Page 3
S A F E T Y N O T E S T E C H N I C A L D A T A Gloves should be worn during installation to prevent crushing and cutting injuries. Operating pressure: max. 1 MPa The product may only be used for bathing, hygienic and body cleaning purposes. Recommended operating pressure: 0,2 - 0,5 MPa Test pressure: 1,6 MPa The hot and cold supplies must be of equal pressures. (1 MPa = 10 bar = 147 PSI) The product may not be used as a holding handle. A separate handle must be Hot water temperature: max. 70°C installed. Recommended hot water temp.: 65°C Do not allow the streams of the shower touch sensitive body parts (such as your...
Page 4
± 2 m m SW 27 mm X + 38 mm SW 3 mm (6 Nm) SW 2 mm (4 Nm)
Page 6
SW 2 mm SW 3 mm (5 Nm) SW 17 mm (10 Nm) SW 2 mm (2 Nm) 94246000...
Page 7
z. B. 42° C SW 3 mm for example 42° C SW 3 mm (1 Nm)
Page 8
SW 3 mm SW 3 mm SW 2 mm SW 22 mm SW 3 mm (6 Nm) SW 22 mm (4 Nm) 红色 ⁄ red SW 3 mm (5 Nm) 1 Nm SW 2 mm Armaturenfett Grease ( 4 Nm) Nr. 10476220...
