- Page 1 STANDING CIRCULATION FAN INSTRUCTION MANUAL INSTRUCTION MANUA Model:KCF-10SRD Please read the instructions carefully before using this product.
-
Page 2: Product Parameters
PRODUCT PARAMETERS Product name： Standing Circulation Fan KCF-10SRD Model： KW-MF02RDA DC24V， Adapter： Motor： DC Motor Rated power： Product size： 330X330X925mm 2.3kg Net weight： Fan head x1 Folding fan x 1、Support tubes x 2、Base x 1、 Packing list： Remote control x1、User manual x1、Power adapter x1 POWER ADAPTER SPECIFICATION Input data：... -
Page 3: Product Size
PRODUCT SIZE 330mm 330mm... -
Page 4: Main Parts
MAIN PARTS Outlet housing Inlet housing Status panel Body Support tube 2 Tilt Timer adjustment Support tube 1 Oscillate Wind speed Base On/Off On/Off Timer Left & Right Wind speed+ oscillation Tilt oscillation Wind speed- input plug Remote-control unit (For the first time, please pull out the battery insulation sheet) Output plug... -
Page 5: Installation
INSTALLATION Notice: Do not insert the adapter output plug into the body when installing fans. assembling the fan. 1. Install Support tube 1 into hole of the base, and install Support tube 2 into corresponding hole of Support tube 1,then install the combined part into the top body, rotate clockwise until all parts are tightened. - Page 6 OPERATING INSTRUCTION Timer shutdown indicator Tilt Timer Angle of tilt oscillation 100° Display current wind 120° speed or auto 90° shutdown time 60° Oscillation Wind speed On / Off Angle of left and right oscillation 1. On/off After the power is switched on, press the switch button “ ”...
- Page 7 COMPONENT DISASSEMBLY INSTRUCTION FRONT HOUSING DISSASSEMBLING Rotate the outlet housing Remove the outlet Turn the phillips screwdriver counterclockwise to remove housing counterclockwise to unlock the outlet housing screw BLADE DISASSEMBLING Rotate clockwise to release blade lock Draw blade forward to remove blade Obverse of blade REAR HOUSING DISASSEMBLING Turn the phillips screwdriver...
- Page 8 NOTES： Please use the power adapter provided with the product. Before use, please make sure that the input voltage is used as required by the adapter within the voltage range (Adapter input : AC100-240V, 50/60Hz; output: DC24V, 1A). The user is not allowed to disassemble and replace the internal parts of the fan at will.
- Page 9 Do not put fingers, other body parts or debris into the air inlet/outlet to avoid injury and damage to the product. Do not put wet towels or wet wipes on the product to avoid electric leakage and electric shock accidents. When removing the protective shell for cleaning, be careful not to touch the touch buttons to avoid accidents in the operation of the product.
-
Page 10: Troubleshooting
6. After cleaning, the product must be completely dry before it can be connect- ed to the power supply. 7. If you will not use it for a long time, please store the product back in the box and store it in a dry, cool and safe place. 8. - Page 11 The design and specifications are subject to change without prior notice for product improvement. Any updates to the manual will be uploaded to the service website, please check for the latest version. If you have any concerns, please contact us at the following: Customer hotline: (02) 8852-6868 Text hotline:...
