INTRODUCTION TO THE PURCHASER This new accessory was carefully designed to give years of dependable service. This manual has been provided to assist in the safe operation and servicing of your attachment. NOTE: All photographs and illustrations in the manual may not necessarily depict the actual models or attachment, but are intended for reference only and are based on the latest product information available at the time of publication.
Page 4
SAFETY PRECAUTIONS Careful operation is your best insurance against an accident. Read this section carefully before operating the vehicle and accessory. This accessory is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury. All operators, no matter how experienced they may be, should read this and other manuals related to the vehicle and accessory before operating.
Page 5
SAFETY PRECAUTIONS OPERATION: MAINTENANCE AND STORAGE Do not put hands or feet near, under or inside rotating parts. When cleaning, repairing or inspecting the vehicle and accessory: stop the engine, set brake, remove Exercise extreme caution when operating on or ignition key, and wait that all moving parts have crossing gravel drives, walks or roads.
Page 6
SAFETY DECALS REPLACE IF DECALS ARE DAMAGED SEE PARTS BREAKDOWN FOR DECAL LOCATION DECAL #105130 Before installing or using: Locate, read and make sure to understand all of the owner’s manual. DECAL #105946 To avoid serious injury: Keep all parts of the body away from moving components. When dismounting the plow from the tractor never put hands between the lifting frame and the push frame.
Page 7
ASSEMBLY TOOLS REQUIRED: Wrench: 1/2”, 9/16”, 3/4” Socket: 1/2”, 9/16”, 3/4” Note : Always torque bolt per the torque specification table unless noted otherwise. Overall view STEP 1: TRACTOR PREPARATION: Install the tire chains if required. Follow the installation instructions supplied with the kit.
Page 8
ASSEMBLY STEP 3: SUBFRAME INSTALLATION: TYPE ’’A’’ FRAME All these parts come from the tractor. Refer to the parts breakdown of the tractor for identification of the parts. Remove the left and right brackets (items 1 & 2) from the tractor, as shown. Put away these brackets and keep the other parts for future use.
Page 9
ASSEMBLY TYPE ’’B’’ FRAME All these parts come from the tractor. Refer to the parts breakdown of the tractor for identification of the parts. Remove bracket (item 3) from the tractor as shown. Put away this bracket and keep the other parts for future use.
Page 10
ASSEMBLY STEP 4: SNOW PLOW INSTALLATION ON THE PUSH FRAME; Install the assembled snow plow on the assembled push frame as shown. Do not over tighten the bolts. The snow plow must be able to rotate freely on the push frame assembly. Plow O/L= Parts that are supplied with the kit and can be found locally when a replacement part is required.
Page 11
ASSEMBLY STEP 6: PEDAL INSTALLATION: Install the pedal on the assembled push frame, choose the right holes according to the desired position. O/L= Parts that are supplied with the kit and can be found locally when a replacement part is required. Install the pedal.
Page 12
OPERATION ADJUSTING THE ANGLE OF THE SNOW WARNING PLOW Lift the latch on the push frame to unlock the plow, Read the tractor Owner’s Manual carefully. Be then pivot the snow plow to the desired position. thoroughly familiar with the controls & proper Make sure the snow plow is well locked into place.
Page 13
MAINTENANCE & DISMOUNTING & STORAGE Refer to parts breakdown section for parts CAUTION identification. TO PREVENT INJURIES: WARNING When dismounting the snow plow from the tractor never put hands between the lifting frame and the TO PREVENT INJURIES: push frame. Stop the motor.
Page 18
PARTS LIST SNOW PLOW 585 64 44-02 Ref. Qty. Part # English description Description française Réf. Qté. Pièce # Lifting frame Châssis de relevage 107099 Subframe Sous-châssis 107100 Push frame Châssis de poussée 107101 Latch Loquet 107102 Lift pedal Pédale de relevage 107103 Pedal support Support de pédale...
Page 19
PARTS LIST SNOW PLOW 585 64 44-02 Ref. Qty. Part # English description Description française Réf. Qté. Pièce # Hex. bolt 5/8" n.c. x 2 1/2" GR5 Boulon hex 5/8" n.c. x 2 1/2" GR5 Hex. bolt 1/2" n.f. x 1 1/4" GR8 Boulon hex 1/2"...
Page 20
TORQUE SPECIFICATION TABLE GENERAL TORQUE SPECIFICATION TABLE USE THE FOLLOWING TORQUES WHEN SPECIAL TORQUES ARE NOT GIVEN NOTE: These values apply to fasteners as received from supplier, dry or when lubricated with normal oil. They do not apply if special graphited or moly disulphide greases or other extreme pressure lubricants are used. This applies to both UNF and UNC threads.
