MS150 Series Installation Guide
About This Guide
This guide provides instruction on how to install and configure your MS150 series switch. This guide also provides mounting instructions and limited
troubleshooting procedures. For more switch installation guides, refer to the
Product Overview
Physical Specifications
1Gbe RJ45
mGbe RJ45
1 Gbe SFP
10Gbe SFP+
Dedicated Mgmt Interface
PoE Type
PoE Port Budget
PoE Switch Budget
Stacking Ports
Power Input
Power Load (idle/max)
Operating Temperature
Storage and
Transportation
Temperature
24T-4G
24P-4G
24
24
-
-
4
4
-
-
1
1
-
802.3bt
-
30W
-
370W
2
2
12VDC, 2.5A
54VDC, 2.78A
13.7W/32.4W
22.9W/422.2W
32°F - 113 °F
32°F - 113 °F
0°C - 45°C
0°C - 45°C
-4°F - 158 °F
-4°F - 158 °F
-20°C - 70°C
-20°C - 70°C
switch installation guides section
24T-4X
24P-4X
24
24
-
-
-
-
4
4
1
1
-
802.3bt
-
30W
-
370W
2
2
12VDC, 3.70A
54VDC, 2.78A
13.7W/32.4W
22.9W/422.2W
32°F - 113 °F
32°F - 113 °F
0°C - 45°C
0°C - 45°C
-4°F - 158 °F
-4°F - 158 °F
-20°C - 70°C
-20°C - 70°C
on our documentation website.
48T-4X
48LP-4X
48
48
-
-
-
-
4
4
1
1
-
802.3bt
-
30W
-
370W
2
2
12VDC, 5.56A
54VDC, 5.56A
23.1W/49.8W
36.2W/460.6W
32°F - 113 °F
32°F - 113 °F
0°C - 45°C
0°C - 45°C
-4°F - 158 °F
-4°F - 158 °F
-20°C - 70°C
-20°C - 70°C
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Meraki MS150 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Cisco Meraki MS150 Series

  • Page 1 MS150 Series Installation Guide About This Guide This guide provides instruction on how to install and configure your MS150 series switch. This guide also provides mounting instructions and limited troubleshooting procedures. For more switch installation guides, refer to the switch installation guides section on our documentation website.
  • Page 2 Humidity 5% to 95% 5% to 95% 5% to 95% 5% to 95% 5% to 95% 5% to 95% Integrated 1U Integrated 1U Integrated 1U Integrated 1U Integrated 1U Integrated 1U Mounting Rack Mount Rack Mount Rack Mount Rack Mount Rack Mount Rack Mount 48FP-4X...
  • Page 3 MS150-24T-4G Series front panel MS150-24T-4X Series front panel MS150-24P-4G Series front panel MS150-24P-4X Series front panel MS150-24MP-4X Series front panel MS150-48T-4G Series front panel MS150-48T-4X Series front panel...
  • Page 4 MS150-48LP-4G Series front panel MS150-48LP-4X Series front panel MS150-48FP-4G Series front panel MS150-48FP-4X Series front panel MS150-48MP-4X Series front panel Back Panel MS150 Series back panel Factory Reset Button There is a factory reset button on the front panel. A brief, momentary press deletes the downloaded configuration and reboots the switch, which will then download a new copy of the config.
  • Page 5 Ports and Status Indicators The MS uses LEDs to inform the user of the device's status. Functions are described below, from left to right. For fixed Ethernet ports, the status LED is on the top left or bottom right depending on port orientation. There is also a traffic LED which flashes orange as traffic is sent/received through that port. Function LED Status Meaning...
  • Page 6: Package Contents

    Package contents In addition to the MS switch, the following are provided: Note: The MS150 does not include stacking cables. Stacking cables sold separately. Safety and Warnings These operations are to be taken with respect to all local laws. Please take the following into consideration for safe operation: •...
  • Page 7: Installation Instructions

    Check and Set Firmware To ensure your switch performs optimally immediately following installation, it is recommended that you facilitate a firmware upgrade prior to mounting your switch. 1. Attach your switch to power and a wired Internet connection. 2. The switch will turn on and the power LED will glow solid orange. 3.
  • Page 8 the physical install of the switch. 1. Install the mounting cage nuts in the rack being used for the switch. 2. Attach the switch face plate to the cage nuts on the rack.
  • Page 9 3. Connect power to the power supply unit.
  • Page 11: Basic Troubleshooting

    If you are still experiencing hardware issues, please contact Cisco Meraki support by logging in to dashboard and using the Help option near the top of the page, then opening and email case or calling using the contact information on that page.
  • Page 12 If your Cisco Meraki device fails and the problem cannot be resolved by troubleshooting, contact support to address the issue. Once support determines that the device is in a failed state, they can process an RMA and send out a replacement device free of charge. In most circumstances, the RMA will include a pre-paid shipping label so the faulty equipment can be returned.
