EDC201 / EDC202 / EDC203
Product Manual
51-52-25-155
Revision: 2.0
July 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDC201 and is the answer not in the manual?

Questions and answers

Related Manuals for Honeywell EDC201

Summary of Contents for Honeywell EDC201

  • Page 1 All manuals and user guides at all-guides.com EDC201 / EDC202 / EDC203 Product Manual 51-52-25-155 Revision: 2.0 July 2015...

  • Page 2: Notices And Trademarks

    Copyright 2015 by Honeywell International Inc. Revision: 2.0, July 2015 While this information is presented in good faith and believed to be accurate, Honeywell disclaims the implied warranties of merchantability and fitness for a particular purpose and makes no express warranties except as may be stated in its written agreement with and for its customers.

  • Page 3: About This Document

    About This Document This document provides descriptions and procedures for the Installation, Configuration, Operation, and Troubleshooting of your the EDC 200 Series Controller. Revision History EDC201 / EDC202 / EDC203 Product Manual, Document # 51-52-25-155 Rev 1.0 June 2015 First release Rev 2.0...
  • Page 4 All manuals and user guides at all-guides.com Contacts Contacts World Wide Web The following Honeywell web sites may be of interest to Process Solutions customers. Honeywell Organization WWW Address (URL) Corporate http://www.honeywell.com Honeywell Process Solutions http://honeywellprocess.com Support and Contact Information...
  • Page 5 All manuals and user guides at all-guides.com bol Definitions Symbol D Definition he following t table lists thos se symbols use ed in this docu ument to deno ote certain con nditions. ymbol Definition ATTENTION : Identifies info ormation that requires spec cial consideration...
  • Page 6 Protective Ea arth at the sou urce of supply y in accordanc e with nationa al and local ele ectrical code require ements. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 7: Table Of Contents

    Configuration Procedure ................19 Introduction ......................... 19 Procedure ..........................19 Input Set Up Group ..................20 Introduction ......................... 20 Function Prompts ........................ 20 Control Set Up Group ..................23 Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 8 Configuring DI as Keypad Locking Switch DI ............... 68 Configuring DI as Timer Initiating Trigger ................68 Configuring DI as Alarm Acknowledging Switch ..............69 Configuring DI as Auto Tuning Initiating Trigger ..............70 viii EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...
  • Page 9 Start Timer .......................... 85 Resetting Timer ........................86 4.18 Setting Output Value .................. 86 In Auto Mode ........................86 AT is Processing ......................... 86 In Man Mode ........................87 Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 10 Power-up Tests ....................89 Background Tests ..................89 Diagnose System Error ......................89 Confirm System Error ......................90 APPENDIX A LOOK-UP TABLE FOR 7 SEGMENT CHARACTER AND ASSOCIATED ENGLISH WORD............91 EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...
  • Page 11 All manuals and user guides at all-guides.com Contents Tables Tables Table 1-1: EDC201/ EDC202/ EDC203 Operator Interface (all display items shown) ..4 Table 1-2: Function of LED Indicators ................5 Table 1-3: Function of Keys ..................... 5 Table 2-1: Condensed Specifications ................8 Table 2-2: TC/RTD Types and Scope ................
  • Page 12 Figure 2-2: Panel Cutout Requirements ................ 12 Figure 2-3: Composite Wiring Diagram Figure .............. 16 Figure 3-1: Configuration Prompt Hierarchy ..............18 Figure 4-1: Operator Interface (EDC201, EDC202) ............71 Figure 4-2 Operator Interface (EDC203) ............... 72 EDC201 / EDC202 / EDC203 Product Manual Revision 2.0...

  • Page 13: Introduction

    • One control output: Electromechanical relay output or SSR driver output. • Alarm outputs. One alarm output ( EDC201) Two alarm outputs ( EDC201 and EDC203) Display 7-segment display Power Supply • 100-240 VAC 50Hz or 60 Hz (-15% to 10%) •...

  • Page 14: Auto Tuning

    PV an nd the target S Set Point value Display Figure 1-1: : EDC201 O perator Inte erface EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0...

  • Page 15: Figure 1-2: Edc202 Operator Interface

    All manuals and user guides at all-guides.com . Introduction 1.1. Overview Figu re 1-2: EDC2 202 Operato or Interface evision 2.0 DC201 / EDC2 202 / EDC203 3 Product Man uly 2015...

