Summary of Contents for Asus ProArt PA27UCGE Series
- Page 1 PA27UCGE PA27UCGE USER GUIDE USER GUIDE The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
- Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
-
Page 3: Table Of Contents
Contents Contents ...................... iii Notices ......................iv Safety information ..................vi Care & Cleaning ..................vii Takeback Services ..................viii Product information for EU energy label ..........viii Chapter 1: Product introduction Welcome! ..................1-1 Package contents ................. 1-1 Monitor introduction ..............1-2 1.3.1 Front view ............... -
Page 4: Notices
All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default. The monitor and computer are automatically set to sleep after 10 and 30 minutes of user inactivity. -
Page 5: Canadian Department Of Communications Statement
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur le matériel brouiller du Canada. Software Low Blue Light compliance ASUS requests every model to pass SW LBL when “Image/ Blue Light Filter” is set to MAX. Please refer to the following to alleviate eye strains: •... -
Page 6: Safety Information
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. -
Page 7: Care & Cleaning
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. -
Page 8: Where To Find More Information
These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials. -
Page 10: Welcome
Welcome! Thank you for purchasing the ASUS® LCD monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual... -
Page 11: Chapter 1: Product
Chapter 1: Product Monitor introduction introduction 1.3.1 Front view Menu (5-way) button: • Press this button to display the OSD menu when the OSD is off. Press this button again to enter the OSD main menu. • Enacts the selected OSD menu items. •... - Page 12 Please avoid placing objects in front of the sensor (between 30cm and 90cm), as it will cause the function of the sensor to fail (misjudging that someone is ahead). 10. Ambient Light Sensor • Configures the ambient brightness and ambient color temperature settings. ASUS PA27UCGE Series LCD Monitor...
-
Page 13: Back View
1.3.2 Back view Kensington lock slot. Power switch: Press the switch to turn on/off power. AC-IN port: This port connects the power cord. HDMI-1 port: This port is for connection with an HDMI compatible device. HDMI-2 port: This port is for connection with an HDMI compatible device. -
Page 14: Quickfit Plus Function
1. Safe Area Facilitates designers and users to organize content and layout on one page and achieve a consistent look and feel. The selections are: Action Safe Title Safe 3 X 3 ASUS PA27UCGE Series LCD Monitor... - Page 15 2. Center Marker Selects the center marker type. The selections are: Type 1 Type 2 Type 3 3. Customization You can decide the frame size by moving the Menu (5-way) button up/down/ left/right. You can press the Menu (5-way) button for longer than 3 seconds to switch the measurements between millimeter and inch.
- Page 16 4. Ruler This pattern presents physical ruler on top and left side. You can press the Menu (5-way) button for longer than 3 seconds to switch the measurements between metric and imperial. ASUS PA27UCGE Series LCD Monitor...
-
Page 17: Color Calibration
1.3.4 Color Calibration Users can do Self-calibration via OSD (please refer page 3-6) or ASUS exclusive ProArt Calibration Software with the color sensor that is embedded on the bottom of the monitor for color calibration to keep long-term color accuracy. -
Page 18: Assembling The Monitor Arm/Base
Press down the arm assembly to snap it into place. Attach the base into the arm, making sure the tab on the arm fits into the groove on the base. Fix the base to the arm by fastening the bundled screw. ASUS PA27UCGE Series LCD Monitor... -
Page 19: Chapter 2: Setup
Base screw size: M6 x 16.5 mm. Chapter 2: Setup... -
Page 20: Detaching The Arm/Base (For Vesa Wall Mount)
The VESA wall mount kit (100 x 100 mm) is purchased separately. • Use only with UL/CSA/GS Listed Wall Mount Bracket with minimum weight/load bearing capacity of 6.3 kg (13.89 Ib) (Screw size: M4 x 10 mm). ASUS PA27UCGE Series LCD Monitor... -
Page 21: Installing The Monitor Hood
Installing the monitor hood Check the monitor hood items as the following: Upper middle hood Rubbers Right hood Left hood Upper right hood Upper left hood The installation method is as follows: 1. Install the left hood, right hood,upper right hood and upper left hood. Swipe the hood to the another one from edge as shown. - Page 22 (Figure 1) (Figure 2) (Figure 3) ASUS PA27UCGE Series LCD Monitor...
