Growatt INFINITY 2000 PRO User Manual

Growatt INFINITY 2000 PRO User Manual

Portable power station
Hide thumbs

Advertisement

Quick Links

Download this manual
User Guide
Contact us
www.growattportable.com
INFINITY 2000 PRO
Portable Power Station
User Manual
1. Keep it dry and do not place heavy objects on the INFINITY 2000 PRO.
2. Do not dismantle, punch, shake, hit, or burn it.
3. Recycle and place INFINITY 2000 PRO according to local policies.

Advertisement

loading
Need help?

Need help?

Do you have a question about the INFINITY 2000 PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Growatt INFINITY 2000 PRO

Summary of Contents for Growatt INFINITY 2000 PRO

  • Page 1 Portable Power Station User Manual Contact us 1. Keep it dry and do not place heavy objects on the INFINITY 2000 PRO. 2. Do not dismantle, punch, shake, hit, or burn it. www.growattportable.com 3. Recycle and place INFINITY 2000 PRO according to local policies.
  • Page 2 I) AC/Vehicle Charging ....................................9 II) Solar Charging ......................................10 Advanced Features ........................................11 EPS Mode ..........................................11 INFINITY 2000 PRO Expansion Battery ................................. 12 Watt+ Function ........................................12 Cold Startup ........................................... 13 Combine Charging Mode ....................................13 INFINITY 2000 PRO Detachable Trolley............................... 14 APP Configuration .........................................15...
  • Page 3 Users promise to be responsible for their actions and all consequences arising therefrom. Growatt is not responsible for any damage caused by using the product not in accordance with the User Manual.
  • Page 4 3. Make sure the machine is turned off before installing or unplugging any modules of the machine. Do not unplug other modules when the machine power is on, otherwise the power interface may be damaged. 4. Do not use the product in an environment of strong static electricity or magnetic field, where abnormal operation may occur. Otherwise, it may cause the product to malfunction or serious damage.
  • Page 5 II. Storage and Transportation 1. Keep the INFINITY 2000 PRO out of the reach of children and pets. If your child accidentally swallows product parts, seek medical help right away. 2. If it prompts that the battery is too low after use, please charge it before storing it. Otherwise, long-term storage with low power may cause damage to the battery inside the product.
  • Page 6 REACH EU Directive. The Entire EU Declaration of Conformity can be found at www.growattportable.com Shenzhen Growatt Power Technology Co., Ltd confirms that the Growatt Portable Power Station and accessories described in this document are in compliance with the above mentioned.
  • Page 7 PORTS AND BUTTONS 1. DC Power Button/Indicator 10. USB-C Output Port 2. Car Cigarette Lighter Output Port 11. USB Power Button/Indicator 3. DC5521 Output Port 12. AC Power Button/Indicator 4. Anderson Output Port 13. AC Outlet 5. LCD Display 14. TT30 Outlet 6.
  • Page 8 The machine experiences a warning or a fault. LoRa Indicator INFINITY 2000 PRO has enabled the RF function, reserved for future function development. DC 5521 & Car Cigarette When the DC 5521 port or Car Cigarette Lighter port is loaded, the icon lights up, and an alarm Lighter Indicator message appears if it is overloaded.
  • Page 9 Anderson Output INFINITY 2000 PRO is supplying power to external devices via the Anderson port. Indicator High Temperature The temperature of INFINITY 2000 PRO is too high. Please place the product in an open area for Warning cooling. Output Frequency Display the frequency of the current AC output port of INFINITY 2000 PRO, which can output two frequencies of 50Hz/60Hz.
  • Page 10 HOW TO USE BASIC INSTRUCTION Before use, please put the INFINITY 2000 PRO on clean and flat ground to ensure that the machine will not be in contact with liquid or tilted, and check whether there are foreign objects on the body.
