- Page 1 OCSB-70 OCTAGONAL COLLAPSIBLE SOFTBOX FOR USE WITH LED BULBS USER MANUAL...
- Page 2 THANK YOU FOR CHOOSING RAYA. The collapsible octagonal softbox provides a translucent fabric that will soften and diffuse the light of ordinary 45-watt LED bulbs or LED bulbs specifically made for photo and video applications. An internal reflector amplifies the light while the nylon fabric and included diffuser create a soft diffuse beam that’s great...
- Page 3 PRECAUTIONS • Please read and follow these instructions, and keep this manual in a safe place. • Keep this unit away from water and any flammable gases or liquids. • Do not stare at the light when it’s powered on. •...
- Page 4 OVERVIEW Locking knob Tilt lock Mounting bracket Power cord and on/off switch...
- Page 5 Showercap diffuser Reflector Locking ring Support rods...
- Page 6 MOUNTING THE SOFTBOX Loosen the locking knob and place the mounting bracket onto the light stand’s 5/8-inch stud. Tighten the locking knob until secure. Loosen the tilt lock, and adjust the softbox to the desired angle. Tighten the tilt lock until secure.
- Page 7 SETTING UP THE SOFTBOX Press the locking ring down over the base until it snaps into place. Screw an LED bulb into the light socket.
- Page 8 ATTACHING THE DIFFUSER Fit the diffuser over the edges of the softbox. Make sure the diffuser’s seams match the softbox’s corners. POWERING THE SOFTBOX Plug the power cord into an available power socket, and press the power switch to the on position.
- Page 9 CLOSING THE SOFTBOX Make sure the light has cooled down sufficiently, and remove the LED bulb from the base. Pull the locking ring up off the base, and fold up the softbox.
-
Page 10: Specifications
SPECIFICATIONS Dimensions 23 × 6 in. (58.4 × 15.2 cm) (H × W) collapsed Diameter 27.6 in. (70 cm) open Base E27 Edison Dimming Cable Length 6.7 ft. (2 m) Mount 5/8 in. (16 mm) receiver Power 110 VAC, 60 Hz Weight 1.3 lb. -
Page 11: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY This RAYA product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
