A.6 Axis
The axis element can be used to sent position values in a 2 float number between
-1.00 and 1.00 separated by a coma (,) format. It can be controlled using
feedback messages. The following sections will give a detailed explanation about
the send and receive capabilities of the axis element.
A.6.1 Send
OSC
Type Function Value
Float Control
UDP and TCP
Type Function Value
Float Control
A.6.2 Feedback
Feedback can be send to an axis using its tag. The type of message determines
which attribute of the fader it changes. The following attributes of an encoder
can be set using feedback:
• Value
The current value of an axis can be set by a feedback message, for example to
indicate the current position of a moving head. The axis responds to feedback
matching its type.
• Colour
The default colour of the axis is set in the showfile, but it can be temporarily
changed using a feedback message. Reloading the showfile will return the axis
to its default colour.
OSC
Type Value
Float 0.00,0.00
Colour colour
decimal number, decimal number
dec. num., dec. num.
Controls
Value
Colour
68
Range
(-1.00,-1.00) - (1.00,1.00)
Range
(-1.00,-1.00) - (1.00,1.00)
Example
axis=0.50,-0.46
