User Manual

v2.0

u11MINI

+1 (888)892-0155

Mon-Fri 7:00AM - 7:00PM (PST)

Need help?

Do you have a question about the U11MINI and is the answer not in the manual?

Questions and answers

Summary of Contents for RUKO U11MINI

Page 1 User Manual v2.0 u11MINI CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST)
Page 2 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) +1 (732) 207-0697...
Page 3 Content 1 Using This Manual 1.1 Legend 1.2 Recommendations 1.3 Download RUKO U11 APP 1.4 Video Tutorials 2 Product Proﬁle 2.1 Introduction 2.2 Feature Highlights 2.3 Preparing the Aircraft 2.4 Aircraft Diagram 2.5 Remote Controller Diagram 3 Aircraft 3.1 3 Types of Flight Speed Mode 3.2 Aircraft Status Indicator...
Page 4 4 Remote Controller 4.1 Remote Controller Proﬁle 4.2 Using the Remote Controller 4.3 Communication Range of remote controller 4.4 Matching the Remote Controller 5 RUKO U11 APP 5.1 Home 5.2 Control Interface 6 FIight 6.1 Flight Environment Requirements 6.2 Pre-Flight Checklist 6.3 Calibration before Flight...
Page 5 Please read the 《User Manual》for more details. 1.3 Download RUKO U11 APP Make sure to use RUKO U11 App during ﬂight. Scan the QR code or Search in the Application store to download "RUKO U11". RUKO U11 app is compatible with Android 6.0 or above, iOS 10.0.2 or above.
Page 6 According to the corresponding aircraft, visit the link or scan the QR code below to locate the model to watch tutorial videos or get more technical support, which how to use the aircraft safely. https://rukotoy.com/support Copyright ©2024 Ruko All Rights Reserved.
Page 7 U 11 M INI User Manual 2.Product Proﬁle 2.1 Introduction U11MINI could hover and ﬂy stably indoors and outdoors, with RTH function. The camera uses an upgraded 5GHz Wi-Fi FPV real-time transmission function, equipped with a 120°FOV lens and a 90°...
Page 8 Mon-Fri 7:00AM - 7:00PM (PST) Screwdriver Screw User Manual for age Quick Guide & Safety Disclaimer v1.0 u11MINI CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) Quick Guide & Safety Disclaimer Copyright ©2024 Ruko All Rights Reserved.
Page 9 Remove the camera cover from the aircraft's camera. Unfold the front arms before unfolding the rear arms. Before powering on the aircraft, ensure that the front and rear arms are extended and the aircraft is placed on the horizontal ground. Copyright ©2024 Ruko All Rights Reserved.
Page 12 3.1 Flight Speed Mode RUKO U11MINI has three types of speed: low speed, medium speed and high speed, which can be adjusted by pressing the speed button to meet your different ﬂight speed experience.
Page 13 Three green lights Drone low battery ﬂashing slowly together Three green lights The drone is returning ﬂash in turn Blue light and three The remote controller green lights ﬂash in turn is charging Copyright ©2024 Ruko All Rights Reserved.
Page 14 U11MI NI User Manual 3.3 Return to Home The U11MINI aircraft has an automatic return-to-home function in GPS mode, making the aircraft return to the take-off point. The Return to Home (RTH) function brings the aircraft back to the last recorded home point.There are three types of RTH: Smart RTH, Low...
Page 15 ﬂy to the left or right to avoid obstacles. During the return home, short press the smart return button on the remote controller or click the return icon （）on the U11MINI interface again to exit the return home. Copyright ©2024 Ruko All Rights Reserved.
Page 16 The drone is not equipped with an obstacle avoidance function. During the ﬂight, please judge the ﬂight situation reasonably, avoid obstacles in time, and set the corresponding ﬂight and return height according to the ﬂight environment. Copyright ©2024 Ruko All Rights Reserved.
Page 17 After hovering, you can continue ﬂying the aircraft at a height of 98 feet 30 meters) and within a radius of 98 feet (30 meters). altitude 65ft radius 65ft Copyright ©2024 Ruko All Rights Reserved.
Page 18 If the signal is recovered during the return home process, you can press the return button to cancel the return, and the remote control can control the aircraft again at this time. Copyright ©2024 Ruko All Rights Reserved.
