Table 7. List of parts used in nutbar installation illustration
Image # Description
1 Nutbar location in 4U space
2 Rail location in the 4U space
3 Rail bracket alignment pins
4 Nutbar alignment pins
5 Nutbar M5 securing screws, black
Figure 48. Nutbar installation (Left nutbar shown)
NOTE: The nutbars are not interchangeable. There is a distinct nutbar for the left and right side. Use part numbers for
identification.
Qty Part number
1 ea Nutbars: (Left: 051-000-357), (Right:
051-000-356)
n/a N/A
n/a N/A
n/a Part of PN 051-000-357 and PN 051-000-356
4 PN 036-709-013
