- Page 2 PRODUCT PARAMETERS Product name： Standing Circulation Fan Model： KCF-10TRD Adapter： DC24V ，1A Motor： DC Inverter Motor Rated power： Product size： 602 x 524 x 962 mm Net weight： 2.08 kg Packing list： Fan head x 1、Iron pipe x6、remote control x1、...
- Page 3 PRODUCT SIZE 602mm 524mm...
- Page 4 UNBOXING Adapter Pull up the Pull up the Remote slit lock and first layer. upper closing It consists of tucks. adapter and remote. Body Upper and lower Warranty card Next layer is the Pull up the last foot tube & Manual unit’s body, owner’s layer.
- Page 5 INSTALLATION Notice: Do not insert the adapter output plug into the body when installing fans Align the lower foot tube with the thread hole of the upper foot tube in turn, tighten clockwise; Then, align the foot tube with the thread hole of the body and tighten it clockwise.
- Page 6 OPERATING INSTRUCTION Timer shutdown indicator Tilt Timer Angle of tilt oscillation 100° Display current wind 120° speed or auto 90° shutdown time 60° Oscillation Wind speed On / Off Angle of left and right oscillation 1. On/off After plugging in the unit, press the On/Off button “ ”...
- Page 7 COMPONENT DISASSEMBLY INSTRUCTION FRONT HOUSING DISSASSEMBLING Remove the outlet Turn the phillips screwdriver Rotate the outlet housing counterclockwise to remove housing counterclockwise to unlock the outlet housing screw BLADE DISASSEMBLING Rotate clockwise to release blade lock Draw blade forward to remove blade Obverse of blade REAR HOUSING DISASSEMBLING Turn the phillips screwdriver...
- Page 8 ATTENTION Please use the power adapter provided with the product. Before use, please make sure that the input voltage is used as required by the adapter within the voltage range (Adapter input : AC230V~, 60Hz; output: DC24V , 1A). The user is not allowed to disassemble and replace the internal parts of the fan at will.
- Page 9 Do not install three brackets only or no bracket at all! This is not recommended. It will make the product unstable and increase the risk of it falling over. To fully experience the efficiency of the Kolin Air Circulator, use it only with six brackets.
- Page 10 CLEANING MAINTENANCE AND SAFETY MATTERS 1. When cleaning, maintaining or moving the product, you must first turn off the product and then unplug the power cord. 2. The fan must be completely stopped before it can be cleaned to avoid injury. 3.
- Page 11 The design and specifications are subject to change without prior notice for product improvement. Any updates to the manual will be uploaded to the service website, please check for the latest version. If you have any concerns, please contact us at the following: Customer hotline: (02) 8852-6868 Text hotline:...
