Racelogic VBOX Omega User Manual

Tests
• You can access the menu by pressing the OK button.
• Use the Up and Down arrows to navigate through the menu and press the OK button to enter a submenu or
change a setting.
• When editing a setting, the Up and Down buttons will let you scroll through the available options for that setting
and the OK button will confirm your selection.
• Use the Back button to exit a setting.
This menu can be used to configure test/lap
timing settings.
S/F Gate Width
Defines the width of any gates set up to 99.99 m (25 m
by default).
Retrigger Time
Defines the minimum time between triggers for the
second trigger to be valid. If a trigger is detected before
this time, it will be ignored (1 s by default).