-
Page 23: Adjusting The Monitor
Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. •... -
Page 24: Connecting The Cables
When these cables are connected, you can choose the desired signal from the Input item in the OSD menu. If you need to replace the power cord or the connection cable(s), please contact ASUS customer service. ASUS PA27UCGE Series LCD Monitor... -
Page 25: Turning On The Monitor
Turning on the monitor Set the AC switch to ON position (A), and then press the button (B). See page 1-3 for the location of the Power button. The power indicator lights up in white to show that the monitor is ON. Chapter 2: Setup... -
Page 26: Osd (On-Screen Display) Menu
Menu (5-way) button up/down to change the settings of the selected function. To exit and save the OSD menu, press the button or move the Menu (5-way) left repeatedly until the OSD menu disappears. To adjust other functions, repeat steps 1-4. ASUS PA27UCGE Series LCD Monitor... -
Page 27: Osd Function Introduction
Input Brightness PA27UCGE Native DisplayPort 3840x2160_60Hz Native Preset sRGB Adobe RGB Palette BT.2020 DCI-P3 ASUS DisplayWidget Center Image DICOM Rec.709 Calibration HDR_PQ DCI PIP/PBP Back Enter Exit Volume 50 • Native: Best choice for document editing. Energy star® cert done in native mode. - Page 28 Enable Enable Enable Enable Enable Gamma Fixed (Off) Fixed (Off) Fixed (Off) Fixed (Off) Fixed (2.2) Light Sync Enable Enable Enable Enable Enable Uniformity Fixed (Off) Fixed (Off) Fixed (Off) Fixed (Off) Fixed (Off) Compensation ASUS PA27UCGE Series LCD Monitor...
-
Page 29: Color Reset
Palette Set a desired color setting from this menu. Preset Input Brightness PA27UCGE Native DisplayPort 3840x2160_60Hz Brightness Preset Contrast Saturation Palette Color Temp. Image Gamma RGB Tuning Calibration Black Level PIP/PBP Back Enter Exit Volume 50 • Brightness: The adjusting range is from 0 to 400. •... - Page 30 Input Range: To map signal range with whole black to white presented range of display. • Blue Light Filter: Adjust the strength of blue light filter. To activate this function, you need to do the following: disable HDR on your device. ASUS PA27UCGE Series LCD Monitor...
- Page 31 Calibration Perform standalone calibration to ensure color accuracy every working period. To maintain the accuracy of the schedule, ensure that the AC switch is always set to ON position. Preset Input Brightness PA27UCGE Native DisplayPort 3840x2160_60Hz Target Preset Warm up (30 minutes) Manual Execution Palette Auto Execution...
- Page 32 Manual Execution: Manually perform the standalone calibration. Select “Yes” to start. Preset Input Brightness PA27UCGE Native DisplayPort 3840x2160_60Hz Target Preset Warm up (30 minutes) Manual Execution Palette Auto Execution Image Calibration PIP/PBP Back Enter Exit Volume 50 ASUS PA27UCGE Series LCD Monitor...
- Page 33 • Auto Execution: Allow the system to automatically perform standalone calibration for your personalized time setup. Preset Input Brightness PA27UCGE Native DisplayPort 3840x2160_60Hz Target Clock Preset Warm up (30 minutes) Appointment Manual Execution Routine Palette Auto Execution Image Calibration PIP/PBP Back Enter Exit...
- Page 34 DisplayPort 3840x2160_60Hz Target Clock Preset Warm up (30 minutes) Single Appointment Manual Execution Everyday Routine Palette Auto Execution Every 7 days Every 14 days Image Every 28 days Calibration PIP/PBP Back Enter Exit Volume 50 ASUS PA27UCGE Series LCD Monitor...
