C. Crane CC WiFi 3 Instruction Manual

Hide thumbs Also See for CC WiFi 3:

Advertisement

Quick Links

Download this manual
INTERNET RADIO
INSTRUCTION
MANUAL
Please read all the instructions completely before use
and save this manual for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CC WiFi 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for C. Crane CC WiFi 3

Summary of Contents for C. Crane CC WiFi 3

  • Page 1 INTERNET RADIO INSTRUCTION MANUAL Please read all the instructions completely before use and save this manual for future reference.

  • Page 2: Owners Record/Unpacking

    Owners Record Thank you for purchasing a CC WiFi 3 Internet Radio from C. Crane. We hope the CC WiFi 3 Internet Radio will give you many years of learning, news and entertainment. If you have questions about your radio, please give us a call 1-800-522-8863 or email: customerservice@ccrane.com...

  • Page 3: Safety Instructions

    It is best to avoid high volume levels when using headphones/earbuds, especially for extended periods. To prevent damage to your radio or possible injury to you or others, read these safe ty precautions and instructions entirely before applying power to your radio. CC WiFi 3...
  • Page 4 2. DISCONNECT THE RADIO IN CASE OF MALFUNCTION If you smell or notice smoke, disconnect the AC adapter immediately to avoid burns. Contact C. Crane for inspection and service before any future operation. Only use the AC adapter supplied with the unit and replace it if wires become frayed or exposed.

  • Page 5: Table Of Contents

    About Your Network Name (SSID) ____________________ About Your Wireless Security Key (password) ___________ Having Trouble Connecting to a Wireless Network _______ Error Messages Troubleshooting/FAQ’s _____________________________ Menu Flow Chart _________________________________ Memory Preset Log _______________________________ Terms of Service __________________________________ Accessories _____________________________________ CC WiFi 3...

  • Page 6: Location Of Controls/Features Radio

    3. Equalizer Button or 9. Power Button or Play Previous Sleep Timer 4. Preset Button 10. Speaker 5. Remote Sensor BACK Antenna 11. DC Power Jack 13. Line Out Jack 12. Headphone Jack 14. WiFi Antenna Jack CC WiFi 3...

  • Page 7: Location Of Controls/Features Remote

    Location of Controls – Remote Control CC WiFi 3...
  • Page 8 18. (PLAY/PAUSE) Play/pause song/track or play/stop stations. 19. (PLAY NEXT) Plays next station or song/track. 20. (SETTINGS) Enters settings menus for various functions. 21. (INFO) Enters network and system information menu. 22. (DIMMER) Enters display bright menu. CC WiFi 3...

  • Page 9: First Time Setup

    Notice that the letter “a” is highlighted in center of the display. Rotate the dial and you will see that the highlighted character is always in the center. To enter the password for the network that you have selected follow these steps: CC WiFi 3...

  • Page 10: Using The Back And Home Buttons

    1. From the Primary Menu, turn the dial until the triangle shaped cursor is in front of “Internet Radio Stations”, then press and release DIAL/SELECT. 2. Next, turn the dial to choose a radio station from either the “Most Popular (U.S.)”, “By Genre” or “By Location” menu. CC WiFi 3...
  • Page 11 NOTE: The “Most Popular (U.S.)” menu lets you choose from the top 40 USA based radio stations that are most popular with CC WiFi 3 Radio users. This list will evolve and change over time as more users acquire the radio. The “By Location”...

  • Page 12: Changing The Volume

    You cannot change the volume when you are in a menu, except when using the remote control. After a station is selected and begins to play, you can then change the volume by turning the dial. CC WiFi 3...

  • Page 13: Ways To Store A Radio Station As A Preset

    4. Advanced users can enter their own custom URL to the radio presets page with a computer or other device such as a tablet or smartphone. See page 15 for more details. CC WiFi 3...

  • Page 14: Ways To Play A Stored Radio Station Preset

    SELECT button to play it. 4. Advanced users can play radio presets using a computer or other device such as a tablet or smartphone. See Page 15 for more details. CC WiFi 3...

  • Page 15: Radio Preset Page (Optional For Advanced Users)

    The computer or device must be connected to the same WiFi network as the CC WiFi 3 radio. To Access the Radio Preset Page: 1. Open a web browser such as Chrome...
  • Page 16 3. If the page result gives you a link to play the station, then try right-clicking on the link, then select “Inspect”. 4. The highlighted result in the code may contain the Stream URL that you are looking for. Write down the portion of the CC WiFi 3...
  • Page 17 Radio Preset Page via a computer, tablet, or smartphone. This is a good feature to remember and will hopefully give peace of mind knowing that the CC WiFi Radio 3 is not fully dependent on the success of the Skytune radio service. CC WiFi 3...

  • Page 18: Using Bluetooth ® Functionality

    B. Bluetooth is usually accessible from “Settings” “Connections” if using an Android device. 4. After enabling Bluetooth, look for “CC WiFi 3-***” in the listed devices and select it. 5. Your smartphone or tablet will connect to the CC WiFi 3 and use it as the speaker.

  • Page 19: Setting The Time And Date

    Setting the Time/Date and Alarm/Sleep Timer SETTING THE TIME AND DATE NOTE: The CC WiFi 3 radio is equipped with “Auto Time” detection and will self-adjust the time once it is connected to your WiFi network. It is likely that the time will be correct without any adjustment.

