SB-RGB
BRITE STIX
RGB LED WAND
WITH REMOTE
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRITE STIX RGB LED and is the answer not in the manual?

Questions and answers

Related Manuals for raya BRITE STIX RGB LED

Summary of Contents for raya BRITE STIX RGB LED

  • Page 1 SB-RGB BRITE STIX RGB LED WAND WITH REMOTE USER MANUAL...
  • Page 2 THANK YOU FOR CHOOSING RAYA The Raya Brite Stix RGB LED wand provides even illumination along its 15-inch length. It’s extremely simple to operate, and it packs up in its own carry bag so it can go anywhere for shooting photos, video streaming, or making YouTube videos.
  • Page 3 Keep this unit away from water and any flammable gases or liquids. • Do not attempt to disassemble or repair the equipment—doing so will void the warranty, and Raya will not be responsible for any damage. • Handle the unit with care.
  • Page 4 FEATURES • Built-in rechargeable lithium-ion battery • 3000 and 5750 K white-balance settings • Six RGB presets • 15 in. illumination area • 11-step adjustable brightness • 1/4-20 socket for tripod mounting • Remote included...

  • Page 5: Box Contents

    BOX CONTENTS • Brite Stix RGB LED Wand • Remote • Wrist strap • Charging cable • Carry bag • User manual...
  • Page 6 OVERVIEW Front Back Mode Light 1. LED panel 6. Charging indicator 2. Built-in diffuser 7. Power button/ 3. Handle mode selector 4. USB charging port 8. Brightness 5. 1/4-20 mounting socket...
  • Page 7 Front Back Remote 9. Power button 12. Battery lock 10. Brightness buttons 13. Battery tray 11. Color selection buttons...

  • Page 8: Charging The Battery

    CHARGING THE BATTERY Connect the Brite Stix to a powered USB port with the included cable. The charging indicator will blink while the battery is charging and will stop blinking when the battery is fully charged. To charge the Brite Stix from an AC outlet, plug the USB cable into a USB power adapter (not included).

  • Page 9: Mounting The Light

    Battery Power Indicator The power indicator blinks every few seconds when the Brite Stix RGB is powered on, and after a color change or brightness adjustment. The indicator blinks to show the percentage or battery power remaining. If the indicator blinks once every cycle, the battery has 25% of its power remaining.
  • Page 10 POWERING ON AND COLOR SELECTION Press and hold the power button to turn the Brite Stix on or off. Press the power button to cycle through the two white-balance settings and six color presets: 3000 K, 5750 K, red, green, blue, yellow-green, purple, and cyan.

  • Page 11: Adjusting Brightness

    ADJUSTING BRIGHTNESS The Brite Stix RGB features 11-step brightness adjustment. Repeatedly press the buttons to adjust the brightness. Each color can have its own brightness setting. When you select a color, the Brite Stix RGB recalls the last brightness setting for that color.

  • Page 12: Remote Operation

    REMOTE OPERATION Power Button: Once the Brite Stix is powered on via the on-handle power button, press the remote’s power button to activate Sleep mode. Press the power button again to resume operation. Brightness Buttons: Press the Brightness buttons to adjust the brightness in 11-step increments. Color Buttons: Press the color buttons for the desired white balance or RGB preset.

  • Page 13: Replacing The Battery

    REPLACING THE BATTERY The remote is powered by a CR2025 battery. To replace the battery, follow these steps: 1. Push in the battery lock and slide the CR2025 battery tray out of PUSH the remote. OPEN 2. Remove the old battery, and replace it with a new battery in the correct orientation, indicated by the illustration on the back of the remote.

  • Page 14: Specifications

    SPECIFICATIONS Light Fixture Color Temperature 3000 / 5750 K Color Accuracy CRI: 95.8 (3000 K), Standard 97.2 (5750 K) TLCI: 98 (3000 K), 99 (5750 K) Light Intensity 381 lx (3000 K), @ 3 ft. 431 lx (5750 K) Cooling System Passive Dimming Yes, 11-step...
  • Page 15 Remote Operation Remote Control Type Wireless Range 23 ft. (7 m) Power AC Input 5 V / 2 A DC Power Source Li-ion battery Max Power Consumption 10 W Cable Cable Type Micro-USB Cable Length 22.25 in. (56.5 cm)

  • Page 16: One-Year Limited Warranty

    ONE-YEAR LIMITED WARRANTY This Raya product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