  • Page 16: Table 1-1: Edc201/ Edc202/ Edc203 Operator Interface (All Display Items Shown)

    Point value i s displayed. In configuratio on mode, sele ected paramet er value is dis splayed. Table 1-1 : EDC201/ E EDC202/ EDC C203 Opera ator Interface e (all displa y items sho own) EDC201 / EDC202 / ED...

  • Page 17: Led

    Au uto tuning is en nabled when he light is on. AN(EDC201) ndicates the st tatus of Manu al or Auto con ntrol mode. In Manual contro ol mode when the light i is on.

  • Page 18: Installation

    Make sure a bag containing mounting hardware is included in the carton with the controller. • Check that the model number shown on the product agrees with what you have ordered. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 19: Condensed Specifications

    2. Installation 2.2. Condensed Specifications Condensed Specifications Honeywell recommends that you review and adhere to the operating limits listed in Table 2-1: Condensed Specifications, Table 2-2: TC/RTD Types and Scope, and Table 2-3: Environmental and Operating Conditions when operating your controller.

  • Page 20: Table 2-1: Condensed Specifications

    R Thermocouple 18 to 1704 S Thermocouple -18 to 1704 T Thermocouple High -184 to 371 PT100（Low） -184 to 149 PT100 -184 to 649 Table 2-2: TC/RTD Types and Scope EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 21: Table 2-3: Environmental And Operating Conditions

    Table 2-3: Environmental and Operating Conditions ATTENTION * The maximum moisture rating only applies up to 40 °C (104 °F). For higher temperatures, the RH specification is derated to maintain constant moisture content. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...

  • Page 22: Model Number Interpretation

    SSR Drive, 24 VDC @ 20 mA _ 1 _ Future · · · None _ _ 0 TABLE II Future · · · None Future · · · None Table 2-4: Model Number Interpretation EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 23: Control And Alarm Relay Contact Information

    Adequate access space must be available at the back of the panel for installation and servicing activities. Overall dimensions and panel cutout requirements for mounting the controller are shown in Figure 2-2: Panel Cutout Requirements. Overall Dimensions Figure 2-1: Overall Dimensions Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...

  • Page 24: Panel Cutout Requirements

    All manuals and user guides at all-guides.com 2. Installation 2.5. Mounting Panel Cutout Requirements Figure 2-2: Panel Cutout Requirements EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 25: Mounting Method

    Insert the prongs of the clips into the two holes on the left and right side of case. Tighten screws to secure the mounting kit against the panel. Over tightening will cause mounting kit damage and a loose fit will CAUTION result in improper unit installation. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...

  • Page 26: Wiring

    Use Suppression Devices—For additional noise protection, you may want to add suppression devices at the external source. Appropriate suppression devices are commercially available. ATTENTION For additional noise information, refer to document number 51-52-05-01, How EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 27: Table 2-5: Permissible Wiring Bundling

    Digital input signals • Low voltage alarm relay output wiring • Low voltage wiring to solid state type control circuits • Low voltage wiring to open collector type control circuits Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...

  • Page 28: Wiring Diagrams

    The model number of the controller is on the outside of the case. Wiring the Controller Figure 2-3: Composite Wiring Diagram Figure Callout Details AC Line Voltage Terminals Alarm Terminals Control Input Terminals TC/RTD Input Terminals Reserved Terminals Switching Value Terminals EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 29: Configuration

    These prompts let you know what group of configuration data (Set Up prompts) you are working with and also, the specific parameters (Function prompts) associated with each group. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...

  • Page 30: Configuration Prompt Hierarchy

    All manuals and user guides at all-guides.com 3. Configuration 3.2. Configuration Prompt Hierarchy Configuration Prompt Hierarchy Figure 3-1: Configuration Prompt Hierarchy EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 31: Configuration Procedure

    All manuals and user guides at all-guides.com 3. C Configuration .3. Configurat ion Procedure Configura ation Pro ocedure ntroduction Each o of the Set Up g groups and the eir functions a are pre-config gured at the fac ctory. The fac ctory settings are sho own in Table 3...

