- Page 1 for age Safety Disclaimer & User Manual v4.0 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST)
- Page 2 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) rukofunnytoys@gmail.com +86 19129317359...
- Page 3 Safety Disclaimer 1-11 User Manual 12 -45...
- Page 4 U 1 1 P RO Safety Disclaimer 1.Safety Disclaimer The Ruko U11PRO is NOT a toy and is NOT suitable for people under the age of 14. 1.1 Glossary The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: Warning Hints &...
- Page 5 U 1 1PRO Safety Disclaimer Ruko reserves the right to update this Safety Disclaimer & User Manual. Visit www.rukotoy.com periodically for the latest version. Ruko is a trademark of Shenzhen Ruike Innovation Technology Co., Ltd. and its affiliated companies. Names of brands, etc., appearing in this document are trademarks of their respective owner companies.
- Page 6 DO NOT charge the battery for a long time, please remove charging cable in time after fully charged to avoid damage due to overcharge. ① ② ① ② Charging Time <= 2.5 hours Overcharge > 2.5 hours Copyright ©2023 Ruko All Rights Reserved.
- Page 7 U 11 PRO Safety Disclaimer DO NOT use non-RUKO poor quality batteries or chargers. RUKO takes no responsibility for any damage caused by non-RUKO batteries or chargers. Ruko Original Cable Non-Ruko Batteries or Chargers DO NOT charge the battery immediately after the flight as the temperature may be...
- Page 8 DO NOT touch the electrolytes in damaged batteries, it may injure your skin or eyes. Discharge the Intelligent Flight Batteries to 50% or lower during transport. Fully charge the Intelligent Flight Battery before using it for the first time. Copyright ©2023 Ruko All Rights Reserved.
- Page 9 DO NOT fly above or near large crowds. Obstacles Tall Structures Voltage power lines Tree Crowds Do not fly the drone in the bad weather. Lightning Snow Rain Windy Copyright ©2023 Ruko All Rights Reserved.
- Page 10 USA: Only fly in authorized areas. To learn more about drone requirements, visit the Federal Aviation Administration's drone page. https://www.faa.gov/ UK: Only fly in authorized areas. To learn more about drone requirements, visit the Civil Aviation Authority’s drone page. www.caa.co.uk/home/ Copyright ©2023 Ruko All Rights Reserved.
- Page 11 It is important to set an appropriate RTH altitude before each flight. Make sure your phone has permission to access the Wi-Fi "RUKO-U11PRO-******" and connect successfully. RUKO-U11PRO-****** Copyright ©2023 Ruko All Rights Reserved.
- Page 12 Fly Outdoor Pay attention and control the aircraft at all times during flight. DO NOT rely only on the Ruko Fly APP. GPS flight assistance features and APP are meant to assist the pilot, not replace their control of the aircraft.
- Page 13 / Android 5.0 or later. This drone will be compatible with the phones which’s WLAN function supports dual-band Wi-Fi (2.4GHz and 5.8 GHz). For iOS system: Connect the Wi-Fi “RUKO-U11PRO-******” with your phone. For Android system: ①After connecting with the drone’s Wi-Fi “RUKO-U11PRO-******” please wait for about 10-30 seconds.
- Page 14 Question: IS YOUR UAS OR DEVICE EQUIPPED WITH REMOTE IDENTIFICATION (REMOTE ID) CAPABILITIES? Please choose: NO Then enter the serial number--Add Device, last type this number, and paste it on the drone. It's done. Copyright ©2023 Ruko All Rights Reserved.
-
Page 15: Table Of Contents
U 1 1PRO User Manual User Manual 1 Reading Tips 1.1 Legend 1.2 Recommendations 1.3 Download the Ruko Fly App 1.4 Video Tutorials 2 Product Overview 2.1 Introduction 2.2 Feature Highlights 2.3 Intelligent Flight Modes 2.4 Product Diagram 2.5 Transmitter Diagram 3 Aircraft 3.1 Three Gears Speed of the Aircraft... - Page 16 4.4 Paring the Transmitter 5 Ruko Fly App 6 Flight 6.1 Flight Environment Requirements 6.2 Pre-Flight Checklist 6.3 Calibration 6.4 Manual starting/Stopping the Motors 6.5 Automatically Take-off / Landing 6.6 Basic Flight 7 Appendix Copyright ©2023 Ruko All Rights Reserved.
