Elite Models: FM-3209-L/Y, FM-3210-L/Y,
STOP and Read
1. Do NOT plug in power cord to power source, check if any loose parts.
2. Plug in 120V power source (some old air curtains might use 240V, verify
the power voltage if not sure); press the front switch to H or L to turn on.
If the air curtain works normally, refer to section 3 through 7 to install
the air curtain. Refer to section 10 for technical support.
3. After installation, if the air curtain doesn't run, first step is to check the
magnetic switch. Refer to section 7 for troubleshooting.
Thanks for purchasing this Air Curtain.
PLEASE READ AND SAVE THESE INSTRUCTIONS.
Strongly recommend to test the unit before installation for any
defective or damage during shipment.
USER'S GUIDE
Version: FM32-202305
AIR CURTAINS
FM-3212-L/Y, FM-3215-L/Y
! Test before installing
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Awoco FM-3209-L/Y
Summary of Contents for Awoco FM-3209-L/Y
- Page 1 USER’S GUIDE Version: FM32-202305 AIR CURTAINS Elite Models: FM-3209-L/Y, FM-3210-L/Y, FM-3212-L/Y, FM-3215-L/Y ! Test before installing STOP and Read 1. Do NOT plug in power cord to power source, check if any loose parts. 2. Plug in 120V power source (some old air curtains might use 240V, verify the power voltage if not sure);...
- Page 2 WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, READ THE FOLLOWING CAREFULLY before attempting to assemble, install, operate, or maintain the product. A. Always disconnect, lock and tag power source before installing or servicing. Failure to disconnect power source can result in fire, shock or serious injury.
- Page 3 2. INSTALLATION CAUTIONS Must observe the following when installing air curtains: Strongly recommend to test the unit before installation for any defective or damage during shipment. 2.1 Please install the unit on a sturdy 2.2 Please install the unit indoor. Require 2 supporting structure to avoid shaking and inches clearance to the ceiling.
- Page 4 3. INSTALLATION INSTRUCTIONS A. Installing on the concrete wall: 3.1.1 Unscrew the fixing screws to remove 3.1.2 Determine the mounting location with the mounting plate from the back of the main the mounting plate. Drill holes and insert the Zinc-Plated Steel Hex-Nut-Head Sleeve body.
- Page 5 Air volume Max air Model entry Voltage level Power (CFM) Current velocity weight opening (dB) (V~Hz) (FPM) (Lb) (Inch) 2.72 FM-3209-L/Y 26.5 FM-3210-L/Y 120V, 2.84 3150 (H), 27.6 60Hz 2559 (L) FM-3212-L/Y 3.64 1236 32.0 FM-3215-L/Y 4.66 1566 1236 40.0 Note: The specification data are subjected to change without notice due to product development.
- Page 6 5. WIRING DIAGRAM 6. OPTIONAL MAGNETIC SWITCH INSTALLATION This air curtain comes with a magnetic door switch, contact seller or Awoco if you are missing a magnetic switch. The dedicated 2 wires (Yellow) are to connect to the magnetic switch.
- Page 7 Mount the 2 pieces magnetic switch to the door/window edge and frame; keep them close when the door/window is closed. If needed, apply a metal “Z” bracket to raise the magnet to the same position. Note: Do NOT use big screws!!! Oversized screws will damage the magnetic switch internally. Note: Don’t place the magnetic switch close to existing alarm sensors.
- Page 8 Return/exchange is always the option. Feel free to contact Awoco technical support at 1-888-412-3428 if you need help. Awoco has all the parts for 1 year limited warranty, including fan wheels, magnetic switches, circuit boards, motors, etc.
- Page 9 9.6. Dry the case with a soft dry cloth before operating the unit. 10. SUPPORT AND CONTACT Contact your local seller for exchange or repair. Visit www.awoco.com for most updated information. Email to sales@awoco.com or call 1-888-412-3428 for technical support and sales activity.