  • Page 32: Introduction

    Input high range of TC and RTD input types are generated by -999 ~ 9999 searching the corresponding table automatically depending on the input type. It cannot be modified. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...
  • Page 33 Pre-configured Failsafe output (selected in the CONTROL Set up BURNOUT Group) applied if a failed input is detected (does not apply for an input out of range). Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 34 (Low Range – 10% of range span) No configured Failsafe output applied if failed input NO FS NO FS is detected. This selection provides input failure detection and alarm. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 35: Control Set Up Group

    Time Proportional Output based on PID A has a resolution of TImA Time A 3.33 msec. Cycle Time is adjustable from 1 to 120 seconds. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 36 PV changes. Otherwise controller action is as described for the PID A equation. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...
  • Page 37 1~ 120 output type is RLY, Units: s; if the control out type is SSR driver, Units: 1/3s CONTROL OUTPUT DIRECTION: Select ACTN ACTION direct or reverse output action. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 38 0%. Keeps the high level enabled for set time each time the output Minimun On MIOT is enabled. 1 ~ 6 Time ATTENTION Only applicable for ON/OFF control. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...
  • Page 39 Controller stays in FLMD FAILMODE Latch last mode that was being used NOLA No Latch (Automatic or Manual); output goes to failsafe value. Failsafe output FLSF FAILSAFE 0 ~ 100% value. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 40 Soft Start Timer. Same as PV Soft Start function Set Point Range ends when the PV reaches the Soft Start Set Point or the Timer elapses. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 41: Tune Par Set Up Group

    Setting Definition Top Display Upper Display Lower Display 0.001 ~ 1000 PID gain. Integral coefficient Tune 0 ~ 3200s of PID Para Differential 0 ~ 999s coefficient of PID Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...

  • Page 42: Alarm Set Up Group

    An alarm is an indication that an event that you have configured (for example—Process Variable) has exceeded one or more alarm limits. There is one alarm available for EDC201.There are two alarms available for EDC202 and EDC203. Each alarm has two Set Points. You can configure each of these two Set Points to alarm on various controller parameters.
  • Page 43 POINT VALUE This configuration is AL21 NONE 21TYPE None not available on EDC201. PROCESS VARIABLE. This configuration is not available on EDC201. DEVIATION. This configuration is not available on EDC201. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 44 DIAG Diagnostic configuration is not available on EDC201. HIGH ALARM This SE21 21SEL HIGH configuration is not available on EDC201. LOW ALARM. This configuration is not available on EDC201. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...
  • Page 45 WARNING. This TCWN TCWARN configuration is not available on EDC201. THERMOCOUPLE FAILING. This TCFL TCFAIL configuration is not available on EDC201. FAILSAFE. This FSAFE configuration is not available on EDC201. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 46 ALARM trigger time of an alarm DLYA 0 ~ 30s DELAY to delay for a time period of from 0 to 30 seconds in an alarm condition. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...
  • Page 47 EABL ENABLE Enable the timer. START allows you to select whether the timer starts with the STAT START keyboard (A/M OK key). This configuration is not available on EDC201. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 48 Alarm 2. This configuration is not available on EDC201. PERIOD allows you to configure the length of 0:00min ~ PERI PERIOD the timeout period 9:59hrs (from 0 to 9 hours:59 minutes). EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 49: Auxiliary Set Up Group

    Accutune if the start condition has been met and Accutune is not running. ACCUTUN Disables the Accutune DISB/ TUNE Disable DISABLE function. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...

  • Page 50: Option Set Up Group

    PV exceeds 99.99, then the display will change to a single decimal place so that values of 100.0 and above can be shown. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...
  • Page 51 All manuals and user guides at all-guides.com 3. C Configuration 3.9. OPTION Set Up Group Segment lection Segment Range Set up nction Default Group ompt Value tting Parameter Definition per Display wer Display Top Display 3 decimal plac ces. ATTENTION A Auto-ranging will occur for s selections of...

  • Page 52: Table 3-1: Set Up Parameter Reference

    Setting the operator level PASS OPER Oper password. PASSWO Setting the configuration Config level password. Table 3-1: Set Up Parameter Reference EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 53: Configuring Analog Input

    All manuals and user guides at all-guides.com 3. C Configuration 0. Configuring g Analog Inpu .10 Con nfiguring Analog Input onfiguring T TC Type Inp This se ection describ es the procedu ure of configu uring TC Type e Input, includ ding Input Typ pe, Input Ranges...

