- Page 1 A XOR 250 1jet 35284XX7 A XOR 300 1jet 35300XX7 A XOR 250 ⁄ 250 1jet 35306XX7 Z H ⁄ 用户手册 ⁄ 组装说明 A XOR 300 ⁄ 300 1jet E N ⁄ Instructions for use ⁄ Assembly instructions 35314XX7 I N S T A L L A T I O N...
- Page 2 ! 安全技巧 符号说明 ! 装配时为避免挤压和切割受伤, 必须戴上手套. 请勿使用含有乙酸的硅胶! ! 本产品只允许作为洗浴, 卫生和洁身之用. 大小 (参见第页 08) ! 冷热水管间过大的压力差必须予以平衡. 流量示意图 (参见第页10) 安装提示 备用零件 (参见第页 11) ⁄ 安装前必须检查产品是否受到运输损害. 安装后将 不认可运输损害或表面损伤. 清洗 (参见第页 12) ⁄ 管道和阀门必须根据通用标准进行安装, 冲洗和 检查. 操作 (参见第页 09) ⁄ 请遵守当地国家现行的安装规定. ⁄ 由有资格的专业人员进行产品安装时请注意: 在所 有加固区域中, 加固表面是否平整 (无突出的接缝 或瓷砖), 墙体结构是否适合产品安装且未显露出 任何缺点. 技术参数 工作压强: 最大 0,6 MPa 推荐工作压强: 35284XX7 ⁄ 35306XX7 0,28 - 0,4 MPa 35300XX7 ⁄ 35314XX7 0,2 - 0,4 MPa (1 MPa = 10 bar = 147 PSI) 热水温度: ...
- Page 3 ! S A F E T Y N O T E S S Y M B O L D E S C R I P T I O N ! Gloves should be worn during installation to prevent Do not use silicone containing acetic acid! crushing and cutting injuries. D I M E N S I O N S (see page 08) ! The product may only be used for bathing, hygienic and body cleaning purposes.
- Page 4 X 8 m X + 8 mm 10 mm 10 mm...
- Page 5 Ø 6 m m...
- Page 6 2,5 mm (2 Nm) 4 mm (6 Nm)
- Page 7 CLICK (1 Nm)
- Page 8 A XOR 250 1jet 35284XX7 Ø 250 Ø 250 A XOR 300 1jet 35300XX7 Ø 300 Ø 300 A XOR 250 ⁄ 250 1jet 35306XX7 □ 238 □ 238 A XOR 300 ⁄ 300 1jet 35314XX7 □ 300 □ 300...
- Page 10 A XOR 250 1jet A XOR 300 1jet 35284XX7 35300XX7 0,60 0,60 0,55 0,55 0,50 0,50 0,45 0,45 0,40 0,40 0,35 0,35 0,30 0,30 0,25 0,25 0,20 0,20 0,15 0,15 0,10 0,10 0,05 0,05 0,00 0,00 Q = l/min 9 12 15 18 21 24 27 30 Q = l/min 9 12 15 18 21 24 27 30 Q = l/sec...
- Page 11 A XOR 250 1jet A XOR 250 ⁄ 250 1jet 35284XX7 35306XX7 A XOR 300 1jet A XOR 300 ⁄ 300 1jet 35300XX7 35314XX7 93455000 98186000 (30x2) 93456000 92137000 93399000 (M6x12) (120x2,5) 93431000 96179000 93419000 (M6) 98137000 (17x1,5) 93403XX0 98201000 93401XX0 (14x1,5) 93402000 934 52XX0 93400XX0 A XOR 250 ⁄ 250 1jet 93404000 934 53XX0 93454000 98430000 A XOR 300 ⁄ 300 1jet (12x1,5)
- Page 12 ⁄ ⁄ ⁄ ⁄ ⁄ Axor ⁄ , Axor ⁄ www.hansgrohe.com/guarantee. ⁄ ⁄ QuickClean QuickClean, ⁄ ⁄ QUICK CLEAN...
- Page 13 If nevertheless any defect is detected ⁄ The safety instructions of the cleaning agent manufactur- within 5 years from date of purchase, Axor will remedy this ers must be strictly followed. defect free of charge. You will fi nd the conditions and de- ⁄...
- Page 15 max. 10 min CLICK (1 Nm)
- Page 16 Z H ⁄ 注意! 表面损坏的部件必须更换, 否则会有 受伤的危险. E N ⁄ Important! Components with damaged surfaces must be exchanged, otherwise there could be an injury danger. Axor ⁄ Hansgrohe SE Auestraße 5–9 77761 Schiltach Deutschland info@axor-design.com axor-design.com...
