Summary of Contents for raya SB-RGB-V3
- Page 1 SB-RGB-V3 BRITE STIX RGB LED WAND WITH REMOTE USER MANUAL...
- Page 2 THANK YOU FOR CHOOSING RAYA The Raya RGB Brite Stix LED wand provides even illumination along its 15-inch length. It’s extremely simple to operate, and it packs up in its own carry bag so it can go anywhere for shooting photos, streaming video, or creating YouTube content.
- Page 3 Keep this unit away from water and any flammable gases or liquids. • Do not attempt to disassemble or repair the equipment—doing so will void the warranty, and Raya will not be responsible for any damage. • Handle the unit with care.
- Page 4 FEATURES • Built-in rechargeable lithium-ion battery • 3000 to 6000 K white-balance settings • CCT, RGB, and Effects operating modes • 15 in. illumination area • Adjustable brightness • 1/4-20 socket for tripod mounting • Remote included...
-
Page 5: Box Contents
BOX CONTENTS • Brite Stix RGB LED Wand • Remote • Wrist strap • USB charging cable • Carry bag • User manual... - Page 6 OVERVIEW Front Back Mode Light 1. LED panel with 5. Power indicator built-in diffuser 6. Power button/ 2. Handle mode selector 3. USB charging port Brightness/ 4. 1/4-20 mounting Adjustment buttons socket...
- Page 7 Front Back Remote 8. On/Off buttons 13. Color temperature 9. Brightness +/− presets buttons 14. Red/Green/Blue 10. CCT+/CCT− buttons buttons 11. RGB+/RGB− buttons 15. Battery lock 12. FX+/FX− buttons 16. Battery tray...
-
Page 8: Charging The Battery
CHARGING THE BATTERY Remove the protective cover from the USB charging port, and connect the Brite Stix to a powered USB port with the included cable. The charging indicator will flash while the battery is charging, and it will remain on when the battery is fully charged. -
Page 9: Mounting The Light
If the indicator blinks once every flash, the battery has less than 25% of its power remaining. It will blink twice for 25%–50%, three times for 50%– 75%, and four times for 75%–100%. MOUNTING THE LIGHT The Brite Stix has a 1/4-20 mounting socket. Screw the light onto the threaded screw of a tripod, light stand, or ball head, until it’s secure. -
Page 10: Operation Modes
• Repeatedly press the power button to select CCT, RGB, or FX mode. • Press and hold the power button to power off. Note: The remote’s On and Off buttons work only when the Brite Stix is powered on. The Brite Stix cannot be powered on or off by the remote. - Page 11 • Press the buttons repeatedly to adjust the color temperature in 100 K increments. • Press and hold the buttons to adjust the brightness. RGB Mode In RGB mode, the Brite Stix glows a constant color. You can select 39 hues from around the 360° color wheel.
- Page 12 Effects (FX) Mode The Brite Stix comes with 12 preloaded selectable effects, described below. • Repeatedly press the power/mode selection button to select FX mode. • Press the buttons to select one of the 12 effects. • Press and hold the buttons to adjust the brightness of select effects.
- Page 13 Paparazzi: Short and long bursts of bright white light at random intervals that simulate flashes from multiple cameras. Red Light Blink: Red light repeating pattern of long and short flashes. Police Car: Repeating pattern of short bursts of red light that simulate flashing police car lights. Fire Truck: Repeating pattern of short bursts of blue light that simulate fire truck emergency...
- Page 14 RGB Fast Loop: Cycles through half-second pulses of alternating red, green, and blue light. Quiet 1 and Quiet 2: Quiet 1 and 2 display complementary colors that are approximately 180° apart on the color wheel. Quiet 1 can be adjusted from red to yellow, and Quiet 2 from green to blue.
-
Page 15: Remote Operation
REMOTE OPERATION ON/OFF Buttons: Once the Brite Stix is powered on via the on-handle power button, press the remote’s OFF button to activate sleep mode. Press ON to resume operation. Brightness +/− Buttons: Press and hold the Brightness +/− buttons to adjust the brightness in CCT, RGB, and select Effects modes. - Page 16 FX+/FX− Buttons: Press the buttons repeatedly to scroll through the 12 effects. Color Temperature Presets: In CCT mode, these buttons will rapidly set the color temperature at 3000, 4400, and 6000 K (warm, neutral, and cool). Once the color temperature is set, press the CCT+ or CCT−...
-
Page 17: Replacing The Battery
REPLACING THE BATTERY The remote is powered by a CR2025 battery. To replace the battery, follow these steps: 1. Press in the battery lock, and slide the CR2025 battery tray out of PUSH the remote. OPEN 2. Remove the old battery, and replace it with a new battery in the correct orientation, indicated by the illustration on the back of the remote. -
Page 18: Specifications
SPECIFICATIONS Light Fixture Color Temperature 3000 to 6000 K Color Accuracy CRI: 97.2 (5750 K), 95.8 (3000 K) Standard TLCI: 99 (5750 K), 98 (3000 K) Light Intensity 431 lx (5750 K), @ 3 ft. 381 lx (3000 K) LED Count Cooling System Passive Dimming... - Page 19 Remote Operation Remote Control Type Wireless Range 23 ft. (7 m) Power AC Input 5 V / 2 A DC Power Source Light: Li-ion battery Remote: CR2025 3 V battery Max Power Consumption 10 W Cable Cable Type USB Standard-A to Type-C ®...
-
Page 20: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY This Raya product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