  • Page 54: Configuring Rtd Type Input

    The cont troller exits Co onfiguration M Long press and retur rns to the Norm mal Operation without any key operation Mode. more than 3 EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 55: Configuring Analog Input Burnout

    All manuals and user guides at all-guides.com 3. C Configuration 0. Configuring g Analog Inpu onfiguring A Analog Inpu ut Burnout This se ection describ es the procedu ure of configu uring Burnout Mode for An nalog Input. reliminary S Steps •...
  • Page 56 The controlle er exits Config guration Mode e and Long press returns to th e Normal Ope eration Mode. without any ke y operation more than 30s EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 57: Assign Temperature Unit

    All manuals and user guides at all-guides.com 3. C Configuration 0. Configuring g Analog Inpu Config guring Downs cale Burnout Mode Action Press Result Enter S Set Up Mode Top D Display= INP ( (This is the firs st Set Up Long pre Grou p title)

  • Page 58: Configuring Control Algorithm

    The cont troller exits Co onfiguration M Long press and retur rns to the Norm mal Operation without any key operation Mode. more than 3 30s. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 59: Configuring Time Proportion Control

    All manuals and user guides at all-guides.com 3. C Configuration 3.11. Co onfiguring Con ntrol Algorithm onfiguring T Time Propor rtion Contro This se ection describ es the procedu ure of configu uring Time Pro oportion Cont trol. reliminary S Steps •...

  • Page 60: Configuring Three Position Step Control

    The contro oller exits Con nfiguration Mo Long press and return ns to the Norm mal Operation without any Mode operation m ore than 30s. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 61: Configuring Soft Start

    All manuals and user guides at all-guides.com 3. C Configuration 3.11. Co onfiguring Con ntrol Algorithm onfiguring S Soft Start This se ection describ es the procedu ure of configu uring Soft Star rt functon. reliminary S Steps • The co ontroller is in t the Configura ation Mode.

  • Page 62: Configuring Pv Alarm

    Parameter Change the ‘A Alarm Lower Dis splay=intended d Alarm Delay Delay’ Value Value splay= LACH Select the ‘Ala Upper Dis Latch (LACH)’ F Function Parameter EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 63: Configuring Alarm

    All manuals and user guides at all-guides.com 3. C Configuration 3.12. Con figuring Alarm Action Press Result Change e the ‘Alarm wer Display=in ntended Alarm m Latch Latch’ V Value Exit Co onfiguration e controller ex xits Configurat tion Mode Long pr ress d returns to th...
  • Page 64 The cont troller exits Co onfiguration M Long press and retur rns to the Norm mal Operation without any y key operatio Mode. more than 3 30s. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 65: Configuring Output Alarm

    All manuals and user guides at all-guides.com 3. C Configuration 3.12. Con figuring Alarm onfiguring O Output Alarm This se ection describ es the procedu ure of configu uring Output A Alarm. reliminary S Steps • The co ontroller is in t the Configura ation Mode.
  • Page 66 The cont troller exits Co onfiguration M Long press and retur rns to the Norm mal Operation without any k ey operation Mode. more than 30 EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 67: Configuring Manual Mode Alarm

    All manuals and user guides at all-guides.com 3. C Configuration 3.12. Con figuring Alarm onfiguring M Manual Mod de Alarm This se ection describ es the procedu ure of configu uring Manual Mode Alarm. reliminary S Steps • The co ontroller is in t the Configura ation Mode.

  • Page 68: Configuring Pv Rate Of Change Alarm

    The con ntroller exits C Configuration M Mode Long press and retu urns to the No ormal Operatio without any key operation Mode. more than 3 EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 69: Configuring Digital Input Alarm

    All manuals and user guides at all-guides.com 3. C Configuration 3.12. Con figuring Alarm onfiguring D Digital Input t Alarm This se ection describ es the procedu ure of configu uring Digital I Input Alarm. reliminary S Steps • The co ontroller is in t the Configura ation Mode.

  • Page 70: Configuring Tc Warning Alarm

    The co ontroller exits C Configuration Long press Mode a and returns to o the Normal without any key operation Operat tion Mode. more than 3 30s. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 71: Configuring Tc Failing Alarm

    All manuals and user guides at all-guides.com 3. C Configuration 3.12. Con figuring Alarm onfiguring T TC Failing A Alarm This se ection describ es the procedu ure of configu uring TC Fail Alarm. reliminary S Steps • The co ontroller is in t the Configura ation Mode.

