  • Page 1 PA27JCV PA27JCV USER GUIDE USER GUIDE...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Contents ...................... iii Notices ......................iv Safety information ..................vi Care & Cleaning ..................vii Takeback Services ..................viii Product information for EU energy label ..........viii Chapter 1: Product introduction Welcome! ..................1-1 Package contents ................. 1-1 Monitor introduction ..............1-2 1.3.1 Front view ...............

  • Page 4: Notices

    All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default. The monitor and computer are automatically set to sleep after 10 and 30 minutes of user inactivity.

  • Page 5: Canadian Department Of Communications Statement

    Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur le matériel brouiller du Canada. Software Low Blue Light compliance ASUS requests every model to pass SW LBL when “Image/ Blue Light Filter” is set to MAX. Please refer to the following to alleviate eye strains: •...

  • Page 6: Safety Information

    Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury.

  • Page 7: Care & Cleaning

    AEEE yönetmeliğine uygundur Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord.

  • Page 8: Where To Find More Information

    These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials.

  • Page 10: Welcome

    Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual...

  • Page 11: Chapter 1: Product

    Press this button to switch to next active input source (if available). QuickFit Plus button: • Press this button to display the OSD menu when the OSD is off. • Selects the QuickFit Plus function. ASUS PA27JCV Series LCD Monitor Chapter 1: Product introduction...
  • Page 12 Enacts the selected OSD menu items. • Increases/Decreases values or moves your selection up/down/left/ right. • Push the 5-way button down for over 5 seconds to toggle the Key Lock function between on and off. ASUS PA27JCV Series LCD Monitor...

  • Page 13: Back View

    USB 3.2 Gen 1 Type-A: These ports are for connection with USB devices, such as USB keyboard/mouse, USB flash drive, etc. 10. USB 3.2 Gen 1 Type-C: This port is for connection with USB devices, such as USB keyboard/mouse, USB flash drive, etc. ASUS PA27JCV Series LCD Monitor Chapter 1: Product introduction...

  • Page 14: Assembling The Monitor Arm/Base

    Fix the base to the arm by fastening the bundled screw. We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. Base screw size: M6 x 16.2 mm. ASUS PA27JCV Series LCD Monitor...

  • Page 15: Detaching The Arm/Base (For Vesa Wall Mount)

    The VESA wall mount kit (100 x 100 mm) is purchased separately. • Use only with UL/CSA/GS Listed Wall Mount Bracket with minimum weight/load bearing capacity of 5.85 kg (12.9 Ib) (Screw size: M4 x 10 mm). ASUS PA27JCV Series LCD Monitor Chapter 1: Product introduction...

  • Page 16: Chapter 2: Setup

    +/- 90˚ pivot adjustment. You can also adjust the monitor’s height within +/- 130 mm. -5° ~ +23° 0° (Tilt) (Swivel) 130mm (Height adjustment) (Pivot) It is normal that the monitor slightly shakes while you adjust the viewing angle. ASUS PA27JCV Series LCD Monitor...

  • Page 17: Connecting The Cables

    USB Type-A jack. When these cables are connected, you can choose the desired signal from the Signal item in the OSD menu. If you need to replace the power cord or the connection cable(s), please contact ASUS customer service. Chapter 2: Setup...

  • Page 18: Turning On The Monitor

    Turning on the monitor Press the power button . See page 1-2 for the location of the power button. The power indicator lights up in white to show that the monitor is ON. ASUS PA27JCV Series LCD Monitor...

  • Page 19: Osd (On-Screen Display) Menu

    Menu (5-way) button up/down to change the settings of the selected function. To exit and save the OSD menu, press the button or move the Menu (5-way) left repeatedly until the OSD menu disappears. To adjust other functions, repeat steps 1-4. ASUS PA27JCV Series LCD Monitor...

  • Page 20: Osd Function Introduction

    For better HDR performance (to meet DisplayHDR standard), you need to do the following: set Dynamic Dimming to Fast and HDR mode to PQ Clip. • User Mode 1/User Mode 2: Allows you to make color adjustments in the Advanced Setting. ASUS PA27JCV Series LCD Monitor Chapter 2: Setup...
  • Page 21 Fixed Enable Fixed Gamma (2.2, 2,6 Fixed (2.2) (2.2) (2.2) (2.4) (DICOM) (2.4) (2.2) only) Input Enable Enable Enable Enable Enable Enable Enable Enable Enable Range (Auto) (Auto) (Auto) (Auto) (Auto) (Auto) (Auto) (Auto) (Auto) ASUS PA27JCV Series LCD Monitor...