  • Page 11 If you charge it immediately after discharge, a high temperature warning will be displayed, which is normal. I) AC/VEHICLE CHARGING The INFINITY 2000 PRO charging port is located on the sides of the product. The INFINITY 2000 PRO can be charged via AC power (AC input port) or a car cigarette lighter (XT60 port).
  • Page 12 Six 200W Solar Panels You can use the Solar Charging Cable to connect the Solar Connector on the solar panel and the XT60 port on the right side of the INFINITY 2000 PRO to supply power to the INFINITY 2000 PRO. Solar Connector XT60 Port Figure I.
  • Page 13 PRO. When the power grid is cut off, INFINITY 2000 PRO can continue to use battery energy to power electrical appliances and protect your equipment (as shown in the figure below). It should be noted that INFINITY 2000 PRO has an automatic AC turn-on function, that is, after a power outage, it supplies power through the EPS function until INFINITY 2000 PRO is exhausted.
  • Page 14 INFINITY 2000 PRO EXPANSION BATTERY Users can connect up to one master unit and two INFINITY 2000 PRO Expansion Batteries to enable users to obtain more energy and meet users' needs for longer running times. It should be noted that this product can only be used with INFINITY 2000 PRO EXPANSION BATTERY.
  • Page 15 3. AC+PV （1）When INFINITY 2000 PRO performs AC and solar charging at the same time, the maximum input power can reach 2300W, （2） When the EXPANSION BATTERY is connected AC and solar charging are performed at the same time, and the expansion battery does not use the independent charging function, the maximum input power of INFINITY 2000 PRO entire system can reach 3000W, *The maximum power of AC input is 1800W, and the maximum power of solar input is 1200W.
  • Page 16 INFINITY 2000 PRO DETACHABLE TROLLEY The INFINITY 2000 PRO can be used with a trolley to meet users' needs for easy transportation of the portable power station. (See the trolley manual for details) - 14 -...
  • Page 17 Bluetooth range of the device. 1. Download the "myGro" APP from the APP Store or Google Play. You can also download it from the Growatt official website (first-time use requires you to complete account registration on the APP according to the instructions).
  • Page 18 (II) Re-pair the Product with a New Mobile Device If the device is already tethered to a mobile device, you will need to unpair the product from the current device and then re-pair it to the new mobile device. After repairing, you can use your new mobile device to remotely control your product and unpair it from your existing device.
  • Page 19 TECHNICAL SPECIFICATIONS Basic Information Net Weight ≈51 lbs (≈23 kg) Dimensions (L*W*H) 457*247*310mm（17.99*9.72*12.20in.） Wi-Fi Supported Bluetooth Supported Input AC Input 100-120V~, 50/60Hz, 15A,1800W MAX Vehicle Input 12-24V⎓, 8A MAX Solar Input 12-60V⎓, 1200W MAX Output AC Outlet（x4）+ TT30（x1） 120V~, 50/60Hz, 2400W MAX, TOTAL 2400W (PEAK 4800W) USB-A Fast Charge（x4）...
  • Page 20 No, you can't. This product is a lithium battery product. According to international air transport regulations, lithium battery products exceeding 100Wh cannot be carried on the plane. Why does the INFINITY 2000 PRO not work properly when the total output power of the device is within the rated power of the INFINITY 2000 PRO? First, please check whether the battery capacity of the product is too low and charge it sufficiently prior to use.
  • Page 21 Temperature the product will continue to work normally. Product Overload The INFINITY 2000 PRO is overloaded. Unplug part or all of the loads and keep the total output within 2400W to resume normal operation. Inverter Low Please move it to a warmer spot or connect it to AC/PV power before use.
  • Page 22 When used in combination with Growatt's photovoltaic inverters (MIC 600-3300TL-X, NEO 600-1000M-X), the Smart PV Function can be engaged, allowing INFINITY 2000 PRO to utilize excess energy generated by the photovoltaic inverter for charging. INFINITY 2000 PRO can be easily connected to the photovoltaic system without the need for professional installation. With the ShinePhone APP, the user can exercise intelligent control, setting the charging power and execution conditions according to their own needs, enabling INFINITY 2000 PRO to perform intelligent charging and discharging.