-
Page 17: Reading Tips
flight. Scan the QR code on the right to download the latest version of the app. Ruko Fly App supports Android 6.0 or higher, iOS 10.0.2 or higher, dual-band wifi (2.4GHz) and 5.8GHz phones. 1.4 Video Tutorials Visit the following link to watch the tutorial videos to ensure correct and safe use of the product. -
Page 18: Product Overview
2.3 Intelligent Flight Modes GPS Follow, Route Planning and Fly Around. The aircraft can follows or flies around you with one click in the Ruko Fly app. It also can flies along the path you marked in the app. Unfold the front arms before unfolding the rear arms. -
Page 19: Product Diagram
Safety Disclaimer v4 .0 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) Safety Disclaimer & User Manual * The content of the package is subject to the actual product Copyright ©2023 Ruko All Rights Reserved. -
Page 20: Transmitter Diagram
TF card slot Camera ④ ⑦ 2.5 Transmitter Diagram Phone Holder Photo/Video Adjust Camera Angle GPS Switch One Key to Joystick Adjust 90° Speed Switch Auto Return Power Switch Indicators Charging Port Joystick Storage Copyright ©2023 Ruko All Rights Reserved. - Page 21 Rotate the left wheel to adjust the camera angle from 0° to 90°. Photo/Video Short press once to take a picture and long press to take a video. Joystick Storage Joystick can be removed for storage Charging Port Charging the remote controller Copyright ©2023 Ruko All Rights Reserved.
-
Page 22: Aircraft
3.2 Calibration and Aircraft Status Indicator Aircraft Indicator Light The U11PRO Aircraft has three status indicator, two of them are under the nose landing gear and the rest one is located in the tail of the aircraft, which can indicate the current status of the flight control system. - Page 23 The green light keeps GPS signal is detected. rear light is green. Remote Controller Indicator Lights The remote controller of U11PRO is a bilateral controller with light and sound prompt function. Copyright ©2023 Ruko All Rights Reserved.
- Page 24 The blue light is always The power of the on + 1 white lights flash controller is less 1 Blue light + 1 quickly together and than 1% white lights make a beep sound Copyright ©2023 Ruko All Rights Reserved.
-
Page 25: Return Home
Click the smart RTH button on Transmitter or tap the return home icon on the Ruko Fly App to cancel the progress when the drone is returning. Then the user can re-control the drone. Copyright ©2023 Ruko All Rights Reserved. - Page 26 The remaining power after returning is related to the return distance, wind speed and wind direction. The drone can only complete return to home with low battery when the GPS signal is strong enough. Copyright ©2023 Ruko All Rights Reserved.
-
Page 27: Intelligent Flight Mode
3.4 Intelligent Flight Mode (GPS Follow / Route Planning / Fly Arround) U11PRO has 3 intelligent flight modes: GPS Follow, Route Planning, Fly Arround. According to the user's shooting needs, the operation can be completed by one click, which is easy and fast. - Page 28 U 1 1P RO User Manual GPS Follow Ensure that the Ruko Fly App has been downloaded and installed ① on the smartphone; Turn on the GPS positioning of the smartphone to connect to the ② Aircraft WiFi; After the Aircraft takes off in an open environment with good GPS ③...
- Page 29 U 11 PRO User Manual Make sure you have downloaded Ruko Fly App on your phone; ① Connect your smartphone to the Aircraft’s WiFi; ② After the Aircraft takes off, tap the Route Planning on the app ③ under GPS mode；...
-
Page 30: Propellers
90 degree. ② 3.5 Propellers The propellers on the adjacent motors of U11PRO are forward and reverse propellers. The two blades on the same motor are the same, and the propellers are marked with A and B respectively. The rotation directions of the propellers with the same mark are different. -
Page 31: Intelligent Flight Battery
Ensure that there is no abnormal noise during flight after the aircraft is powered on. 3.6 Intelligent Flight Battery The U11PRO intelligent flight battery has a capacity of 1900mAh, a rated voltage of 7.6 V, and with charge and discharge management functions. This battery uses high-energy and large-capacity batteries to increase the flight time of the Aircraft. - Page 32 Otherwise, the poor contact of the battery interface during the operation may cause the battery to short-circuit and burn the Aircraft. The battery must be installed or removed with the battery power turned off. Copyright ©2023 Ruko All Rights Reserved.
- Page 33 It is recommended to use a 5V/2A or 5V/3A charger. If the Aircraft has not been used for a month, the battery must be ⑦ removed to prevent the battery from being discharged for a long time. Copyright ©2023 Ruko All Rights Reserved.
-
Page 34: Camera Overview 3
Please remove the lens protective film before the camera is using. -90° Storage of Photos and Videos U11PRO is equipped with a micro SD card slot for storage space expansion.( microSD card is not included) Card speed：10M/s; ① File format: support FAT32 format;... -
Page 35: Transmitter
U 1 1PRO User Manual 4 Transmitter 4.1 Transmitter Profile U11PRO Transmitter uses the 2.4 GHz frequency band, and the Transmitter distance is up to 984FT-1640FT (unobstructed and interference-free environment). The foldable handle can stably place the mobile device, and the maximum adjustable width is 3.38 inches. - Page 36 Aircraft left and right tilt. The greater the offset,and right.the greater the tilt angle and the faster the flight speed Copyright ©2023 Ruko All Rights Reserved.
