual_English_V1.03...
  • Page 17 8.Press function key F1 to save the trouble code information. 9.Select the system you would like to test, and press the ENTER key. When the scanner has established connection with the vehicle, the Function Menu displays. Figure 4-14 Sample Function Menu screen NT630 Pro User’s Manual_English_V1.03...
  • Page 18: Manual Selection

    After a system is selected and the scanner establishes communication with the vehicle, the Function Menu displays. The menu options may include: Read Codes ● Erase Codes ● ECU Information ● Live Data ● Special Function ● NT630 Pro User’s Manual_English_V1.03...
  • Page 19: Read Codes

    Figure 4-17 Sample Function menu screen 13.Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. Figure 4-18 Sample Code Screen NT630 Pro User’s Manual_English_V1.03...
  • Page 20: Clear Codes

    17.Check the codes again. If any codes remain, repeat the Clear Codes steps. 4.3.3 ECU Information ECU Information screen displays the identification data of the control module under test, such as the control module identification string and the control module coding. NT630 Pro User’s Manual_English_V1.03...
  • Page 21: Live Data

    Complete Data List menu lets you view all live PID data from a selected system. To view all live PID data 1. Scroll with the arrow keys to highlight Live Data from the menu and press the ENTER key to display the live data menu. NT630 Pro User’s Manual_English_V1.03...
  • Page 22 Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. Figure 4-25 Sample PID graph Screen NT630 Pro User’s Manual_English_V1.03...
  • Page 23: Custom List

    Custom List menu lets you to minimize the number of PIDs on the data list and focus on any suspicious or symptom-specific data parameters. To create a custom list: 1.Select Custom List from the menu and press the ENTER key. NT630 Pro User’s Manual_English_V1.03...
  • Page 24 To deselect an item, select it again and then press the ENTER key. Alternatively, use the function keys Select All and Deselect to select or deselect all items at once. 3.When finished selection, use the function key VIEW DATA to display selected items. NT630 Pro User’s Manual_English_V1.03...
  • Page 25: Active Test

    To start a test: 1. Press Active Test from the menu. Figure 4-31 Sample Active Test Screen 2.Select an option to start the test . NT630 Pro User’s Manual_English_V1.03...
  • Page 26: Special Functions

    Actuator Tests – allows to manually control the actuators in order to test AYC valves, inlet valves, ● outlet valves, pump motors, and TRACS valves. Autobleed Test, Automated Bleed, or Service Bleed – removes air from the internal brake fluid ● chambers after servicing the brakes. NT630 Pro User’s Manual_English_V1.03...
  • Page 27 Voltage Load Test – “loads” the ABS battery supply circuit to test for adequate battery capacity. ● To perform special tests on a vehicle: 1. Scroll with the arrow keys to Service on the menu and press the ENTER key. NT630 Pro User’s Manual_English_V1.03...
  • Page 28: Obdii/Eobd Operations

    5 OBDII/EOBD Operations OBD-II/EOBD menu lets you access all OBD service modes. According to ISO 9141-2, ISO 14230-4, and SAE J1850 standards, the OBD application is divided into several sub programs, called ‘Service $xx’. NT630 Pro User’s Manual_English_V1.03...
  • Page 29: Diagnostic Trouble Codes & Ffd

    If a fault occurs a specific number of times, the code matures into a DTC and the MIL illuminates or blinks. To read codes/pending codes from a vehicle: 1. Scroll with the arrow keys to highlight Diagnostic trouble codes & FFD from Diagnostic Menu and press the ENTER key. NT630 Pro User’s Manual_English_V1.03...
  • Page 30 DTC information. 3. Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. NT630 Pro User’s Manual_English_V1.03...
  • Page 31 “?”means there are help information. No “?”means there are no help information. 4. Click “ Erase “ to erase codes. Figure 5-4 Sample Erase Codes Screen 5. Follow the on-screen instructions and answer questions about the vehicle being tested to complete the procedure. NT630 Pro User’s Manual_English_V1.03...
  • Page 32: Live Data

