Front Panel

To facilitate unit configuration, VBOX Omega has an

OLED display and four membrane buttons on the front

panel.

Buttons

Display

Menu up / Increase the

value when editing a

number.

Menu down / Decrease

the value when editing a

number.

https://en.racelogic.support//Product_Info/Sensors/VBOX_Omega/VBOX_Omega_-_User_Guide/03_Front_Panel

Move to the previous

menu level.

Enter the menu / select

the menu item for

adjustment.

Need help?

Do you have a question about the VBOX Omega and is the answer not in the manual?

Page 1 Front Panel To facilitate unit configuration, VBOX Omega has an OLED display and four membrane buttons on the front panel. Buttons Menu up / Increase the Move to the previous value when editing a menu level. number. Menu down / Decrease...
Page 2 Startup When VBOX Omega is powered up, it will display 'VBOX Omega' and then the serial number of the unit. Next, it will change to display the firmware version of the unit. When the unit has initialised and any status messages have been cleared, the display will show 'Waiting for movement'.
Page 3 • Medium Accuracy When the speed quality is <0.1 km/h. • OK When the speed quality is <0.06 km/h for at least 5 seconds. For more information on how to calibrate the Kalman Filter on VBOX Omega, click here. https://en.racelogic.support//Product_Info/Sensors/VBOX_Omega/VBOX_Omega_-_User_Guide/03_Front_Panel...
Page 4 You can reset the unit to its factory settings by pressing the Up and Down arrow buttons simultaneously and holding them for 5 seconds. After this period, the unit will beep and it will play an audible confirmation signal when the reset is finished. Note: Receiver settings (DGNSS Rate and Elevation mask) will not reset. https://en.racelogic.support//Product_Info/Sensors/VBOX_Omega/VBOX_Omega_-_User_Guide/03_Front_Panel...