-
Page 37: Communication Range Of Transmitter
Install the mobile phone into the Transmitter bracket, refer to the aircraft flight direction of the Attitude Indicator in the APP, and the Attitude Indicator points straight ahead(perpendicular to the coordinates), indicating that the Transmitter is facing the Aircraft. Remote controller position Aircraft orientation Copyright ©2023 Ruko All Rights Reserved. -
Page 38: Paring The Transmitter
③ Once successfully paired, 4 indicator light flashing change to indicator light is always on and dripping sounds Connect your mobile phone to Aircraft's "RUKO-U11PRO-******", ④ tap the APP to enter the control interface; the mobile phone screen displays information such as the Transmitter's battery signal and camera screen. -
Page 39: Ruko Fly App
Click to enter the orbital flight, you can control the surround distance in Fly Around therange of 5-20 meters through the right joystick front and back, and adjust the surround speed and direction from left to right Camera Angle Adjust camera angle Copyright ©2023 Ruko All Rights Reserved. - Page 40 U 1 1P RO User Manual Instruction Video Guide Watch video of Unboxing, Preflight, First Flight for U11PRO drone APP Guide Read the App Guide to operate more smoothly. Quick Guide & Safety Read the Quick Guide & Safety Disclaimer to fly more easily and safely.
- Page 41 Before using the Ruko Fly App, make sure that the phone has sufficient power. When you use the Ruko Fly App on your mobile phone, please focus on controlling the Aircraft. Do not answer incoming calls, send and receive text messages or use other mobile phone functions during the flight.
-
Page 42: Flight
flying. The flying altitude is limited to 120m, and the local laws and regulations must be strictly observed during flight. Please be sure to read the U11PRO Disclaimer and Safety Summary, and understand the safety precautions before flying. 6.1 Flight Environment Requirements Do NOT fly in severe weather such as strong wind, snow, rain, and... -
Page 43: Pre-Flight Checklist
Connect drone wifi with your phone, make sure that you have connected the WIFI name "RUKO-U11PRO-******" exactly after App access right and Internets permission with your phone. Make sure that the camera lens is clean. - Page 44 WiFi The drone open after 30s, open the WiFi list, and find the ① drone’s wifi. Connect the phone with the drone’s WiFi ("RUKO-U11PRO-******"), ② then click on the APP to enter Control interface. When the Android phone connect drone’s wife, there is a option ③...
- Page 45 When the drone is flying unbalanced, you can push the right joystick to 5 o'clock position on the remote controller for Acc calibration. Or You can find acc calibration in the app interface then click “calibrate”. Copyright ©2023 Ruko All Rights Reserved.
-
Page 46: Manual Starting/Stopping The Motors
When you need to manually land the Aircraft, continue to push the Transmitter throttle lever downwards. Do not release the throttle lever during landing until the Aircraft lands and the motors stop. Please choose a flat ground to land. Avoid causing damage to the drone. Copyright ©2023 Ruko All Rights Reserved. -
Page 47: Automatically Take-Off / Landing
Confirm the safe landing conditions, enter the APP, click the ① One key landing button, confirm to enter the automatic landing, the drone will automatic land. The Aircraft landed on the ground and turned off the motors by ② itself. Copyright ©2023 Ruko All Rights Reserved. -
Page 48: Basic Flight
Turn on the power of transmitter. ③ Connect the mobile phone to Aircraf's WiFi "RUKO-U11PRO-******". ④ Open the Ruko Fly App, and enter the camera interface. After GPS search successfully, the status of rear indicator is ⑤ always green , and the motor is started. - Page 49 Push the stick as little as possible during the flight to make the ④ Aircraft fly smoothly. Awareness of flight safety is very important for the safety of you, the surrounding people and the environment. Please read Safety Disclaimer & User Manual carefully. Copyright ©2023 Ruko All Rights Reserved.
-
Page 50: Appendix
U 1 1P RO User Manual 7 Appendix Specifications U11PRO Phone:3840x2160P SD Card3840x2160P/2560x1440P Phone:1280x720P SDCard:3840x2160P/2560x1440P RukoFlyApp Copyright ©2023 Ruko All Rights Reserved. - Page 51 Ruko's official website https://rukotoy.com/support-drones If you have any questions or suggestions about the User Manual, please contact us via the following email: rukodrone@gmail.com Ruko is a trademark of Shenzhen Ruike Innovation Technology Co.,Ltd Copyright 2023 Ruko All Rights Reserved.
- Page 52 rukotoy.com CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) Rukofunnytoys@gmail.com +86 19129317359...
