EMH metering
GmbH & Co. KG
Neu-Galliner Weg 1 • 19258 Gallin
GERMANY
Tel.
+49 38851 326-0
Fax
+49 38851 326-1129
Email info@emh-metering.com
Web
www.emh-metering.com
Tel.
+49 38851 326-1930 (Technical Support)
Email support@emh-metering.com
DMTZ-XC
Digital multi-rate meter
EN
Instructions for use
Scope of delivery ............................................................................................... 2
Important information......................................................................................... 2
Target audience ............................................................................................. 2
Intended use.................................................................................................. 2
Maintenance and warranty instructions ......................................................... 2
Care and disposal information....................................................................... 3
Basic safety instructions ................................................................................ 4
Notes on correctness of measurements........................................................ 4
Technical data.................................................................................................... 5
Housing, display and control elements .............................................................. 6
Name plate .................................................................................................... 7
Displays ......................................................................................................... 8
Installation and start-up ................................................................................... 12
a) Transformer connected meter ................................................................. 14
b) Meter for direct connection at 60 A.......................................................... 16
c) Meter for direct connection at 100 A ........................................................ 17
Terminal cover ............................................................................................. 19
Readout battery (optional) ........................................................................... 19
Installation control register C.86.0 ................................................................... 20
Error register F.F .............................................................................................. 22
Meaning of error flags: ................................................................................ 22
Communication module ................................................................................... 23
Abbreviations ................................................................................................... 24
EU Declaration of Conformity .......................................................................... 27
Issue date: 02 January 2025; subject to technical changes.
DMTZXC-BIA-E-1.53
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EMH metering DMTZ-XC
Summary of Contents for EMH metering DMTZ-XC
-
Page 1: Table Of Contents
EMH metering GmbH & Co. KG Neu-Galliner Weg 1 • 19258 Gallin GERMANY Tel. +49 38851 326-0 +49 38851 326-1129 Email info@emh-metering.com www.emh-metering.com Tel. +49 38851 326-1930 (Technical Support) Email support@emh-metering.com DMTZ-XC Digital multi-rate meter Instructions for use Scope of delivery ....................2 Important information.................. -
Page 2: Scope Of Delivery
Scope of delivery Please check that the contents of the packing box are complete before starting the installation and start-up procedure. y 1 DMTZ-XC device y 1 Instructions for use If the contents are incomplete or damaged, please contact your suppli- er. -
Page 3: Care And Disposal Information
Care and disposal information DANGER Risk of fatal injury in case of contact with live parts! Before the housing of the meter is cleaned, all conductors that the meter is connected to must be de-energised. Use a dry cloth to clean the device housing. Do not use any chemical cleaning agents! The following table names the components and how they are to be treated at the end of their life cycle. -
Page 4: Basic Safety Instructions
If the mains power fails and then returns, there is no need to do anything to the meter. Notes on correctness of measurements For the notes on correctness of measurements applicable to this meter in Germany, please see the enclosed document entitled “Notes on correctness of measurements for LZQJ-XC, DMTZ-XC and XC-RACK”. -
Page 5: Technical Data
Technical data Voltage, current, frequen- See name plate cy, utilisation category Overvoltage category OVC III (as per EN 62052-31) Rated peak withstand voltage 4 kV (as per EN 62052-31) Input S0 input max. 27 V DC, 27 mA (not potential-free) Low voltage 18…40 V DC System voltage... -
Page 6: Housing, Display And Control Elements
Housing, display and control elements 1 - Name plate 2 - No function 3 - LC display 4 - Test LED for active power (permanently on = no energy consump- tion or incorrect current direction, return lock active) 5 - Optical call sensor 6 - Meter cover 7 - Sealing screw 8 - Optical data interface D0... -
Page 7: Name Plate
Name plate 1 - Serial number 2 - Year of construction 3 - No function 4 - Optical call sensor 5 - Test LED for active power 6 - Registered quadrants 7 - Accuracy class 8 - OBIS codes for the most important registers 9 - Product standard 10 - Utilisation category 11 - Overvoltage category... -
Page 8: Displays
Displays a) LC display 1. The operation display shows the energy direction that is currently being measured by the meter (supply/draw of active power, inductive/capacitive reactive power). If a load current is flowing through the meter, the energy direction arrow indicates which quadrant is being used for the measurement, e.g.: 1st quadrant +P/+Q 3rd quadrant –P/–Q... - Page 9 6. The additional cursor field displays the operating states for the meter. The arrows indicate whether any manipulation or an installation error was registered or if the power threshold was exceeded. The cursor is active where any manipulation of the terminal cover, meter cover or any magnetic influence is registered.
- Page 10 b) 4-line display 1. The comment text describes the displayed values in the lists as plain text. 2. The energy direction indicator indicates the direction of the measured energy (+ for obtained energy, - for supplied energy). 3. The value area displays the measured values. 4.