    1. Scroll with the arrow keys to highlight Live Data from the menu and press the ENTER key to display the live data menu. Figure 5-6 Sample Live Data Selection Screen 2. Select the Complete List from the menu and press the ENTER key to display the datastream screen. NT630 Pro User’s Manual_English_V1.03...
  • Page 33 Press the function key One Graphic to display the PID graph. Figure 5-9 Sample PID Graph Screen 5. Press the function key Two Graphics to display two PID graphs in one screen NT630 Pro User’s Manual_English_V1.03...
  • Page 34: Custom List

    Custom Data List menu lets you to minimize the number of PIDs on the data list and focus on any suspicious or symptom-specific data parameters. To create a custom data list: 1.Select Custom List from the menu and press the ENTER key. NT630 Pro User’s Manual_English_V1.03...
  • Page 35 To deselect an item, select it again and then press the ENTER key. Alternatively, use the function keys Select ALL and Deselect to select or deselect all items at once. 3.When finished selection, use the function key VIEW DATA to display selected items. NT630 Pro User’s Manual_English_V1.03...
  • Page 36: Freeze Frame

    2. Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. If no freeze frame detected, the message “No freeze frame data stored!” is displayed. NT630 Pro User’s Manual_English_V1.03...
  • Page 37: Read I/M Readiness Status Data

    Evaporative System Monitor Sec Air System Secondary Air System Monitor A/C Refrig Mon Air Conditioning Refrigerant Monitor Oxygen Sens Mon Oxygen Sensor Monitor Oxygen Sens Htr Oxygen Sensor Heater Monitor Exhaust Gas Recirculation System EGR System Mon Monitor NT630 Pro User’s Manual_English_V1.03...
  • Page 38 5. Depending on readiness test, one of these 2 screens will be present. Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. Figure 5-18 Sample IM Readiness Screen 1 NT630 Pro User’s Manual_English_V1.03...
  • Page 39: Sonda Lambda Monitor

    ENTER key. A screen with a list of available sensors displays. Figure 5-20 Sample Diagnostic Menu Screen 2. Scroll with the arrow keys to highlight an O2 sensor and press the ENTER key to confirm. A screen with details of the selected sensor displays. NT630 Pro User’s Manual_English_V1.03...
  • Page 40 3. Use the up and down arrow keys to scroll through data to select lines, and left and right arrow keys to scroll back and forth through different screens of data. Figure 5-22 Sample O2 Bank1 Sensor 1 Screen 4. Press Enter key to view data of selection. Figure 5-23 Sample data of $81 screen NT630 Pro User’s Manual_English_V1.03...
  • Page 41: On-Board Monitor Test

    1. Scroll with the arrow keys to highlight On-Board Monitor Test from Diagnostic Menu and press the ENTER key. Figure 5-24 Sample Diagnostic Menu Screen 2. Depending on the protocol the vehicle used, one of these 2 screens shows. Figure 5-25 Sample Non-CAN Vehicle Test Screen NT630 Pro User’s Manual_English_V1.03...
  • Page 42 For non-CAN vehicles, test screen is illustrated as below: Figure 5-27 Sample Non-CAN vehicle test screen For CAN vehicles, test screen is illustrated as below: Figure 5-28 Sample Can vehicle test screen NT630 Pro User’s Manual_English_V1.03...
  • Page 43: Component Test

    “Command Sent!”. Figure 5-30 Sample Component test screen 7. Press the BACK key to exit and return. 5.8 Request Vehicle Information Vehicle Information allows to request the vehicle’s VIN number, calibration ID(s) which identifies NT630 Pro User’s Manual_English_V1.03...
  • Page 44 2. Follow on-screen instruction and send the command to read vehicle information. A screen with a list of available options displays. Figure 5-32 Sample Vehicle Info Screen 3. Scroll with the arrow keys to highlight an available option and press the ENTER key. A screen with details of the selected option displays. NT630 Pro User’s Manual_English_V1.03...
  • Page 45: Vehicle Status

