A.3 CheckBox
The check box can be used to sent various messages. It can be controlled using
feedback messages. The following sections will give a detailed explanation about
the send and receive capabilities of a check box.
A.3.1 Send
OSC
Type Function
Bool Control
Integer Control
UDP and TCP
Type Function
Bool Control
Integer Control
A.3.2 Feedback
Feedback can be send to a check box using its tag. The type of message deter-
mines which attribute of the check box it changes. The following attributes of
a check box can be set using feedback:
• State
The state of a check box can be used as visual feedback to the user, indicating
for example if a light or cue is active. When enabled, either via a feedback
message or by pressing check box area, the inside of the box will be filled.
• Label
The label is a string of text displayed close to the check box. The default
value is set in the showfile, but it can be temporarily changed using a feedback
message. Reloading the showfile will return the check box to its default label.
• Colour
The default colour of the check box is set in the showfile, but it can be
temporarily changed using a feedback message. Reloading the showfile will
return the check box to its default colour.
Value Checked Value Unchecked
On Off
1 0
Value Checked Value Unchecked
On Off
1 0
63
Example
my-check=On
my-check=1
