EMH metering
GmbH & Co. KG
Neu-Galliner Weg 1 • 19258 Gallin
GERMANY
Tel.
+49 38851 326-0
Fax
+49 38851 326-1129
Email info@emh-metering.com
Web
www.emh-metering.com
Tel.
+49 38851 326-1930 (Technical Support)
Email support@emh-metering.com
LZQJ-XC
Digital 4-quadrant/combi meter
EN
Instructions for use
Scope of delivery and storage / transport .......................................................... 2
Important information......................................................................................... 2
Target audience ............................................................................................. 2
Intended use.................................................................................................. 3
Maintenance and warranty instructions ......................................................... 3
Care and disposal instructions ...................................................................... 3
Basic safety instructions ................................................................................ 4
Notes on correctness of measurements........................................................ 4
Technical data.................................................................................................... 4
Housing, display and control elements .............................................................. 6
Name plate .................................................................................................... 7
LC displays .................................................................................................... 8
Installation and start-up ................................................................................... 12
a) Transformer connected meter ................................................................. 14
b) Meter for direct connection at 60 A.......................................................... 16
c) Meter for direct connection at 100 A ........................................................ 17
Terminal cover ............................................................................................. 19
Readout battery (optional) ........................................................................... 19
Installation control register C.86.0 ................................................................... 20
Error register F.F .............................................................................................. 22
Meaning of error flags ................................................................................. 22
Abbreviations ................................................................................................... 24
EU Declaration of Conformity .......................................................................... 27
Issue date: 05 February 2024; subject to technical changes.
LZQJXC-BIA-E-2.61
Advertisement
Table of Contents
Related Manuals for EMH metering LZQJ-XC
Summary of Contents for EMH metering LZQJ-XC
-
Page 1: Table Of Contents
EMH metering GmbH & Co. KG Neu-Galliner Weg 1 • 19258 Gallin GERMANY Tel. +49 38851 326-0 +49 38851 326-1129 Email info@emh-metering.com www.emh-metering.com Tel. +49 38851 326-1930 (Technical Support) Email support@emh-metering.com LZQJ-XC Digital 4-quadrant/combi meter Instructions for use Scope of delivery and storage / transport ............2 Important information.................. -
Page 2: Scope Of Delivery And Storage / Transport
Scope of delivery and storage / transport Please check the contents of the packing box are complete before starting with the installation and start-up procedure. y 1 LZQJ-XC device y 1 Instructions for use If the contents are incomplete or damaged, please contact your supplier. -
Page 3: Intended Use
Intended use The meter is intended to be used solely for the measurement of elec- trical energy in inside spaces, and it must not be operated outside the specified technical data (see name plate). Make sure that the meter is suitable for the intended application. Maintenance and warranty instructions The device requires zero maintenance. -
Page 4: Basic Safety Instructions
Notes on correctness of measurements For the notes on correctness of measurements applicable to this meter in Germany, please see the document provided, entitled “Messrichtigkeitshinweise für den LZQJ-XC, DMTZ-XC and XC-RACK”. Technical data Voltage, current, See name plate... - Page 5 Accuracy Active energy Cl. A to Cl. 0.2S, depending on the version Reactive energy Cl. 3 to Cl. 0.5S, depending on the version Overvoltage category OVC III (as per EN 62052-31) Rated peak withstand 4 kV (as per EN 62052-31) voltage Measuring voltage inputs 3 x 500V, 3 x 400/690V, 3 x 690V: U...
-
Page 6: Housing, Display And Control Elements
Housing, display and control elements 1 - Name plate 2 - Test LED for reactive power (permanently on = no energy consumption or incorrect current direction, return lock active) 3 - LC display 4 - Test LED for active power (permanently on = no energy consumption or incorrect current direction, return lock active) 5 - Optical call sensor 6 - Meter cover... -
Page 7: Name Plate
Name plate 1 - Serial number 2 - Year of construction 3 - Test LED for reactive power (LZQJ-XC only) 4 - Optical call sensor 5 - Test LED for active power 6 - Registered quadrants 7 - Accuracy class... -
Page 8: Lc Displays
LC displays a) VDEW display 1. The operation display shows the energy direction that is currently being measured by the meter (export/import of active power, inductive/capacitive reactive power). If a load current is flowing, the energy direction arrow indicates which quadrant is being used for the measurement, e.g.: 1st quadrant +P/+Q 3rd quadrant −P/−Q... - Page 9 6. The additional cursor field displays the operating states for the meter. The arrows indicate whether any manipulation or an installation error was registered or if the power threshold was exceeded. The cursor is active if any manipulation of the terminal cover or the meter cover or any magnetic influence is registered.
- Page 10 b) 4-line display 1. The comment text describes the displayed values in the lists as plain text. 2. The energy direction indicator indicates the direction of the measured energy (+ for import, – for export). 3. The value area displays the measurements. 4.
