Installation Guide
8-port Gigabit Ethernet High-Power PoE+
Unmanaged Essentials Switch with FlexPoE
Model GS308PP
Package contents
•
Switch
•
Power cord (varies by region)
•
Power adapter (90W)
•
Wall installation screws
•
Rubber feet
•
Mounting ties (for power adapter)
•
Installation guide
Advertisement
Related Manuals for NETGEAR GS308PP
Summary of Contents for NETGEAR GS308PP
- Page 1 Installation Guide 8-port Gigabit Ethernet High-Power PoE+ Unmanaged Essentials Switch with FlexPoE Model GS308PP Package contents • Switch • Power cord (varies by region) • Power adapter (90W) • Wall installation screws • Rubber feet • Mounting ties (for power adapter) •...
- Page 2 From a computer or mobile device that is connected to the Internet, visit my.netgear.com. Log in to your NETGEAR account. NOTE: If you don’t have a free NETGEAR account, you can create one. The Your Registered Products page displays. Click the REGISTER NEW PRODUCT button.
- Page 3 Failure to do so can damage the switch. WARNING: Before connecting this switch to outdoor cables or devices, see https://kb.netgear.com/000057103 for safety and warranty information. 3. Check the LEDs When you connect the power cord to the switch and plug it into an electrical...
- Page 4 Description Solid Green: The port is delivering PoE power. Right Port LED Off: The port is not delivering PoE power. Solid yellow: A PoE fault occurred. PoE considerations The switch can supply up to 30W PoE+ (IEEE 802.3at) to each port, with a maximum PoE power budget of total 83W with a 90W power adapter and total 123W with a 130W power adapter across all active PoE+ ports.
- Page 5 Device Compatible Class Maximum Power Class Description Power Supplied Delivered to Standard by the Switch the Device PoE and Mid power 15.4W 6.49W–12.95W PoE+ PoE+ High power 30.0W 12.95W–25.5W Change the switch’s PoE budget As an option, you can move the slider on the back of the switch to increase or decrease the PoE budget.
- Page 6 PoE troubleshooting Here are some tips for correcting PoE problems that might occur: • If the PoE Max LED is yellow, disconnect one or more PoE devices to prevent PoE oversubscription. Start by disconnecting the device from the highest- numbered port. •...
- Page 7 Mount the switch on a wall We recommend that you use the wall-mount screws that are included. The screws are 0.25 in. (6.5 mm) in diameter, 0.86 in. (22 mm) in length. Locate the two mounting holes on the bottom panel of the switch. Mark and drill two mounting holes in the wall where you want to mount the switch.
- Page 8 See the regulatory compliance document before connecting the power supply. For NETGEAR’s Privacy Policy, visit https://www.netgear.com/about/privacy- policy. By using this device, you are agreeing to NETGEAR’s Terms and Conditions at https://www.netgear.com/about/terms-and-conditions. If you do not agree, return the device to your place of purchase within your return period.