- Page 35 PIP/PBP The PIP/PBP menu allows you to open up another sub-window connected from another video source (when input source is below 60Hz) besides the main-window from your original video source. To activate this function, you need to do the following: turn off FreeSync Premium Pro/Dynamic Dimming and disable HDR on your device.
- Page 36 Ruler: This pattern presents physical ruler on top and left side. You can press the Menu (5-way) button for longer than 3 seconds to switch the measurements between metric and imperial. • Mirror Mode: Flip the image horizontally. ASUS PA27UCGE Series LCD Monitor 3-11...
- Page 37 Input In this function, you can select your desired input source. Preset Input Brightness PA27UCGE Native DisplayPort 3840x2160_60Hz HDMI-1 QuickFit Plus HDMI-2 DisplayPort Input USB Type-C Auto Detection Settings Shortcut Back Enter Exit Volume 50 • Auto Detection: Automatically detects other active signals when current input signal is inactive.
- Page 38 To activate this function, you need to do the following: turn off PIP/PBP. • Power Saving: Select Normal Level for power on hub during power saving. Select Deep Level for power off hub during power saving. ASUS PA27UCGE Series LCD Monitor 3-13...
- Page 39 • OSD Setup: Adjusts the OSD Timeout from 10 to 120 seconds. Enables or disables the DDC/CI function. Adjusts the OSD background from opaque to Transparent. Enables or disables the Auto Rotation function. To activate OSD Auto Rotation, you need to do the following: turn off PIP/PBP. •...
- Page 40 HDMI port. • Information: Shows the monitor information. • All Reset: “Yes” allows you to restore the default settings. ASUS PA27UCGE Series LCD Monitor 3-15...
- Page 41 Shortcut Defines the functions for Shortcut 1 and 2 buttons. Preset Input Brightness PA32UCE Native DisplayPort 3840x2160_60Hz Shortcut 1 QuickFit Plus Shortcut 2 Input Settings Shortcut Back Enter Exit Volume 50 • Shortcut 1/Shortcut 2: Selects a function for Shortcut 1 and 2 buttons.
-
Page 42: Specifications Summary
Dimension (W x H x D) 612.4 mm x 574.7 mm x 201.8 mm (highest) with stand 612.4 mm x 454.7 mm x 201.8 mm (lowest) 780 mm x 492mm x 140 mm (package) ASUS PA27UCGE Series LCD Monitor 3-17... - Page 43 Weight (Esti.) 6.4 kg (Net); 4.5 kg (Net, without stand); 10.6 kg (Gross) Multi-languages 22 languages (English, French, German, Italian, Spanish, Dutch, Portuguese, Russian, Czech, Croatian, Polish, Romanian, Hungarian, Turkish, Simplified Chinese, Traditional Chinese, Japanese, Korean, Thai, Indonesian, Persian, Ukrainian) Accessories Quick start guide, warranty card, power cord, HDMI cable, DisplayPort cable, USB C to C cable (optional),...
-
Page 44: Outline Dimensions
Outline dimensions ASUS PA27UCGE Series LCD Monitor 3-19... -
Page 45: Troubleshooting (Faq)
Troubleshooting (FAQ) Problem Possible Solution Power LED is not ON • Press the button to check if the monitor is in the ON mode. • Check if the power cord is properly connected to the monitor and the power outlet. •... -
Page 46: Supported Operating Modes
“P” / “N” stands for “Positive” / “Negative” polarity of incoming H-sync/V-sync (input timing). * When HDMI VRR is ON, preset 14 is not supported. ** PIP sub-screen of each input does not preset 13, preset 15 and preset 16. ASUS PA27UCGE Series LCD Monitor 3-21... - Page 47 When the monitor is operating in the video mode (ie, not displaying data), the following high definition modes shall be supported in addition to standard definition video. Resolution Vertical Frequency (Hz) 3840 x 2160p 120Hz 100Hz 60Hz 50Hz 30Hz 25Hz 24Hz 1920 x 1080p 120Hz...