  • Page 20: Setting The Sleep Timer

    120, 150, and 180 minutes. When the cursor is in front on your selection – press and release DIAL/SELECT. A small icon will show on the top of the screen to remind you that the sleep timer is set. CC WiFi 3...

  • Page 21: Settings Menu Options

    Standby Mode. This way it will not power on to a station in the middle of the night to wake you while sleeping. To power on to play a station, you will need to press and release the red power button. CC WiFi 3...

  • Page 22: Display Brightness

    If the buffering time is increased then the station should play longer without problems, but there will be extra time for the station to begin playing. For most high-quality stations longer buffering is not needed. CC WiFi 3...

  • Page 23: Software Update

    You may recognize your network name (SSID). If your router’s manufacturer name or your internet service provider name is displayed, try selecting it. NOTE: Hidden Networks are not supported (see page 30 for possible workaround). CC WiFi 3...

  • Page 24: About Your Wireless Security Key (Password)

    You may need to call the manufacturer of the router or your Internet service provider for more assistance. C. Crane cannot assist you with WiFi network setup. Having Trouble Connecting to a Wireless Network: This problem can be caused by several possible scenarios.

  • Page 25: Error Messages

    Error #2: There has been a glitch with the WiFi chip inside your radio. Unplug your radio for 10 seconds and try again. Contact C. Crane customer support for further assistance. Error #3: After scanning for nearby WiFi networks, no networks are found.
  • Page 26 Wait a few minutes and try again later. This problem should not last long. After a few unsuccessful tries, the radio will offer a backup list of saved stations. Unplug your radio for 10 seconds and try again. CC WiFi 3...
  • Page 27 Wait a few minutes and try again later. This problem should not last long. Unplug your radio for 10 seconds and try again. your radio. Recommend contacting C. Crane customer support for assistance. CC WiFi 3...

  • Page 28: Troubleshooting/Faq's

    Search function. If the station plays, then you can re-assign the station to your preset. D. If the above does not help, please contact C. Crane. Having Trouble Finding a Particular Radio Station: If you are then you can visit to search it.
  • Page 29 No. The radio will only display and connect to WiFi routers that use 2.4Ghz. Will the alarm be audible on the CC WiFi 3 Internet Radio if the volume is turned down or muted? Yes. You can set the Volume Level in the Alarm settings to your desired volume.
  • Page 30 Troubleshooting/FAQ’s Where do I locate the MAC address on the CC WiFi 3 Internet Radio? 1. Press the Home button 2. Select Settings 3. Select Information 4. Select Network Information 5. Scroll down to Wi-Fi MAC to view the MAC address...
  • Page 31 To do this the computer, laptop, smartphone, iPad or other device needs to be connected to the same WiFi network as the CC WiFi 3 Internet Radio. The radio must be powered on and connected to your WiFi network.
  • Page 32 NOTE: To locate the radios IP address, press and release the HOME button. Select Settings. Select Information. Select Network Information. Turn the dial to locate where it starts with IP. This is your radios IP address. It will look similar to 192.168.00.0. CC WiFi 3...
  • Page 33 Press and release the Dial/Select on the radio or the OK on the remote control to select one of the options. Once you select the option to delete, it cannot be undone. For more expanded FAQ’s, please visit our website at ccrane.com. CC WiFi 3...

  • Page 34: Menu Flow Chart

    Name To Search ALARM ALARM 1 ALARM 2 TURN ON TURN OFF Time: Sound Repeat: Alarm 12:00 am Tone Everyday Volume: 80% (Set Alarm Everyday (Set Alarm Tone/Radio Time) Once Volume) Monday Tuesday Wednesday Thursday Friday Saturday Sunday CC WiFi 3...
  • Page 35 Heavy Metal - Disco - Live - Soft - Hall - Advanced Buffer Time Connection: Wireless Network Information SSID: Medianet_192 Signal: -57 DBM Information System Information IP: 192.168.10.1 NM: 255.255.255.0 Software Update DNS: 192.168.10.1 30:AE:FF:PF:D7:C4 Reset to Default CC WiFi 3...

  • Page 36: Earphone Jack

    8 ohms 3W STATION AGGREGATOR Skytune based © CONNECTION WiFi: • 802.11b • 802.11g • 802.11n BlueTooth ® Audio (receiver) SECURITY WEP, WPA & WPA2 DISPLAY LINES EARPHONE JACK 1/8” (3.5mm) Stereo LINE OUT JACK 1/8” (3.5mm) Stereo CC WiFi 3...
  • Page 37 12/24 Hour modes, Auto-set with Internet time or choose zone. DIMENSIONS 6.5” W x 3.9” H x 3.9” D WEIGHT 1 lb. 2.6 oz. WARRANTY 1-Year Limited Warranty INCLUDED ACCESSORIES AC adapter, remote control, manual, USB to Radio power cord, and warranty card. NOTE: CC WiFi 3...

  • Page 38: Memory Preset Log

    Memory Preset Log Station Host Preset Location/Genre CC WiFi 3...

  • Page 39: Terms Of Service

    C. Crane has no control over content or the stream provider and cannot be responsible for Internet radio programs or availability.
  • Page 40 172 Main Street Fortuna, CA 95540-1816 Phone: 1-800-522-8863 | Web: ccrane.com Copyright © 2025 C. Crane. All rights reserved. No part of this booklet may be reproduced, in any form or means whatsoever, without permission in writing from C. Crane. (Ver 6)
