TMB-2088

TMB-2288-B

Guangdong Transtek Medical Electronics Co., Ltd.

Zone A, No.105, Dongli Road, Torch Development

District, 528437 Zhongshan, Guangdong, China

MDSS GmbH

EC REP

Schiffgraben 41, 30175 Hannover, Germany

20240517-v6 TMB-2288-B UK

User Manual

Smart Blood Pressure Monitor

Thank you for selecting the Kinetik Wellbeing Smart Blood Pressure Monitor.

Please read the user manual carefully and thoroughly, this is to ensure the

safe usage of the product. Please keep the user manual for future

reference.

TMB-2088

TMB-2288-B

Need help?

Do you have a question about the TMB-2088 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kinetik TMB-2088

Page 1 TMB-2288-B TMB-2288-B Guangdong Transtek Medical Electronics Co., Ltd. Thank you for selecting the Kinetik Wellbeing Smart Blood Pressure Monitor. Zone A, No.105, Dongli Road, Torch Development District, 528437 Zhongshan, Guangdong, China Please read the user manual carefully and thoroughly, this is to ensure the safe usage of the product.
Page 2 CATALOGUE Table of Contents SUPPORT..........................2 INTRODUCTION........................3 General Description Indications for Use Measurement Principle Receiving and Inspecting your Monitor Safety Information Display and Symbols Name of Each Part Contents/Product Includes BEFORE YOU START......................10 Choice of Power Supply Installing and Replacing the Batteries Setting the Date and Time Setting a user ID Pair a smart device with the monitor...
Page 3 INTRODUCTION General Description Support Thank you for selecting the Kinetik Wellbeing Smart Blood Pressure Our manual should provide you with all the information you need Monitor. The monitor features blood pressure measurement, pulse to set up and use this product.
Page 4 (testing at least at 50 mmHg and 200 mmHg). Please contact Kinetik Wellbeing Authorized representative in the European Community/ for authorised service personnel.
Page 5 * At the request of authorised service personnel, circuit diagrams, component part lists, descriptions, and calibration procedures will be made available by Kinetik Wellbeing. Cuff wearing OK symbol * The expected lifetime of the cuff may vary by the frequency of washing, skin condition, and storage state.
Page 6 INTRODUCTION INTRODUCTION Name of Each Part SYMBOL EXPLANATION CUFF Pulse display Pulse rate appears after the measurement. AIR HOSE Warning Messages [User/Forward] Refer to page 30 for more information. button Blood Pressure Trends AIR CONNECTOR Appears when viewing the blood pressure trends PLUG of the specified period of the past 7 days under Type-C port...
Page 7 BEFORE YOU START BEFORE YOU START Choice of Power Supply Setting the Date and Time It is important to set the date and time before using your blood pressure Battery powered mode: 6VDC 4×AA batteries monitor for the first time, so that a correct time stamp can be assigned to AC adaptor powered mode: each record that is stored in the memory.
Page 8 BEFORE YOU START BEFORE YOU START 3. Press the “START/STOP” button to confirm the date format, then the 6. After confirming the [Minute], the LCD will display all the settings [Month] will flash. Repeat the same steps to set the [Month] and [Day]. you have done, and then it will display “do nE”...
Page 9 BEFORE YOU START BEFORE YOU START Setting a user ID Pair a smart device with the monitor You can measure your blood pressure and have the measurement data There are 3 user ID available. The user , have 250 automatically sent to a smart device (such as smartphone or tablet) with memories, so that 2 people can save their measured values separately.
Page 10 MEASUREMENT BEFORE YOU START Applying the cuff Only use a cuff that has been approved by Kinetik Wellbeing for this device. Before use, please confirm if it fits your arm circumference. Remove all jewelery , such as watches Specifications for Bluetooth Transmission and bracelets from your left arm.
Page 11 MEASUREMENT MEASUREMENT Start a measurement Note Any time, to stop the measurement, press the “START/STOP” button. You can use your monitor without pairing to a smart device. To pair your If you don’t pair the device with the MedM Blood Pressure Diary or MedM monitor with a smart device refer to page 15.
Page 12 MEASUREMENT DATA MANAGEMENT Recall the Records 4. About the irregular pulse rate and excessive body motion during the measurement. 1. When the monitor is off, press the “MEM” button, the LCD will display During a measurement, If an irregular pulse rate is detected, the symbol the total groups of the memory records, with the user ID blinking.
Page 13 DATA MANAGEMENT DATA MANAGEMENT Delete the Records When the maximum average systolic pressure is higher than 170mmHg or the maximum average diastolic pressure is higher than 110mmHg, the Delete the records by following the steps below. symbol“ ” will be displayed. When the minimum average systolic pressure is lower than or equal to A: Delete one record (Example shown below for User 1) 100mmHg, the minimum average diastolic pressure is lower than or equal...
Page 14 DATA MANAGEMENT DATA MANAGEMENT B: Delete all records (Example shown below for User 1) 4. Once deleted, your readings cannot be restored. The LCD will display “---” like the following picture. 1. Enter the memory recall mode as described in the previous section "Recall the records".
Page 15 INFORMATION FOR USER INFORMATION FOR USER Tips for Measurement Maintenance Measurements may be inaccurate if taken in the following In order to get the best performance, please follow the instructions circumstances. below. 1. Cleaning Process: Step 1: Make sure to switch off and unplug the device prior to cleaning. Step 2: Use a soft cloth and dampen it with soapy water to clean the cuff first, and then use a soft cloth and damped it with clear water to remove residual soap until there is no visible residual...
Page 16 ABOUT BLOOD PRESSURE ABOUT BLOOD PRESSURE What are systolic pressure and diastolic pressure? Blood Level Optimal Normal High-normal Mild Moderate Severe Pressure When ventricles contract and pump blood out of the heart, the blood (mmHg) pressure reaches its maximum value in the cycle, which is called systolic <120 120-129 130-139...
Page 17 We suggest you range. problem persists, contact measure the same arm every time. your physician. NOTE: If the product still does not work, contact Kinetik Wellbeing. Under no circumstance should you disassemble or attempt to repair the unit by yourself.
Page 18 SPECIFICATIONS AUTHORIZED COMPONENT External dimensions Approx.178 mm × 101 mm × 42.89 mm Authorized Component Display mode Digital LCD V.A.124 mm × 76 mm Please use the authorised adapter (not included). Approx.343 g (Excluding the batteries and cuff) Weight Measurement mode Oscillographic testing mode Mode of operation Continuous operation...
Page 19 EMC GUIDANCE EMC GUIDANCE EMC Guidance Technical description： 1. All necessary instructions for maintaining BASIC SAFETY and ESSENTIAL The ME EQUIPMENT or ME SYSTEM is suitable for home healthcare environ- PERFORMANCE with regard to electromagnetic disturbances for the expected ments. lifetime.
Page 20 EMC GUIDANCE EMC GUIDANCE Table 2 Table 3 Guidance and manufacturer’s declaration - electromagnetic Immunity Guidance and manufacturer’s declaration – electromagnetic Immunity Compliance Radiated RF Test Band Service Modulation Distance Maximum IEC 60601-1-2 Immunity Test 60601-1-2 level Compliance level IEC61000-4-3 Frequency (MHz) Power...
