A.5 Encoder
The encoder element can be used to sent various control values. It can be
controlled using feedback messages. The following sections will give a detailed
explanation about the send and receive capabilities of the encoder element.
A.5.1 Send
OSC
Type Function
Float Control
Integer Control
UDP and TCP
Type Function
Float Control
Integer Control
A.5.2 Feedback
Feedback can be send to an encoder using its tag. The type of message deter-
mines which attribute of the fader it changes. The following attributes of an
encoder can be set using feedback:
• Value
The current value of an encoder can be set by a feedback message, for example
to indicate the current intensity of a playback.
feedback matching its type, and it takes into account the min and max range
set in the showfile.
• Label
The label is a string of text displayed inside the encoder.
value is set in the showfile, but it can be temporarily changed using a feed-
back message. Reloading the showfile will return the encoder to its default label.
• Colour
The default colour of the encoder is set in the showfile, but it can be temporarily
changed using a feedback message. Reloading the showfile will return the
encoder to its default colour.
Value
decimal number
whole number
Value
decimal number
whole number
66
Range
Min-Max
Min-Max
Range Example
Min-Max my-encoder=0.50
Min-Max my-encoder=127
The encoder responds to
The default
