RAS-I
REFLECTOR
ADAPTER
FOR SPEEDLIGHT
USER MANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAS-I and is the answer not in the manual?

Questions and answers

Related Manuals for raya RAS-I

Summary of Contents for raya RAS-I

  • Page 1 RAS-I REFLECTOR ADAPTER FOR SPEEDLIGHT USER MANUAL...
  • Page 2 INTRODUCTION Use the Raya Reflector Adapter when you need to get your shoe-mount flash off your camera and onto a light stand. Set it up in your home studio, mount a reflector in the Bowens mount, and use with a variety of light modifiers to achieve your desired lighting effect.
  • Page 3 OVERVIEW Bowens mount 8. Distance adjustment knob 2. Release 9. Umbrella mount 3. Riser 10. Stand adapter 4. Height adjustment knob 11. Tilt lock 5. Flash bracket 12. Locking knob 6. Shoe mount Umbrella lock...
  • Page 4 SETTING UP THE FLASH BRACKET Slide the riser into the flash bracket’s riser mount and tighten the height adjustment knob. 2. Fit the stand adapter onto your light stand’s 5/8-inch mount, and tighten until secure. MOUNTING YOUR FLASH ONTO THE BRACKET Loosen the shoe-mount lock if necessary.
  • Page 5 2. Loosen the height adjustment knob, and position the Bowens mount so the flash head is centered in the mount. Tighten the knob until secure. 3. Loosen the distance adjustment knob. Position the flash along the bracket, and then tighten the knob.
  • Page 6 MOUNTING A SOFTBOX TO THE BOWENS MOUNT Insert your softbox’s mounting tabs into the Bowens mount, and rotate the softbox clockwise until it locks into place. 2. To remove the softbox, pull the release and rotate the softbox counterclockwise.
  • Page 7 INSTALLING ACCESSORIES TO THE MOUNTING BRACKET The softbox mounting ring is compatible with many light-modifying accessories, including snoots, grid reflectors, and beauty dishes. Snoot Beauty dish Speed ring Umbrella (Use without the riser)
  • Page 8 ONE-YEAR LIMITED WARRANTY This RAYA product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