Page 19 The aircraft automatically ﬂies over the home point, then starts to land, and completes the home return. Note: When out of control, the aircraft cannot avoid obstacles. When the GPS signal is weak, the aircraft cannot return to home automatically Copyright ©2024 Ruko All Rights Reserved.
Page 20 Optical ﬂow vision system in the environment light is too bright, too dark, mirror, solid colour smooth ground, water,poor or ineffective effect in scenes such as reﬂective surfaces and sparsely textured surfaces. Copyright ©2024 Ruko All Rights Reserved.
Page 21 GPS and switch to the indoor attitude mode before take-off. Once GPS is turned off, the drone will not be able to return automatically, and the smart ﬂight feature will not be used. Copyright ©2024 Ruko All Rights Reserved.
Page 22 U11M I NI User Manual 3.5 Intelligent Flight Mode U11MINI has 5 intelligent ﬂight modes to meet the user's shooting needs: Route Rules,GPS Follow, Point of Interest,Ges Quickshot/Ges Record and Image Follow. According to the user's shooting needs, the operation can be completed by one click, which is simple and fast.
Page 23 U 11 M INI User Manual Route Rules Ensure that you have downloaded the RUKO U11 APP on your phone; Connect the phone with the remote control via the data cable and open the APP. After the aircraft takes off, in GPS mode, tap the icon( Mark interested of points (up to 16) which you plan to ﬂy on app...
Page 24 U11MI NI User Manual GPS Follow Ensure that you have downloaded the RUKO U11 APP on your phone; Turn on the smartphone’ s GPS location; connect the phone with the remote control via the data cable and open the APP;...
Page 25 U 11 M INI User Manual Point of Interest Ensure that you have downloaded the RUKO U11 APP on your phone; Turn on the smartphone’ s GPS location; connect the phone with the remote control via the data cable and open the APP;...
Page 26 U11MI NI User Manual Ges Quickshot/Ges Record Ensure that you have downloaded the RUKO U11 APP on your phone; Turn on the smartphone’ s GPS location; connect the phone with the remote control via the data cable and open the APP;...
Page 27 3.6 Propeller The adjacent propellers on the motors of the U11MINI are forward and reverse propellers. The two propellers on the same motor are the same, and the propellers are marked with A and B respectively.
Page 28 Detaching the Propellers Use the screwdriver to detach the propellers from the motors. Please use the propellers provided by Ruko, and do not mix propellers of different types. Please check whether the propeller is installed correctly and tightly before each ﬂight.
Page 29 U 11 M INI User Manual 3.7 Intelligent Flight Battery The U11MINI intelligent ﬂight battery has a capacity of 2200mAh, a rated voltage of 7.6V, and with charge and discharge management functions. This battery uses high-energy and large-capacity batteries to increase the ﬂight time of the aircraft.
Page 30 Otherwise, the poor contact of the battery interface during the operation may cause the battery to short-circuit and burn the aircraft. The battery must be installed or removed with the battery power turned off. Copyright ©2024 Ruko All Rights Reserved.
Page 31 In a low-temperature environment, due to the battery output power limitation, the aircraft's wind resistance and ﬂight performance will be reduced. Please be careful. You need to be extra cautious when ﬂying in low-temperature and high-altitude environments. Copyright ©2024 Ruko All Rights Reserved.
Page 32 In the charging state, the battery power indicator will ﬂash and indicate the current charge level; when the fourth indicator light is always on, it indicates that the charging is complete. After charging is complete, please remove the charger in time. 5V=2A-3A (Not included) Copyright ©2024 Ruko All Rights Reserved.
Page 33 5V/2A or 5V/3A charger. If the aircraft has not been used for a month, the battery must be removed to prevent the battery from being discharged for a long time. Copyright ©2024 Ruko All Rights Reserved.
Page 34 0° -90° Storing Photos and Videos U11MINI is equipped with a micro SD card slot for storage space expansion. 1.Card speed: 10M/s. 2.File format: support FAT32 format. 3.Memory capacity: a memory card with a memory capacity of 64G or less.
