User Manual
VALUE HDMI KVM Extender IPCOLOR
over IP, 4K60Hz, 120m
14.99.3044
Disclaimer
The product name and brand name may be registered trademark of related
manufactures. ™ and ® may be omitted on the user manual. The pictures in this user
manual are just for reference. We reserve the rights to make changes
without further notice to a product or system described herein to improve reliability,
function or design.
Advertisement
Table of Contents
Related Manuals for Value 14.99.3044
Summary of Contents for Value 14.99.3044
- Page 1 User Manual VALUE HDMI KVM Extender IPCOLOR over IP, 4K60Hz, 120m 14.99.3044 Disclaimer The product name and brand name may be registered trademark of related manufactures. ™ and ® may be omitted on the user manual. The pictures in this user manual are just for reference.
-
Page 2: Important Safety Instructions
Important Safety Instructions: Do not expose this device to rain or place it near water. Any liquid that goes into the device may cause a failure, fire, or electric shock. 2) Never insert anything metallic into the open parts of the appliance. There is a risk of electric shock. -
Page 3: Installation Requirements
Installation Requirements Attribute Description Requirement Signal source PC, DVD, NVR, etc. with HDMI port HDMI cable ≤ 5m device Cable Cat5/5e/6 or above, following standard Cat6/6A/7 ≤ 120m IEEE-568B Display device TV, projector, LED screen, etc. with HDMI HDMI cable ≤ 5m port Network One to many or switch cascading... - Page 4 L/R IN Connect to the audio source device with 3.5mm stereo audio cable RS-232 (GND/RXD/TXD Used for RS-232 passthrough Micro USB port For firmware upgrading USB-A port Connect to the computer with USB cable HDMI input Connect with HDMI source device HDMI output Connect with local HDMI display device ipcolor Tx (RJ45)
-
Page 5: Installation Procedures
Installation Procedures 1. Network cable Follow the standard of IEEE-568B: 1-white and orange 2-orange 3-white and green 4-blue 5-white and blue 6-green 7-white and brown 8-brown 2. Connection Diagrams 2.1. One-to-one connection: 2.2. One-to-many connection (through gigabit switch): 2.3. One-to-many connection (cascade of gigabit switches): Note: It is suggested to use gigabit (1000 Mbps) switches in LAN transmission, and 100Mbps switches should not be mixed with gigabit switches when cascading. -
Page 6: Connection Instructions
TXD line and RXD line. 4.3. Check baud rate If you need to check the baud rate, set the baud rate value of the serial port test tool to the default value of 115200, connect the serial port test tool to the product, and then power on the product. -
Page 7: Technical Parameters
4.4. Set baud rate For example: the baud rate of the product is 9600, and the baud rate of the serial port test tool is 115200. Then, the baud rate of the serial port test tool must be set to 9600, which is consistent with the product, and then input the command you want to set: "Bset:19200". - Page 8 Power Consumption TX ≤ 5.5W RX ≤ 4W Operating Environment Working temperature - 20℃ ~60℃ Storage temperature - 30℃ ~70℃ Humidity 0~90%RH (no condensation） Physical Properties Housing Iron Weight TX: 315g RX: 307g Color Black Dimensions 106.0(L)*103.0(W)*20.6(H)mm ESD protection 1a Contact discharge level 2 (±4KV) 1b Air discharge level 3 (±8KV) Protection Implementation of the standard: IEC61000-4-2...