- Page 11 9. The symbol for reading out data appears when the data interface (optical or electrical) is used to communicate with the meter. 10. The symbol for clock controller indicates that the tariff control of the meter is performed via the internal clock. 11.
-
Page 12: Installation And Start-Up
Installation and start-up The meters in series LZQJ-XC are suitable for wall mounting as per DIN 43857-2. When connecting the meter, always observe the corresponding connection diagram, which you will find in the terminal cover of the meter and in your delivery documents. - Page 13 DANGER Risk of fatal injury in case of contact with live parts! During installation or when replacing the meter, the wires connected to the meter must be de-energised. y The installer bears responsibility for coordinating the rated values and parameters of the supply-side overcurrent protection devices with the maximum rated currents of the meter.
-
Page 14: A) Transformer Connected Meter
ATTENTION Application of excessive torque will damage the connection terminals! The appropriate torque is dependent on the type of connection line involved and its maximum current. y Make sure that the screws of the connection terminals are undam- aged and smooth-running before starting the screwing process. y Tighten the connection terminals to the corresponding torque as per EN 60999-1. - Page 15 Terminal block, view from below (left), view from above 1 - Optical fibre coupling 2 - Button for manipulation detection DANGER Risk of fatal injury from high voltage when current transformers disconnected! In transformer connected meters, the high voltage generated on a disconnected current transformer can cause fatal injuries.
-
Page 16: B) Meter For Direct Connection At 60 A
b) Meter for direct connection at 60 A DANGER Improper installation endangers life and health, and can lead to malfunctions and material damage! y Use an overcurrent protection device rated for a maximum of 63 A as per the applicable Technical Connection Rules for Power Instal- lations (e.g. -
Page 17: C) Meter For Direct Connection At 100 A
Terminal block, view from below (left), view from above 1 - Optical fibre coupling 2 - Button for manipulation detection When the devices are tested, the voltage circuits are disconnected by a path separator. Remove the path separator again when resuming normal operation! c) Meter for direct connection at 100 A DANGER Improper installation endangers life and health, and can lead to... - Page 18 Current Additional Meters up to 100 A terminals terminals terminals 1, 3, 4, 6, 7, 9 10, 12 Terminal dimensions 9.8 x 11.2 10.0 2.6 x 2.2 W x H or d (mm) Minimum connection 16.0 16.0 cross sections (mm²) Maximum connection 35.0 35.0...
-
Page 19: Terminal Cover
Terminal cover To prevent any unauthorised access to the connection terminals, the terminal cover is attached with sealing screws which you can secure with seals. ATTENTION Application of excessive torque will damage the device! Tighten the sealing screws to a torque of 0.5 Nm. Readout battery (optional) The replaceable readout battery makes it possible to read the display and read out the meter via the optical data interface D0 even if the... -
Page 20: Installation Control Register C.86.0
Installation control register C.86.0 The installation control register C.86.0 registers installation errors. The register is displayed as standard on the alternating display on the display or output with the call-up list. C.86.0 (0 0 0 0 0 0 0 0) Manipulation detection Wrong rotating field Phase failure... - Page 21 Event Value Meaning Manipulation detection Manipulation of the meter cover Manipulation of the terminal cover Manipulation through magnetic fields Manipulation input Wrong rotating field Failure of neutral conductor Wrong rotating field Current imbalance, e.g. 30% Current imbalance, e.g. 18% Phase failure Phase failure L1 Phase failure L2 Phase failure L3...
-
Page 22: Error Register F.f
Error register F.F The meter has an error register with 32 error flags that are represented by an 8-digit hex number. Every error is assigned to a bit of the hex number. The output of the error register is performed via the display and one of the read-out lists. - Page 23 F.F(00000600) Error in Set checksum + error in code checksum F.F(00000700) Error in Par checksum + error in Set checksum + error in code checksum F.F(00000800) Error in system checksum F.F(00000900) Error in Par checksum + error in system checksum F.F(00000A00) Error in Set checksum + error in system checksum...
-
Page 24: Abbreviations
Abbreviations Accuracy class Optical interface as per EN 62056-21 Deutsches Institut für Normung e.V. (German Standardisation Institute) European Norm Utility company Current International Electrotechnical Commission Ingress Protection (protection classification) Infrared L1, L2, L3 External conductor Liquid Crystal Liquid Crystal Display Light Emitting Diode Neutral conductor OBIS... -
Page 27: Eu Declaration Of Conformity
EU Declaration of Conformity You will find the current EU Declaration of Conformity on the in- ternet site www.emh-metering.com in the “Products & Solutions” area in the product description for the meter. As Declarations of Conformity can differ in terms of the ap- plicable standards, we advise you to save the Declaration of Conformity available at the time of delivery.
