VALUE HDMI Point to Point KVM
Extender 4K30Hz, 40m
14.99.3043

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 14.99.3043 and is the answer not in the manual?

Questions and answers

Related Manuals for Value 14.99.3043

Summary of Contents for Value 14.99.3043

  • Page 1 User Guide VALUE HDMI Point to Point KVM Extender 4K30Hz, 40m 14.99.3043...

  • Page 2: Important Safety Instructions

    · Important safety instructions 1. Do not disassemble the equipment to repair it during operation to avoid electric shock. 2. Please turn off the power before installation. Installation under voltage may damage the equipment. 3. Do not expose the devices to rain, moisture or liquids. 4.
  • Page 3 · Interfaces 1.Transmitter (TX) DC5V Connection for a 5V/2A DC power supply HDMI input Connect to HDMI source device Reset button Press the button to restart the device RJ45 output Connection for a CAT6/6A/7 patch cord KVM Display a) Off: the USB port and the computer are not connected b) On : The USB port is connected to the computer, but no KVM data is being transferred c) Flashing: KVM data is being transferred...

  • Page 4: Installation Procedure

    2. Receiver (RX) HDMI output Connecting to an HDMI display device Reset button Press the button to restart the device RJ45 input Connection for a CAT6/6A/7 patch cord KVM Display a) Off: the USB port and the computer are not connected b) On: The USB port is connected to the computer, but no KVM data is being transferred c) Flashing: KVM data is being transferred...
  • Page 5 3. Connection instructions 1) Connect the HDMI port of the source device to the HDMI IN port of the transmitter using an HDMI cable. 2) Connect the CAT6 OUT port of the transmitter to the CAT6 IN port of the receiver using a network cable.
  • Page 6 Entrance and exit 0.7 ~ 1.2Vp-p (TMDS) TMDS signal Entrance and exit 5Vp-p (TTL) DDC signal Transmission 1080p@60Hz 70 meters Cat6/6A/7 distance 4K@30Hz 40 meters Implementation of the standard: IEC61000-4-2 Degree of 1a Contact discharge level 2 (±4KV) protection 1b Air discharge level 3 (±8KV) Working -20 ~ 60 ℃...
