A.9 Image
The image element can be used to send various messages. It can be controlled
using feedback messages. The following sections will give a detailed explanation
about the send and receive capabilities of the image element.
A.9.1 Send
OSC
Type Function
Bool Control
Bool Control
Integer Control
Integer Control
Integer Set
Integer Set
UDP and TCP
Type Function
None -
None -
Bool Control
Bool Control
Integer Control
Integer Control
Integer Set
Integer Set
A.9.2 Feedback
Feedback can be sent to an image using its tag. The type of message determines
which attribute of the button it changes. The following attributes of an image
can be set using feedback:
• Alpha
The default alpha of the image is set to 100%, but it can be temporarily
changed using a feedback message. Reloading the showfile will return the image
to its default alpha.
Property Value Down
- On
Toggle On
- 1
Toggle 1
- Number
Toggle Number
Property Value Down
- Tag only
Toggle Tag only
- On
Toggle On
- 1
Toggle 1
- Number
Toggle Number
73
Value Up
Off
Off
0
0
-
Number
Value Up Example
- my-image
Tag only my-image
Off my-image=On
Off my-image=On
0 my-image=1
0 my-image=1
- my-image=23
Number my-image=23