  • Page 72: Configuring Failsafe Alarm

    The control ler exits Confi guration Mode Long press and returns to the Norma al Operation M Mode. without any k operation mo re than 30s. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 73: Configuring Diagnostic Alarm

    All manuals and user guides at all-guides.com 3. C Configuration 3.12. Con figuring Alarm onfiguring D Diagnostic A Alarm This se ection describ es the procedu ure of configu uring Diagnos stic Alarm. reliminary S Steps • The co ontroller is in t the Configura ation Mode.

  • Page 74: Assign Alarm Hysteresis

    The control ler exits Confi guration Mode Long press and returns to the Norma al Operation M Mode. without any k operation mo re than 30s. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 75: Configuring Alarm Delay

    All manuals and user guides at all-guides.com 3. C Configuration 3.12. Con figuring Alarm onfiguring A Alarm Delay This se ection describ es the procedu ure of configu uring Alarm D Delay. reliminary S Steps • The co ontroller is in t the Configura ation Mode.

  • Page 76: Configuring Alarm Latching

    ALM Group and ‘Al play= AL11 or AL12 Upper Disp Type’ Functio Parameter play= BLK Select the ‘Ala Upper Disp Blocking (BLK) )’ Function Para ameter EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 77: Configuring Timer

    All manuals and user guides at all-guides.com 3. C Configuration 3.12. Con figuring Alarm Action Press Result Change e the ‘Alarm wer Display=int tended Alarm Blocking Blockin ng’ Value Valu Exit Co onfiguration controller exit ts Configuratio on Mode Long pr ress returns to the e Normal Oper...

  • Page 78: Configuring Digital Input

    The contro oller exits Con nfiguration Mo Long press and return ns to the Norm mal Operation without any k ey operation Mode. more than 30 EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 79: Configuring Di As Control Mode Switch

    All manuals and user guides at all-guides.com 3. C Configuration 13. Configurin ng Digital Input onfiguring D DI as Contro ol Mode Swi itch This se ection describ es the procedu ure of configu uring DI as Co ontrol Mode S Switch.

  • Page 80: Configuring Di As Keypad Locking Switch Di

    The controller r exits Configu uration Mode a ong press returns to the Normal Oper ration Mode thout any key y operation ore than 30s. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 81: Configuring Di As Alarm Acknowledging Switch

    All manuals and user guides at all-guides.com 3. C Configuration 13. Configurin ng Digital Input onfiguring D DI as Alarm Acknowled ging Switch This se ection describ es the procedu ure of configu uring DI as Al larm Acknowl ledging. reliminary S Steps •...

  • Page 82: Configuring Di As Auto Tuning Initiating Trigger

    Config guration Mode e and Long press returns to th e Normal Ope eration Mode. or without an ny key operation m ore than 30s. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 83: Monitoring And Operating The Controller

    All manuals and user guides at all-guides.com 4. Moni itoring a and Ope erating the Co ntroller Overview This se ection gives y ou all the info ormation nece ssary to help y you monitor a and operate yo our controller includi ing an Operat or Interface ov...

  • Page 84: Monitoring Your Controller

    [None], F o or C A visual in ndication of the e temperature e units [None]—N No temperatur e unit annunc ciator F—Degre es Fahrenheit C—Degre ees Celsius EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 85: Viewing The Operating Parameters

    The lockout feature has been enabled to prevent unauthorized changes of certain functions or parameters. EDxx Power on error FCxx Configure and calibration check error ECxx IO control error Table 4-2: Diagnostic Messages Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...

  • Page 86: Controller Mode

    (0 % to 100 % for a time proportioning output or –5 % to 105 % for a current output). EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 87: Setting Operation Level

    All manuals and user guides at all-guides.com Monitoring a and Operating the Controller 4.5. Setting O peration Leve Setting O peration n Level There are two opera ating levels for r parameters, configurator l level and oper rator level.You u can set up or mod dify the operat tion level usin...

  • Page 88: Procedure

    If the pas ssword is corre ect, return to normal o operating mode • If you en ter the wrong password, ret turn to Step 4 EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 89: Setting Parameter Mask

    All manuals and user guides at all-guides.com Monitoring a and Operating the Controller 4.7. Setting Pa arameter Mask Setting Pa arameter r Mask The pa arameter settin ng can be set t to allow acces ss or configura ation by differ rent operating g levels.