Page 35 Please turn off the aircraft correctly, otherwise the camera parameters will not be saved and the video being recorded will be damaged. Ruko is not responsible for any damage caused by the inability to read videos and photos. Copyright ©2024 Ruko All Rights Reserved.
Page 36 U11MI NI User Manual 4 Remote Controller 4.1 Remote Controller Proﬁle U11MINI remote controller uses the 5 GHz frequency band, and the remote controller distance is up to 9842FT (unobstructed and interference-free environment). The folding handle can stably place the mobile phone, and the maximum adjustable width is 6.7 inches.
Page 37 Powering On/Off Turn on the remote control: Press the power button for 3 seconds to turn it on. Turn off the remote control: Press the power button for another 3 seconds to turn it off. Copyright ©2024 Ruko All Rights Reserved.
Page 38 Press and hold 3 seconds to start/stop recording. Gimbal adjustment: Turn the gimbal dial to adjust the Angle. Quick down or up with one click. Gimbal dial Recording/Shooting Gimbal back to the center facing down Copyright ©2024 Ruko All Rights Reserved.
Page 39 Left Joystick Right Joystick Switching to Japanese Hand's Control Stick: 1.Turn on the aircraft. 2. Press and hold the record button to turn on the power of the remote controller. Left Joystick Right Joystick Copyright ©2024 Ruko All Rights Reserved.
Page 41 Install the mobile phone into the remote controller bracket, refer to the aircraft ﬂight direction of the Attitude Indicator in the app, and the attitude Indicator points straight ahead (perpendicular to the coordinates), indicating that the remote controller is facing the aircraft. Copyright ©2024 Ruko All Rights Reserved.
Page 42 When using the remote control handle to grip the mobile device, be sure to press tightly to avoid the mobile device slipping. Keep the battery at around 3.8-3.9V, and recharge it every month or so to keep the battery active. Copyright ©2024 Ruko All Rights Reserved.
Page 43 U 11 M INI User Manual 5 RUKO U11 App 5.1 Home After running RUKO U11 App, enter the homepage. CONTROLS GUIDE FEEDBACK SUPPORT Control Operate the aircraft through the app page buttons to realize the functions of the aircraft.
Page 44 DS : ﬂight speed VS : ascent and descent DS 0.0 VS 0.0 speed 1 . SD card capacity display 2 . Format : Click to format when the memory card is loaded and cannot be recognized or save ﬁles Copyright ©2024 Ruko All Rights Reserved.
Page 45 Flight Height : Set the maximum ﬂight height. Gyroscope Calibration：When the drone is unstable, it can be placed horizontally to re-calibrate. Compass Calibration：Calibrate the compass ﬁrst when ﬂying in a new location or complex environment. Copyright ©2024 Ruko All Rights Reserved.
Page 46 Recording：When recording a video, you can record the sound into the video. Voice prompt：Voice prompts the status of the drone when the APP is opened or closed. Display prompt message： Switch on or off the prompt bar. Copyright ©2024 Ruko All Rights Reserved.
Page 47 Open the map to ﬁnd the position where the aircraft is disconnected from the App. Flight Logs: You can export the ﬂight log data. Drone information display: APP version, Wi-Fi version, ID number. Copyright ©2024 Ruko All Rights Reserved.
Page 48 Allow RUKO U11MINI to get your location. Otherwise, the following functions cannot be realized. Allow RUKO U11MINI to connect to the mobile phone on the local network, otherwise you will not be able to see the aircraft image transmission screen.
Page 49 ﬂying. The ﬂying altitude is limited to 393ft, and the local laws and regulations must be strictly observed during ﬂight. Please be sure to read the U11MINI Disclaimer and Safety Summary, and understand the safety precautions before ﬂying. 6.1 Flight Environment Requirements Do not ﬂy in severe weather such as strong wind, snow, rain,...
Page 50 If you need to replace parts, be sure to use original parts. The use of non-original accessories may cause danger to the safe use of the Aircraft. For details on accessory support, please refer to the accessory support page in the appendix of the user manual. Copyright ©2024 Ruko All Rights Reserved.
