Foxwell BT60 Quick Start Manual

Sign up for an Account
Settings
Hello
Welcome to Battery Analyzer
Please login/register first
Email or Foxwell ID
Language setting
Report sharing
Verification Code
Quick guide
Please enter password.
Clear detection data
Confirm Password
About us
Feedback and suggestions
Login registration
Free registration
Connect to a Battery
1 Clean the battery posts on the top or
side of the battery.
2 Connect the red clamp to the positive
(+) terminal and the black clamp to the
negative (-) terminal.
3 Rock the clamp back and forth to
ensure that the clamp and battery post
are firmly connected.
4 After the clamp is connected correctly,
in order to achieve matching binding
between the device and the APP, it is
necessary to connect Bluetooth on the
APP side.
Pictures illustrated here are for reference only and this Quick Start Guide is subject to change without prior notice.
Enter the Settings module of
BT60-APP and click Please
login/register first.
On the account registration
page, enter an email address as
the user ID, and then click the
Send Code
Send Code. You will receive a
4-digit verification code to the
email address you just entered.
Please enter the verification
code, create a password and
click Free registration.
After registering, please use the
account and password you just
entered to log in to the APP.
Battery Test
1. Create battery information on the APP homepage, fill in the "battery name", select "inside or
outside the car", "battery type", "battery standard", and fill in the rated capacity.
2. Click the navigation "Battery Test" at the bottom of the APP to
enter the history page.
4. View test results as well as battery state of health, test/rated capacity, test voltage, battery state
of charge, and test resistance on the screen.
Test Time Test/Rated CCA
2025-02-12 09:47:35
State of Health
60
%
Battery health status
State of Charge
No.
Test Results Result Description
1 GOOD BATTERY The battery is in good condition.
2 GOOD-RECHARGE The battery is in good condition but low current. Fully charge the
battery and return it to service.
3 CHARGE & RETEST Fully charge the battery and retest. Failure to fully charge the battery
before testing may result in inaccurate results.If you still get
CHARGE & RETEST message after you fully charge the battery,
please replace it.
4 REPLACE BATTERY The battery is almost dead or the connection between the battery
and battery cable is poor. Replace the battery and retest; or
disconnect the battery cables and retest the battery using the
out-of-vehicle test before replacing it.
The battery may be damaged such as broken cell or short circuit.
BAD CELL-REPLACE
5
Replace the battery and retest.
BT60 Battery Analyzer
3. Click "Perform
Battery Test".
Test Results
Share Results
Delete Results
GOOD-RECHARGE
637/1100 12.08V
Test/rated
Test Voltage
Voltage
capacitance
35% 5.62mΩ
Test Resistance
State of charge Resistance