    1. Scroll with the arrow keys to highlight Vehicles status from Diagnostic Menu and press the ENTER key. Figure 5-34 Sample Diagnostic Menu Screen 2. A screen with the module IDs and protocols displays. Figure 5-35 Sample Module Present Screen NT630 Pro User’s Manual_English_V1.03...
  • Page 46: Dtc Query

    Manufacturer Specific), the scanner displays “DTC definition not found! Please refer to vehicle service manual!” If a P1xxx, C1xxx, B1xxx or U1xxx code is entered, select a vehicle make to look for DTC definitions. Press the Back key to exit. Figure 5-38 Sample Trouble Codes Screen NT630 Pro User’s Manual_English_V1.03...
  • Page 47: Battery Test Operations

    To start a battery test: 1. Scroll with the UP or DOWN button to highlight Battery Test from Main Menu and press the ENTER key. NT630 Pro User’s Manual_English_V1.03...
  • Page 48 Figure 6-4 Sample Select Battery Type Screen 4. Scroll with the UP or DOWN button to select the battery standard from BATTERY STANDARD menu and press ENTER to confirm. Not all rating systems are available for each application. NT630 Pro User’s Manual_English_V1.03...
  • Page 49 5. Use button to change measure range till you enter the correct range of your battery. Press ENTER to start the test.( UP or DOWN button modification value is ±5, Left or right button modification value is ±50) NT630 Pro User’s Manual_English_V1.03...
  • Page 50 YES or NO. Figure 6-7 Sample Query Screen Figure 6-8 Sample Query Screen 7. View test results on the screen. Depending on battery status, one of the following test results may display. Figure 6-9 Sample Battery Test Screen NT630 Pro User’s Manual_English_V1.03...
  • Page 51: Cranking Test

    2. Follow the instructions on the page to start the engine within 30 seconds. Figure 6-10 Sample Instruction Screen 3. If the device isn't sure the engine has started after 30 seconds of testing, manually select "STARTED" or "NO STARTED". NT630 Pro User’s Manual_English_V1.03...
  • Page 52 Fully charge the battery and repeat the starter system test. BATTERY Battery must be replaced before the starting system can be REPLACE tested. BATTERY NO START No vehicle start detected. CRANKING A start was not detected. SKIPPED NT630 Pro User’s Manual_English_V1.03...
  • Page 53: Charging Test

    2.Turn on high beams headlights and the blower fan. Figure 6-14 Sample Instruction Screen 3.Rev engine with loads on. 4.Idle engine and turn off loads. 5.The Charging System decision is displayed at the end of the procedure. NT630 Pro User’s Manual_English_V1.03...
  • Page 54 The starter voltage is low and the battery is discharged. CHARGE BATTERY Fully charge the battery and repeat the starter system test. REPLACE BATTERY Battery must be replaced before the starting system can be tested. NT630 Pro User’s Manual_English_V1.03...
  • Page 55: System Test

    Figure 6-17 Sample Result Screen 6.7 Read Voltage Read Voltage menu lets you Read Voltage results. To Read Voltage results: 1.Click the VOLT button at the top of the page and the voltage value will be displayed. NT630 Pro User’s Manual_English_V1.03...
  • Page 56: System Setup

    1. Scroll with the arrow keys to highlight Language from Settings menu and press ENTER key. Figure 7-1 Sample Settings Screen 2. Press left and right arrow key select a language and press the ENTER key to confirm. Press the Back key to exit and return. NT630 Pro User’s Manual_English_V1.03...
  • Page 57: Change Units

