Figure 52. DD9300 with DS60 shelves, HA

DD9300 with DD Cloud Tier or HA and DD Cloud Tier

Table 14. DD9300 with DS60 DD Cloud Tier or HA and DD Cloud Tier primary node cabling instructions

String

I/O - Port

(Loop)

I/O 7 - Port 0

I/O 2 - Port 0

I/O 7 - Port 1

Shelf Port

A controller port 0 of shelf V1.1

B controller port 0 of the highest number shelf in V1

A controller port 0 of shelf V2.1

Connect Cables and Power On
