INFINITY 1500
User Manual
V2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INFINITY 1500 and is the answer not in the manual?

Questions and answers

Related Manuals for Growatt INFINITY 1500

Summary of Contents for Growatt INFINITY 1500

  • Page 1 INFINITY 1500 User Manual V2.0...

  • Page 2: Table Of Contents

    CATALOGUE Important Safety Instructions Package Contents Getting to Know the INFINITY 1500 LED Display How to Use How to Recharge Instructions for Advanced Features How to Connect to APP Technical Specification Error Codes Troubleshooting...

  • Page 3: Important Safety Instructions

    The use of unofficial component is strictly prohibited, which may result in a risk of fire, electric shock, or i njury to persons.For replacement, please check the relevant purchase information on the Growatt official website (https : //www. growattportable. com).Growatt is not responsible for product accidents and malfunctions caused by the use of products not officially provided by Growatt.

  • Page 4: Package Contents

    Please dispose of over-discharged batteries that cannot be recharged. Package Contents User Manual and Warranty Card 1×1.5m AC Charging Cable INFINITY 1500 Protable Power Station (according to country/region) MC 4 to XT60 Solar Panel Charging Cable 1.5m Car Charging Cable...

  • Page 5: Getting To Know The Infinity 1500

    Getting to Know the INFINITY 1500 (EU Outlet) LCD Display Product Power AC Output Port (AUS Outlet) DC Power/ AC Power/Indicator Indicator USB-C Port 5521 Output WIFI Reset (UK Outlet) Port Car Output Port USB-A Fast Charge Port USB-A Port...
  • Page 6 Remaining Battery Percentage Display the current remaining battery percentage in real time. Car Output Indicator INFINITY 1500 is supplying power to external devices via the car output port. USB-A Output Indicator INFINITY 1500 is supplying power to external devices via USB-A port(s).

  • Page 7: How To Use

    How to Use Before use, please put INFINITY 1500 on a clean and flat ground to ensure that the machine will not be in contact with liquid or tilted, and check whether there are foreign objects on the body. Product ON/OFF A) To turn on the INFINITY 1500, long press the power button until the screen lights up.

  • Page 8: How To Recharge

    50°F~82°F(10°C-28°C) can greatly extend the battery life. I) AC Charging and Car Charging The AC charging ports for the INFINITY 1500 are located on the right side of the product. Please follow the instructions below to connect and recharge the product.
  • Page 9 The solar charging ports for the INFINITY 1500 are located on the left side of the product. The INFINITY 1500 DC input range is 12V-100V.You must ensure that the input voltage is within the specified range. When the input voltage exceeds 100V, the excessive voltage may cause damage to the product and the INFINITY 1500 will trigger over voltage protection.
  • Page 10 Connect with Growatt Solar Panels You can charge the INFINITY 1 00 by connecting up to two 24V solar panels in series or using one 12V solar panels(two sets in parallel with each set of four panels in series). Connect the MC4 connector on the solar panel to the MC4-XT60 adapter cable, and supply power to the INFINITY 1 00 through the XT60 port on the side of the INFINITY 1 00.
  • Page 11 Please follow the figure below to connect the positive and negative poles. Incorrect connection may result in damage to the product. During the warranty period of product is damaged due to quality problems of the third- party solar panels or improper operation, Growatt is not responsible for free maintenance during the warranty period.

  • Page 12: Instructions For Advanced Features

    Female Male Male Female Instructions for Advanced Features I) UPS(Uninterruptible Power Supply) The INFINITY 1 00 supports UPS (Uninterruptible Power Supply) function. In UPS mode, the AC power comes from the grid, not the battery. When the power grid is cut off, INFINITY 1 00 will automatically switch to battery power supply mode within 20ms, providing high stability power supply for your load.
  • Page 13 UPS only supports the use of electrical appliances below 2000W, and do not use other devices at the same time during use to avoid overload protection. UPS function is only supported when one INFINITY 1500 is running independently, and it is not available when multiple INFINITY 1500 work in series.

  • Page 14: How To Connect To App

    How to Connect to APP I) Pairing the Product with Your Device When the product is connected to the APP for the first time, you need to use Bluetooth pairing for network configuration. Please get as close as possible to the product and make sure the phone is within the Bluetooth coverage of the device.
  • Page 15 Local Bluetooth Control a) Go to the Device page and click Bluetooth Connection. Or select the "+" button at the top right of the page, then select Bluetooth Connection. b) Short press the Wi-Fi Reset button to send Bluetooth & Wi-Fi signals and connect with your mobile devices. c) Follow the instruction on the APP and finish the rest of the setup.
  • Page 16 II) Re-pairing the Product with New Mobile Devices If the device is already bound to a mobile device, you need to un-pair the product from the current device before re-pairing it to the new mobile device. After re-pairing, you can use the new mobile device to remotely control the product.
  • Page 17 III) Using Multiple Mobile Devices to Control the Product If multiple users need to remotely control the product, the master account needs to authorize other MyGro accounts to allow other mobile devices to control the product. 1. Go to Device, select the product from the device list to enter the product details, and then click the to enter the setting page.

  • Page 18: Technical Specification

    1907/2006 concerning the REACH EU Directive. The Entire EU Declaration of Conformity can be found at www.growattportable.com Shenzhen Growatt Power Technology Co., Ltd confirms that the Growatt Portable Power Station and accessories described in this document are in compliance with the above mentioned.

  • Page 19: Faq

    How to clean INFINITY 1500? If the INFINITY 1500 needs to be cleaned, please wipe it with a dry, non-abrasive cloth or use a special cleaner for LCD screens to achieve better cleaning results. Do not let water enter the inside of the product, which may...

  • Page 20: Error Codes

    Please check the output power of your USB devices. Remove your USB device(s) if the output exceeds the maximum output of the USB port(s). Overload The INFINITY 1500 is overloaded. Unplug part or all of the loads and keep the total output Product Overload within 2000W (or 2400 surge) to resume normal operation.

  • Page 21: Troubleshooting

    INFINITY 1500 is not powering my devices Please recharge the INFINITY 1500 with the Please check if the battery is too low. powering provided power cable. Please check if the device's startup power Please choose a model with a higher rated power.