    1. Scroll with the arrow keys to highlight Units from Settings menu and press the ENTER key. Figure 7-3 Sample Settings Screen 2. Press the up and down arrow key select an item and press the ENTER key to save and return. NT630 Pro User’s Manual_English_V1.03...
  • Page 58: Configure Shortcut Keys

    1. Scroll with the arrow keys to highlight Shortcuts from Settings menu and press the ENTER key. A screen with available shortcut keys displays. Figure 7-5 Sample Settings screen 2. Press the up and down arrow key select a shortcut key and press the ENTER key. A screen with a list of loaded applications displays. NT630 Pro User’s Manual_English_V1.03...
  • Page 59: Display Test

    To test the display: 1. Scroll with the arrow keys to highlight Display Test from Settings menu and press the ENTER key to start test. Check if there are any missing spots in the LCD screen. NT630 Pro User’s Manual_English_V1.03...
  • Page 60: Keypad Test

    1. Scroll with the arrow keys to highlight Keypad Test from Settings menu and press ENTER key. Figure 7-9 Sample Settings Screen 2. Press any key to start test. The virtue key corresponding with the key you pressed will be highlighted on the screen if it works correctly. NT630 Pro User’s Manual_English_V1.03...
  • Page 61: Tool Information

    To view information of your scan tool: 1. Scroll with the arrow keys to highlight About from Settings menu and press the ENTER key. Figure 7-11 Sample Settings Screen 2. A screen with detailed information of the scanner displays. NT630 Pro User’s Manual_English_V1.03...
  • Page 62 NOTE Before updating, please make sure your network works correctly. Before updating, please make sure you have already created a Foxwell ID. Before updating, please make sure your scanner is turned on. 1.Enter Update and select an avaliable WIFI to connect.
  • Page 63 2.In the Update, click the check box(es) in front of the software(s) you wish to update and then click the Update Select button to download. Figure 8-3 Sample Upgrade Check Screen 3.When all the items are updated, an “All software downloads are successfully installed!” message displays. Figure 8-4 Sample Update Completed Screen NT630 Pro User’s Manual_English_V1.03...
  • Page 64 Figure 9-2 Sample Uninstall Vehicle Software Screen 10 Register The scanner can be updated to keep you stay current with the latest development of diagnosis. This section illustrates how to register and update your scan tool. NT630 Pro User’s Manual_English_V1.03...
  • Page 65: Create A Foxwell Id

    Note: Please always remember your FOXWELL ID and Password, as it’s important for your to manage your product and updates.
  • Page 66 Please always remember your FOXWELL ID and Password as it’s important for you to manager your product and updates. 4. The registration page will be bypassed, skipping to the log in page. Just input your FOXWELL ID and Password to sign in.
  • Page 67: Register By Scanning Qr Code

    Figure 10-7 Sample Password Reset Succeeded Screen 8. If you forget your email or Foxwell ID, just click Sign in at the top right of the website, then click Forgot password, and click Forget Email or Foxwell ID. You are required to input your registered serial number.
  • Page 68: Register Your Scanner

    10.2 Register Your Scanner 10.2.1 Register Product Through Website 1. Open main page on the computer or scan the QR code. and click Sign in. Input your www.foxwelltech.us FOXWELL ID/registered email and password. Figure 10-12 Sample Sign in Screen NT630 Pro User’s Manual_English_V1.03...
  • Page 69: Register Product By Scanning Qr Code

    About page. You can also find the serial number on the back of main unit or Warranty Card. .2.2 Register Product by Scanning QR Code To register product by scanning QR code: 1. Enter Update and connect WIFI, then scan the QR code to register to sign in and finish Product Registeration. NT630 Pro User’s Manual_English_V1.03...
  • Page 70 Figure 10-15 Sample Foxwell ID Sign in Screen 2. When log in successfully, input correct serial number and click the Submit button to complete product registration. Figure 10-16 Sample Product Registration Screen NT630 Pro User’s Manual_English_V1.03...
