BALAY 3VF330NP - annexe 1 Instructions

en
Short and handy: everything
your dishwasher needs...
Before using for the first
time, read the Installation
and Operating Instructions!
Add salt.
Add rinse-aid.
Add detergent.
Select programme.
Switch appliance ON
Press main switch, choose programme.
Close door.
Switch appliance OFF
Signal sounds, open door. End-of-programme
indicator flashes, press main switch.
Setting the water softening system *
Find out the water
hardness at your water
utility company and
enter below
* only before using the
dishwasher for the first
time or if the water hard-
ness changes
Dissolves limescale (not required for set value 0!)
Everything is sparkling clean ...
Very dirty dishes, a lot of detergent ...
Quick, economical or intensive ...
Overview of programmes
This overview indicates the max. possible number of
programmes. The programmes which correspond to your
appliance can be found on your appliance fascia.
The programme data are values measured in the
laboratory in compliance with Standard EN 50242.
Deviations is practice are possible.
Additional programmes **
, off we go...
, everything OK...
** on some models
Read off the setting
°fH
°dH °Clarke mmol/l Setting
0–6 0–11 0–8 0–1,1 0
7–16 12–29 9–20 1,2–2,9 1
17–21 30–37 21–26 3,0–3,7 2
22–35 38–60 27–44 3,8–6,2 3
Only before using
Unscrew
the dishwasher
the lid.
for the first time
pour approx. 1 l /
1 1/4 pt water into
the salt opening.
Press mark 1,
lift up lid 2.
Warning,
If required, open
the lid (press the
combination
pin).
products are not
suitable for all
programmes,
follow manufac-
turer's instructions.
Duration in minutes
Power consumption in kWh
Water consumption in litres
Increased flexibility ...
Extra dry
... improves the drying
result by increased
temperature in the final
rinse (Please take care
with delicate dishes)
Quickly sorted
and then select a setting
– Hold down programme button B and switch on the main
A B C
switch, then release the buttons. The
buttons A and B illuminate (water hardness setting was set
Reset
to 2 at the factory).
– Each time button B is depressed, the setting increases by
one (0-3). If buttons A, B and C illuminate, the maximum
water hardness setting has been reached. If the water
hardness setting is now increased again, the lights go out
and the water hardness setting is set to 0.
– Switch off the main switch. The selected setting has been
stored in the appliance.
Pour in max.
1.5 kg / 3 lb 5 oz
salt (never deter-
gent!)
Refill whenever level indicator is light!
Pour in
rinse aid.
Pour in
detergent.
Normal Eco
Intensive
70_ 65_ 50_
120 110 140
2,00 1,75 1,05
21 21 17
Upper basket cleaning Half load
...Only the crockery in the
... for a few items, saves
upper basket is cleaned
water, energy and time
. display flashes and
Screw on the
lid. Switch on
dishwasher
immediately.
Close the
lid. CLICK!
Push the lid
shut, press.
PLOP!
Quick Prerinse
Gentle
40_ 35_
70 30 15
1,00 0,80 0,10
17 13 5
