BALAY 3VF781XA - annexe 1 Instructions

en
Brief and handy: everything
your dishwasher needs ...
Before using for the first
time, read the operating
instructions!

Filling the salt dispenser

Adding rinse aid

Adding detergent

Switching on the appliance

Select programme

Start programme
Here we go...
Switch off the appliance Everything o.k...

Adjusting the water softening system *

Ask your water supply
company what the
water hardness is and
enter...
* only before the
first wash or if the
water hardness
has been
changed
Dissolves limescale (not necessary for set value 0 !) ...
Unscrew
cover.
Spick and span ...
Press mark 1,
lift up cover 2.
A lot of dirt, a lot of detergent ...
If required, open Attention
the cover (press
Combination
button).
products are not
suitable for all
programmes, follow
manufacturer's
instructions.
Quick, economical or intensive ...

Overview of programmes

The max. possible number of programmes is illustrated
in this overview. The corresponding programmes for your
appliance can be found on the fascia.
The programme data has been measured in the laboratory
according to European standard EN 50242.
Deviations are possible in practice.
*
half normal load

Additional options **

Express Wash Half load
(VarioSpeed)
... for a few items, saves
... is obtained by
water, energy and time
increased energy
consumption at a
constant cleaning and
drying performance.
** depending on model
Quickly sorted ...
How to adjust the water softening system
– Switch on ON/OFF switch
– Hold down programme button A and press START button until H:0...
A B C
is indicated on the digital display.
– Release both buttons.
The LED for button A flashes and the factory set value of H:04 is
indicated on the digital display
– Press programme button C.
Each time the button is pressed the set value increases by one setting;
when the value reaches H:07, the display jumps back to H:00 (off).
– Press START button. The chosen setting has now been stored.
Fill the salt Add salt
dispenser with (never add
water before the detergent!).
first wash only.
Refill if rinse-aid refill indicator is lit!
Adding
rinse aid.
Adding
detergent.
Intensive Auto
70_ 45_/65_
Duration: hs/mins
2:15 1:35-2:30
Energy Consumption: kWh
1,50 1,00-1,60
Water consumption in litres 15 –
With Aquasensor
12 9-19
Flexibility ...
IntensiveZone Hygiene
... perfect for a mixed ... The temperature is
load. Washing pressure increased during
and washing the rinsing process. This
temperature are increases the hygiene
increased slightly. status.
Screw on the
cover. Wash
immediately.
Screw on
the cover.
CLICK!
Slide cover
shut, press.
PLOP!
Eco Gentle Quick Prerinse
50_ 40_ 45_
*
2:20 1:10 0:29 0:15
1,05 0,80 0,80 0,05
10 13 10 4
– 10 – –
Extra drying
... improves the drying
result by increased
temperature in the final
rinse (Please take care
with delicate dishes)