  • Page 90: Reseting To Factory Default

    Upper Dis splay=TYPE Select OPT S et Up Top Displa ay= OPT Group splay= HZ Upper Dis splay= STA Select Status( (STA) Upper Dis Function Para ameter EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 91: Setting Power Frequency

    All manuals and user guides at all-guides.com Monitoring a and Operating the Controller 4.10 0. Setting Pow wer Frequency Action Press Result TEST Select Reset to Disp play wer Display= EST) Test (T the LEDs on t the screen are e “on”...

  • Page 92: Setting Decimal Point Location

    Upper Disp lay=TYPE Select OPT Se et Up Top Display y= OPT Group lay= HZ Upper Disp lay= STA Upper Disp Select Status( (STA) Function Para ameter EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 93: Acknowledge Alarms

    All manuals and user guides at all-guides.com Monitoring a and Operating the Controller 4.13. Acknow wledge Alarms Action Press Result er Display= FW Select Firmware Lowe Version n (FIRM) er Display= FW Enter th he Selection Uppe Lowe er Display=Sy ystem Firmwar re Version Acknowle...

  • Page 94: Setting Auto Tuning

    AS STP. If Auto T Tuning is runni ing, lower display y shows up AS STP. Start Auto Tun ning Auto Tuning is started. EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...
  • Page 95 System detects the rising edge of the digital input and sends the command to start the Auto Tuning process. If the prerequisite of Auto Tuning is not met, the lower display will show up Error (ERR) after short pressing, otherwise, the Auto Tuning process is started. Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...

  • Page 96: Stopping Auto Tuning

    Result In the lower d isplay, ower Display= Current SP v value of the sy ystem select the SP value which needs t to be set EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 97: Setting Timer

    All manuals and user guides at all-guides.com Monitoring a and Operating the Controller 4.17. Setting Timer Set SP P value. Lower Dis splay= current t set SP value • Short press to adjust the SP P value; • Long p press to adjust the SP...

  • Page 98: Resetting Timer

    PV or SP v value or Selection Enter the Valu ue or Enters val lue or selectio on made into Selection memory a after another k key is pressed EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 99: In Man Mode

    All manuals and user guides at all-guides.com Monitoring a and Operating the Controller 4.18. Setting g Output Value n Man Mode reliminary S Steps In Nor rmal Operation n Mode, Man LED is on an nd Upper Disp play= current P PV Lower Dis splay= SP.

  • Page 100: Troubleshooting/Service

    Do not return your controller without authorization from Honeywells Technical Assistance Center or until the replacement has been received. Please refer to the Honeywell website: http://www.honeywell.com/ps. EDC201 / EDC202 / EDC203 Product Manual Revision 2.0 July 2015...

  • Page 101: Power-Up Tests

    All manuals and user guides at all-guides.com 5. Troublesho ooting/Service 5.2. Po ower-up Tests Determ mining the fir rmware versi Step Action Press Result Select OPT TION Set Up Upper Displ ay = STA Group Lower Displ ay = FMVN Read the f irmware verio Upper Displ...

  • Page 102: Confirm System Error

    Result FaIl ower Display= Switch the low wer display to show the Fail m message. ower Display= “FaIl” messa age disappears Acknowledge t the Failsafe message EDC201 / EDC202 / ED DC203 Produc ct Manual Revis sion 2.0 ly 2015...

  • Page 103: Appendix A Look-Up Table For 7 Segment Character And Associated English Word

    REVR Reverse DIRT DIRT Direct DEADBAND FLMD FLMD FAILMODE FLSF FLSF FAILSAFE PERI PERI PERIOD RLST RLST RLYSTATE Table 6-2 Examples for 7 Segment Code and Associated English Word Revision 2.0 EDC201 / EDC202 / EDC203 Product Manual July 2015...
  • Page 104 Specifications are subject to change without notice. For more information To learn more about PI New Wave Controllers, visit www.honeywellprocess.com Or contact your Honeywell Account Manager Process Solutions Honeywell 1250 W Sam Houston Pkwy S Houston, TX 77042 Honeywell Control Systems Ltd...