- Page 11 9. The symbol for reading out data appears when the data interface (optical or electrical) is used to communicate with the meter. 10. The symbol for clock controller indicates that the tariff control of the meter is performed via the internal clock. 11.
-
Page 12: Installation And Start-Up
Installation and start-up The meters in series DMTZ-XC are suitable for wall mounting as per DIN 43857-2. When connecting the meter, always observe the corresponding connection diagram, which you will find in the terminal cover of the meter and in your delivery documents. - Page 13 DANGER Risk of fatal injury in case of contact with live parts! S0 inputs are not potential-free. Depending on the voltage version of the device, the S0 inputs are connected electronically internally with the measuring connections or with the auxiliary voltage and are therefore not potential-free.
-
Page 14: A) Transformer Connected Meter
ATTENTION Application of excessive torque will damage the connection terminals! The appropriate torque is dependent on the type of connection line involved and its maximum current. y Tighten the connection terminals to the corresponding torque as per EN 60999-1. a) Transformer connected meter DANGER Risk of fatal injury in case of contact with live parts! y The voltage taps in the meter are not fuse-protected, and are con-... - Page 15 Button for manipulation detection Optical fibre coupling DANGER Risk of fatal injury from high voltage when power transformers disconnected! In transformer connected meters, the high voltage generated on a dis- connected power transformer can cause fatal injuries, and will destroy the power transformer.
-
Page 16: B) Meter For Direct Connection At 60 A
b) Meter for direct connection at 60 A DANGER Improper installation endangers life and health, and can lead to malfunctions and material damage! y Use an overcurrent protection device rated for a maximum of 63 A as per the applicable Technical Connection Rules for Power Instal- lations (e.g. -
Page 17: C) Meter For Direct Connection At 100 A
Button for manipulation Optical fibre coupling detection When the devices are tested, the volt- age circuits are disconnected by a path separator. Remove the path separator again when resuming normal operation! c) Meter for direct connection at 100 A DANGER Improper installation endangers life and health, and can lead to malfunctions and material damage! y Use an overcurrent protection device rated for a maximum of 100 A... - Page 18 Current N terminals N tap Additional Meters up to 100 A terminals 10, 12 terminals 1, 3, 4, 6, 7, 9 Terminal dimensions 9.8 x 11.2 10.0 2.6 x 2.2 W x H or d (mm) Minimum connection 16.0 16.0 cross sections (mm²) Maximum connection 35.0...
-
Page 19: Terminal Cover
Terminal cover To prevent any unauthorised access to the connection terminals, the terminal cover is attached with sealing screws which you can secure with seals. ATTENTION Application of excessive torque will damage the device! y Tighten the sealing screws to a torque of 0.5 Nm. Readout battery (optional) The replaceable readout battery makes it possible to read the display and read out the meter via the optical data interface D0 as long as the... -
Page 20: Installation Control Register C.86.0
Installation control register C.86.0 The installation control register C.86.0 registers installation errors. As a rule it is displayed in on the alternating display or can be called up via the call list. C.86.0 (0 0 0 0 0 0 0 0) Manipulation detection Wrong rotating field Phase failure... - Page 21 Event Value Meaning Manipulation detection Manipulation of the meter cover Manipulation of the terminal cover Manipulation through magnetic fields Manipulation input Wrong rotating field Failure of neutral conductor Wrong rotating field Current imbalance, e.g. 30% Current imbalance, e.g. 18% Phase failure Phase failure L1 Phase failure L2 Phase failure L3...
-
Page 22: Error Register F.f
Error register F.F The meter is equipped with an error register with 32 error flags (8-digit hex number) that is used to record the function errors of the meter. The output of the error register is performed via the display and one of the read-out lists. -
Page 23: Communication Module
F.F(00000600) Error in Set checksum + Error in code checksum F.F(00000700) Error in Par checksum + Error in Set checksum + Error in code checksum F.F(00000800) Error in system checksum F.F(00000900) Error in Par checksum + Error in system checksum F.F(00000A00) Error in Set checksum + Error in system checksum... -
Page 24: Abbreviations
Abbreviations Accuracy class Optical interface as per EN 62056-21 Deutsches Institut für Normung e.V. (German Standardisation Institute) European Norm Utility company Current International Electrotechnical Commission Ingress Protection (protection classification) Infrared L1, L2, L3 External conductor Liquid Crystal Liquid Crystal Display Light emitting diode Neutral conductor OBIS... -
Page 27: Eu Declaration Of Conformity
EU Declaration of Conformity You will find the current EU Declaration of Conformity on the internet site www.emh-metering.com in the “Products & Solu- tions” area in the product description for the meter. As Declarations of Conformity can differ in terms of the ap- plicable standards, we advise you to save the Declaration of Conformity available at the time of delivery.
