- Page 3 Vyoo...
- Page 4 Keenz Vyoo Axle (1)
- Page 7 Step 1: 1. Remove the product from the packaging box. 2. Set aside the wheels and other parts. 3. Adjust the platform to match the state shown in the picture to prepare for installation. Step 2: 1. Unlock the folding lock (1), as illustrated in the picture. 2.
- Page 8 Insert the short rear leg tube into the rear axle (as shown in the picture) until you hear a snapping sound, and ensure that the shrapnel insertion hole is confirmed to be installed. Next, insert the entire group into the rear foot of the platform, listen for a click, and confirm that the shrapnel insertion hole has been installed.
- Page 9 FRONT-WHEEL INSTALLATION: •Align the shaft of the front wheel group with the hole of the front foot tube seat and insert it until you hear a distinct ringing sound. Pull the wheel in the opposite direction to confirm that it is securely in place. •Install the other front wheel in the same manner.
- Page 10 1. Begin by placing the seat (1)(2) into the compartment as shown in the picture. 2. Next, thread the seat back webbing through the hole in the carriage wall, bypassing the horizontal tube, and fasten it using the buckle (3). 3.
- Page 11 INSTALLING KEENZ Vyoo TRAY: Lower the beverage rack to the middle position of the body and hang the beverage rack with four hooks on both sides of the body. Similarly, remove the beverage rack hook from the body.
- Page 12 CANOPY INSTALLATION: 1. Refer to figure (1) for guidance. 2. Open the switch in the direction of the arrow. 3. Lift the carriage pole upward (2). 4. Finally, secure the four angle buckles on the canopy to the four poles to complete the installation.
- Page 13 FOLDING: 1.Begin by removing the large canopy (1) and stowing the pole. 2.Then, squeeze the car handles (2) on both sides and lift them up simultaneously (3). 3.Pull in the pressure (4) on both sides until it is tightened. 4.Finally, fasten the car buckle to complete the folding process.
- Page 14 REVERSIBLE SEAT When removing the bar for use, the adhesive buckle attached to the seat must be connected to the frame WARNING: Back state: In the outward looking direction, when disassembling the frame, it should be closely connected to the frame, the Velcro installed on the front of the bottom of the seat should be closely connected to the frame, and the Velcro on the back of the seat should be connected to the tray.
- Page 15 FASTENING:Snap the buckle on the upper side of the seatbelt into the insert plate, and then insert the combined insert plate into the center buckle of the seatbelt. UNFASTENING: To unfasten the safety belt buckle, press both exposed insert parts on the sides of the center buckle, causing it to pop out and release the buckle.
- Page 18 After installing the canopy, open the four buckles on the top, lower the shade cloth on both sides, and secure it with adhesive buckles.
- Page 19 In addition to providing sunshade, the large canopy can also enhance ventilation. Similarly, by unzipping both sides of the big roof and rolling up the entire roof to one side, you can improve ventilation and create a more comfortable environment for your baby.
- Page 20 HANDLE ADJUSTMENT: Handle adjustment is divided into seven positions. First, press the knob adjustment button inside the handle joint on both sides with your thumb, and then adjust the handle's height as needed, up or down. first position...
- Page 21 REAR-WHEEL BRAKE:Press down on the rear wheel brake pedal to engage the brake, preventing the stroller from being pushed. To disengage the rear wheel brake, lift the brake pedal upward and push the stroller freely.
- Page 27 Vyoo...
- Page 28 Vyoo Essieu (1)
- Page 32 Insérez le tube court de la jambe arrière dans l’essieu arrière (comme le montre l’image) jusqu’à ce que vous entendiez un bruit de claquement, et assurez-vous que le trou d’insertion des éclats d’obus est confirmé. Ensuite, insérez le groupe entier dans le pied arrière de la plate-forme, écoutez un clic et confirmez que le trou d’insertion d’obus d’obus a été...
- Page 35 Vyoo...
- Page 38 SIÈGE RÉVERSIBLE Lors du retrait de la barre d’utilisation, la boucle adhésive attachée au siège doit être connectée au cadre. Avertissement État du dos: en regardant vers l’extérieur, lors du démontage du cadre, il devrait être étroitement relié au cadre, le Velcro installé sur l’avant du bas du siège devrait être étroitement relié...
- Page 50 Vyoo...
- Page 51 Vyoo Eje (1)
- Page 55 Inserte el tubo corto de la pierna trasera en el eje trasero (como se muestra en la imagen) hasta que escuche un sonido que se chasquey asegúrese de que el agujero de inserción de metralla se haya instalado. A continuación, inserte todo el grupo en el pie trasero de la plataforma, escuche un clic y confirme que el orificio de inserción de metralla ha sido instalado.
- Page 58 Vyoo...
- Page 61 ASIENTO REVERSIBLE Al retirar la barra para su uso, la hebilla adhefijada al asiento debe estar Conectado a la estructura. Advertencia: Estado posterior: en la dirección hacia el exterior, cuando se desmonta el marco, debe estar estrechamente conectado al marco, el Velcro instalado en la parte delantera de la parte inferior del asiento debe estar estrechamente conectado al marco, y el Velcro en la parte posterior del asiento debe estar conectado a la bandeja.