Page 51 6.4 Connection&Settings 1. Connect the phone with the remote control via data cable and then set up. 2. Tap the APP, the ﬁrst time to use the interface will pop up the permission setting. Copyright ©2024 Ruko All Rights Reserved.
Page 52 U11M I NI User Manual Please allow the following permissions 1.mobile phone location rights 2.network rights 3.recording rights 4.album access rights IPhone Settings Android phone USB Settings Copyright ©2024 Ruko All Rights Reserved.
Page 53 “Developer options” , you need to change the "Default USB conﬁguration" to "Transferring ﬁles" after opening the developer mode. (The way to open “Developer options” varies depending on the phone model. You can search Google for details.) Copyright ©2024 Ruko All Rights Reserved.
Page 54 2 seconds (as shown in picture 1)or tap “Compass calibration” on the APP calibration interface (as shown in picture 2) to turn off the green light of the drone and enter the calibration step; Turn 3 times Copyright ©2024 Ruko All Rights Reserved.
Page 55 Aircraft (refer to the ﬁrst step of calibrating the compass). When calibrating the Aircraft, please open the arm and keep the aircraft 1 meter above the ground to avoid the inﬂuence of the magnetic ﬁeld of the motor. Copyright ©2024 Ruko All Rights Reserved.
Page 56 When the Aircraft's ﬂight state is tilted and unstable, please land the Aircraft on a level ground for gyroscope/horizontal calibration. When the tilt Angle of the fuselage is greater than 10°, the horizontal correction cannot be performed. Copyright ©2024 Ruko All Rights Reserved.
Page 57 1.6 ft（0.5 meters) will stop, conﬁrm the landing continue to pull down the throttle lever, the drone will land and stop the motor. Please choose the ﬂat surface to landing. Copyright ©2024 Ruko All Rights Reserved.
Page 58 The Aircraft will take off automatically and hover at a distance of 1.5m(4.9ft） from the ground. 7.4V 7.4V 16GB/ 14GB Lens Lens 1.5m(4.9ft) O N/A H N/A H.5 N/A V.5 N/A Copyright ©2024 Ruko All Rights Reserved.
Page 59 ” on the APP, Slide to conﬁrm automatic landing. The vehicle descends to the ground and turns off its motors. 7.4V 7.4V 16GB/ 14GB Lens Lens O N/A H N/A H.5 N/A V.5 N/A Copyright ©2024 Ruko All Rights Reserved.
Page 60 After a successful match, connect the phone to the remote control through the data cable (pay attention to the USB permission setting) Open the RUKO U11 App, and enter the operation interface. GPS signal search is completed, and the drone light is green and Unlock and start the motor.
Page 61 Push the stick as little as possible during the ﬂight to make the Aircraft ﬂy smoothly. Awareness of ﬂight safety is very important for the safety of you, the surrounding people and the environment. Please read the"Safety and Disclaimer Guidelines" carefully. Copyright ©2024 Ruko All Rights Reserved.
Page 62 Up to 3KM (Outdoor and Unobstructed) Battery 3000mAh Li-polymer Charging Time About 4 Hours Operating Time About 3.3 Hours Remote Operating Voltage 3.7V controller Mobile Device Holder 4.7 to 6.7 Smart Phones Operating Temperature 32°to 104°F (0°to 40°C) Copyright ©2024 Ruko All Rights Reserved.
Page 63 The above accessories can be purchased by searching on Amazon and entering Ruko store. Always use original accessories. The use of non-original accessories may pose a risk to the safe use of the aircraft. Copyright ©2024 Ruko All Rights Reserved.
Page 64 1，The battery is not installed properly. Check whether the battery or propeller is The drone suddenly crashed 2，The propeller is not securely abnormal, and re-test after ﬁrm installation. installed and falls off. Copyright ©2024 Ruko All Rights Reserved.
Page 65 APP phone. No image is displayed on the App. Wrong app downloaded Download the correct app (RUKO U11) It takes about 40 seconds for the drone The drone cannot be paired and the remote control to match, and the...
Page 66 We tested all drone before shipping. Therefore, it is inevitable that The product has slight marks shipping there will be slight traces. However, it can be guaranteed that all drone are 100% brand new Copyright ©2024 Ruko All Rights Reserved.
Page 68 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) rukodrone@gmail.com +1 (732) 207-0697...
