- Page 1 OC-OSB80 32˝ OCTA SOFTBOX FOR RAYA FLUORESCENT FIXTURE 7...
- Page 2 FEATURES • Perfect for use with the Raya OC-OF7 light socket fixture • For use with spiral fluorescent bulbs, up to 350 watts total • No speed ring required •...
- Page 3 • Make sure that this product is intact and that there are no missing parts before use. • All photos are for illustrative purposes only. Specifications OC-OSB80 Shape Octagonal Heat Rating Up to 350 watts (fluorescent only) Removable front face...
- Page 4 INSTRUCTIONS ASSEMBLING THE SOFTBOX The Raya 32˝ Octa Softbox is directly compatible for use with the Raya Octa Fluorescent 7 Socket Fixture. Before attaching the two items, make sure all lamps are removed from the fixture and that it is not plugged into a power source. Also remove the fixture from any mounted peripheral.
- Page 5 necessary to fit into the Take a flex rod from the pocket. carrying case and insert the black end into one of Attach the next rod on the eight flex rod slots on the opposite side from the light fixture. the first rod.
- Page 6 ASSEMBLY INSTRUCTIONS Install the fluorescent Once secured, take bulbs on the light fixture. the outer diffuser and stretch it over the open Install the inner diffuser mouth of the softbox. baffle in the softbox by Connect the baffle and inserting the baffle’s diffuser’s touch fasteners loops into the softbox’s to secure.
- Page 7 1400 watt output from a tungsten bulb (Caution: do not use this product with a tungsten bulb). With the 5/8˝ light stand mount and locking tilt knob, the Raya Octa Fluorescent Fixture has the ability to be adjusted easily into many positions.
- Page 8 ONE-YEAR LIMITED WARRANTY This RAYA product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