  • Page 22: Chapter 3: General Instructions

    Chapter 3: General instructions Palette Set a desired color setting from this menu. Preset Signal Brightness PA27JCV Native Mode DisplayPort 5120 x 2880_60Hz Brightness Preset Contrast Saturation Palette Color Temp. Image Gamma RGB Tuning PIP/PBP Black Level QuickFit Plus Back Enter Exit •...
  • Page 23 Input Range: To map signal range with whole black to white presented range of display. • Blue Light Filter: Adjust the strength of blue light filter. To activate this function, you need to do the following: disable HDR on your device. ASUS PA27JCV Series LCD Monitor...
  • Page 24 PIP/PBP The PIP/PBP menu allows you to open up another sub-window connected from another video source (when input source is below 60Hz) besides the main-window from your original video source. To activate this function, you need to do the following: turn off MediaSync/ VRR/Dynamic Dimming and disable HDR on your device.
  • Page 25 • Ruler: This pattern presents physical ruler on top and left side. You can press the Menu (5-way) button for longer than 3 seconds to switch the measurements between metric and imperial. ASUS PA27JCV Series LCD Monitor...
  • Page 26 Input In this function, you can select your desired input source. Preset Signal Brightness PA27JCV Native Mode DisplayPort 5120 x 2880_60Hz HDMI Signal DisplayPort USB Type-C Settings Auto Detection Shortcut Back Enter Exit • Auto Detection: automatically detects other active signals when current input signal is inactive.
  • Page 27 Select Deep Level for power off hub during power saving. To activate daisy chaining, you need to do the following: set Power Saving to Normal Level. Note: Input port will be fixed (no auto detection) when DP out cable is plugged. ASUS PA27JCV Series LCD Monitor...
  • Page 28 • OSD Setup: Adjusts the OSD Timeout from 10 to 120 seconds. Enables or disables the DDC/CI function. Adjusts the OSD background from Opaque to Transparent. Enables or disables the Auto Rotation function. To activate Auto Rotation, you need to do the following: turn off PIP/PBP. •...
  • Page 29 NUC connected to it. Switches on or off the NUC connected to also turns on or off the monitor. • Information: Shows the monitor information. • All Reset: “Yes” allows you to restore the default settings. ASUS PA27JCV Series LCD Monitor 3-11...
  • Page 30 Shortcut Defines the functions for Shortcut 1 and 2 buttons. Preset Signal Brightness PA27JCV Native Mode DisplayPort 5120 x 2880_60Hz Shortcut 1 Signal Shortcut 2 Settings Shortcut Back Enter Exit • Shortcut 1/Shortcut 2: Selects a function for Shortcut 1 and 2 buttons.

  • Page 31: Specifications Summary

    612.22 mm x 538.11mm x 215.00 mm (highest) with stand 612.22 mm x 408.11mm x 215.00 mm (lowest) 691mm x 427mm x 138mm (package) Weight (Esti.) 5.91 kg (Net); 4.14 kg (Net, without stand); 8.73 kg (Gross) ASUS PA27JCV Series LCD Monitor 3-13...
  • Page 32 Multi-languages 23 languages (English, French, German, Italian, Spanish, Dutch, Portuguese, Russian, Czech, Croatian, Polish, Romanian, Hungarian, Turkish, Simplified Chinese, Traditional Chinese, Japanese, Korean, Thai, Indonesian, Persian, Ukrainian, Vietnamese) Accessories Quick start guide, warranty card, power cord, HDMI cable (optional), DisplayPort cable (optional), USB C to C cable (optional), color calibration testing report, ProArt welcome card Compliance and Standards...

  • Page 33: Outline Dimensions

    Outline dimensions 538.11 [21.19] 362.89 [14.29] 175.22 [6.90] 335.66 [13.21] 190 [7.48] 12.5[0.49] 130 [5.12] 361.9 [14.25] 382.35 [15.05] 408.11 [16.07] 175.22[6.90] 100[3.94] ASUS PA27JCV Series LCD Monitor 3-15...

  • Page 34: Troubleshooting (Faq)

    Troubleshooting (FAQ) Problem Possible Solution Power LED is not ON • Press the button to check if the monitor is in the ON mode. • Check if the power cord is properly connected to the monitor and the power outlet. •...

  • Page 35: Supported Operating Modes

    30(N) 262.5 (Reduced Blanking) 3840 x 2160 52.375(P) 24(N) 209.5 (Reduced Blanking) 2560 x 2880 177.665(P) 60(N) 483.25 (Reduced Blanking) “P” / “N” stands for “Positive” / “Negative” polarity of incoming H-sync/V-sync (input timing). ASUS PA27JCV Series LCD Monitor 3-17...
  • Page 36 When the monitor is operating in the video mode (ie, not displaying data), the following high definition modes shall be supported in addition to standard definition video. Resolution Vertical Frequency (Hz) 4096 x 2160p 24Hz 25Hz 30Hz 50Hz 60Hz 24Hz 25Hz 30Hz 3840 x 2160p...
