- Page 2 PRODUCT PARAMETERS Product name： Standing Circulation Fan Model： KCF-10SRD Adapter： DC24V ，1A Motor： DC Inverter Motor Rated power： Product size： 330 x 330 x 925mm Net weight： 2.3 kg Packing list： Fan Head x 1、Support tubes x 2、Base x 1、...
- Page 3 PRODUCT SIZE 330mm 330mm...
- Page 4 UNBOXING Support Adapter Tube 1 Pull up the Pull up the Remote slit lock and first layer. upper closing It consists of tucks. adapter, remote, and first support tube. Body Support Tube 2 Next layer is the Warranty card & Manual unit’s body, owner’s manual and IMPORTANT...
- Page 5 INSTALLATION Notice: Do not insert the adapter output plug into the body when installing fans. 1. Install Support tube 1 into hole of the base, and install Support tube 2 into corresponding hole of Support tube 1,then install the combined part into the top body, rotate clockwise until all parts are tightened.
- Page 6 OPERATING INSTRUCTION Timer shutdown indicator Tilt Timer Angle of tilt oscillation 100° Display current wind 120° speed or auto 90° shutdown time 60° Oscillation Wind speed On / Off Angle of left and right oscillation 1. On/off After plugging in the unit, press the On/Off button “ ”...
- Page 7 COMPONENT DISASSEMBLY INSTRUCTION FRONT HOUSING DISSASSEMBLING Remove the outlet Turn the phillips screwdriver Rotate the outlet housing counterclockwise to remove housing counterclockwise to unlock the outlet housing screw BLADE DISASSEMBLING Rotate clockwise to release blade lock Draw blade forward to remove blade Obverse of blade REAR HOUSING DISASSEMBLING Turn the phillips screwdriver...
- Page 8 ATTENTION Please use the power adapter provided with the product. Before use, please make sure that the input voltage is used as required by the adapter within the voltage range (Adapter input : AC230V~, 60Hz; output: DC24V , 1A). The user is not allowed to disassemble and replace the internal parts of the fan at will.
- Page 9 Do not put fingers, other body parts or debris into the air inlet/outlet to avoid injury and damage to the product. Do not put wet towels or wet wipes on the product to avoid electric leakage and electric shock accidents. When removing the protective shell for cleaning, be careful not to touch the touch buttons to avoid accidents in the operation of the product.
- Page 10 TROUBLESHOOTING FAULT CAUSE TREATMENT DESCRIPTION ANALYSIS MEASURES The adapter is not Plug in the adapter plugged in. power cord plug. Machine No power supply. Replace power supply. can't work The switch button is Press the switch not pressed. button again. Wind leaf cracking.
- Page 11 The design and specifications are subject to change without prior notice for product improvement. Any updates to the manual will be uploaded to the service website, please check for the latest version. If you have any concerns, please contact us at the following: Customer hotline: (02) 8852-6868 Text hotline:...
